Aidoo Pro Air To Water
accessories
AIDOO PRO FANCOIL
EN
Perform the connection and configuration of the elements according to their technical
specifications:
•
AZAI6WSPFAN - Aidoo Pro Fancoil
•
AZAI6WSPXXX - Aidoo Pro for aerothermal equipment
Connection
Connect the INT port of the Aidoo Pro Fancoil to the RS485 port of the Aidoo Pro Air To Water.
FANCOIL
INT
10
ZONE
AZAI6WSPFAN
RS485
AZ1
AIR TO WATER
HEAT PUMP
AZAI6WSPXXX
DHW
Fancoil water
production
