Mounting instructions
Montagevoorschrift
Instructions de montage
Montageanleitung
Guía de montaje
Istruzioni di montaggio
Instruções de montagem
Monteringsanvisning
Instrukcja montażu
Rekomendacii po ustanovke
step 1
PFA 9012
LCD ceiling support
Amount
A
1
B
1
C
1
D
D
1
E
1
F
2
G
1
H
4
I
4
16
step 2
E
D
F
C
B
A
Bolt
M8 x 20 / M8 x 0,79
LCD ceiling support
U-shape
Washer (metal)
Nut
Bolt
M6 x 20 / M6 x 0,79
Tube
PFA 9015: 800 / 31
(optional)
PFA 9003: 1500 / 60
PFA 9004: 3000 / 118
Bolt
M4 x 10 / M4 x 0,39
Washer (metal)
Total
G
I
H
mm / inch
M12
M8
M4
