Summary of Contents for Airzone VAF AZX6QADAPT Series
- Page 1 Installation Manual...
-
Page 3: Table Of Contents
Table of contents PRECAUTIONS Y ENVIRONMENTAL POLICY ___________________________________________________ 7 > Precautions ________________________________________________________________________________ 7 > Environmental policy ____________________________________________________________________ 7 GENERAL REQUIREMENTS _______________________________________________________________________ 8 INTRODUCTION ______________________________________________________________________________________ 10 SYSTEM INSTALLATION____________________________________________________________________________ 11 SYSTEM ELEMENTS ________________________________________________________________________________ 13 > Main control board with communication (AZVAFCBxxxx) _______________________ 13 >... - Page 4 5-Relay Fancoil control gateway (AZVAFGTF5R) __________________________________ 35 > Description ___________________________________________________________________________ 35 > Assembly _____________________________________________________________________________ 35 > Connection ___________________________________________________________________________ 35 > Webserver Airzone Cloud ______________________________________________________________ 37 > Description ___________________________________________________________________________ 37 > Assembly _____________________________________________________________________________ 38 > Connection ___________________________________________________________________________ 38 > Configuration ________________________________________________________________________ 40 >...
- Page 5 USER AND ZONE SETTINGS _______________________________________________________________________ 51 ADVANCED SETTINGS ______________________________________________________________________________ 51 > Airzone Blueface Zero thermostat ____________________________________________________ 51 > Airzone Think thermostat ______________________________________________________________ 51 > Airzone Cloud _____________________________________________________________________________ 51 > System parameters ______________________________________________________________________ 52 > Zone parameters _________________________________________________________________________ 56 INCIDENCES __________________________________________________________________________________________ 58 >...
-
Page 7: Precautions Y Environmental Policy
Precautions y environmental policy PRECAUTIONS For your security and to protect the devices, follow these instructions: • Do not manipulate the system with wet or damp hands. • Make all connections or disconnections with the HVAC system unpowered. • Take care not to cause a short-circuit in any of the system connections. ENVIRONMENTAL POLICY •... -
Page 8: General Requirements
Connect all wiring securely. Loose wiring may cause overheating at the connection points and is a possible fire hazard. • Do not locate the Airzone communication bus close to power lines, fluorescent lights, actuators, etc. as this may cause interference in communications. •... - Page 9 • Once the Airzone system is configured, verify that the static pressure of the duct system complies with the air distribution network conditions where is installed (check the manufacturer’s manual of the unit if you need to modify this parameter).
-
Page 10: Introduction
Introduction Airzone systems enable the management of main and zone thermostats. Main thermostats enable operation or user mode and fan speed of the unit. • Blueface Zero main: “Operation mode”, “User mode” and “Speed” icons are shown in white color. -
Page 11: System Installation
◊ Zone and control modules connection with the Airzone VAF main control board. Connect the modules of the system to any of the 3 Airzone connection bus terminals. Use shielded twisted pair 4 wired cable: 2x0.22 mm + 2x0.5mm (AWG 23 –... - Page 12 Auxiliary heat and other peripherals. If your system includes auxiliary heat, connect the “Auxiliary heat” relays of the VAF main control board to the elements to control. Important: The Airzone system is not compatible with electric duct heaters, it may result in system malfunction and/or fire.
-
Page 13: System Elements
(AZX6GTCxxx) Gateway for the management of AC units compatible with Airzone control systems. Powered by the indoor unit. Assembly and connection on the AC unit bus of the Airzone devices. Product developed and tested in collaboration with the manufacturer. Functionalities: •... -
Page 14: Assembly
Power supply Airzone connection bus The Airzone connection bus allows you to connect all the internal elements independent of the main control board and can control up to 10 zones. The elements that can be connected to this bus are: •... - Page 15 The automation bus allows several systems to be interconnected in order to manage all of them, using the control peripherals offered by Airzone or their integration into a higher-level control network. The elements that can be connected to this bus are: •...
- Page 16 Protection temperature probe Allows the return temperature of an AC unit to be measured by means of an external probe. The use of this probe is recommended when working with electromechanical or NON Inverter units, where the return temperature of the AC unit must be controlled. Auxiliary heat outputs If the system includes auxiliary heat, connect the “Auxiliary heat”...
-
Page 17: Wired/Wireless Intelligent Round Damper
Damper with actuator of 6, 8, 10, 12 or 14 inch diameter. Powered with 12 VDC by the zone module. Wired/Wireless damper zone module Local control module for controlling the operation of the damper. Wired/wireless communication with zone thermostat. Powered through system Airzone connection bus. Functionalities: • Detection of open window input. -
Page 18: Connection
Connection Nº Description Remote temperature probe connector Motorized damper connector Airzone connection bus Thermostat connection (only wired module) Occupancy contact input Window contact input Note: Use a shielded twisted pair to connect the window contact. Remote temperature probe connector Allows you to connect a probe (AZX6SONDPROTECT) for remote or distributed temperature reading, depending on how the module is configured: •... - Page 19 Airzone connection bus The intelligent motorized damper is a device that is connected to the Airzone connection bus of the main control board through the zone module. To connect the bus, there is a 5-pin terminal. Use shielded twisted pair 4 wired cable: 2x0.22 mm + 2x0.5 mm...
-
Page 20: Airflow Regulation
Inputs The module has inputs to control the zone based on the occupancy or if there are open windows. • Control by occupancy. When the occupancy sensor connected to the module indicates that the zone is unoccupied, the system waits for 5 minutes to confirm it is actually empty. After this period of time, the zone is set to “Timer mode”... -
Page 21: Wired/Wireless Only Radiant Zone Module
Wireless only radiant zone module (AZVAFZMRADR) For further information, see the technical datasheet. Description Local control module for controlling radiant elements. Wired/wireless communication with zone thermostat. Powered through system Airzone connection bus. Functionalities: • Detection of open window input. • Detection of occupancy input. -
Page 22: Connection
Airzone connection bus The only radiant zone module is a device that is connected to the Airzone connection bus of the main control board. To connect the bus, there is a 5-pin terminal. Use shielded twisted pair 4 wired cable: 2x0.22 mm + 2x0.5 mm... - Page 23 Thermostat connection (only wired module) To connect the wired thermostat, there is a 4-pin terminal. Use shielded twisted pair 4 wired cable: 2x0.22 mm + 2x0.5 mm (AWG 23 – 2 wired + AWG 20 – 2 wired). Fix the wires with the screws on the terminal, following the color code.
-
Page 24: Wired/Wireless Zone Module With Communication
For further information, see the technical datasheet. Description Module for controlling individual direct expansion units through communication gateway. Wired/wireless communications with zone thermostat. Powered through system Airzone connection bus. Mounted on DIN rail or on wall. Functionalities: • Detection of open window input. - Page 25 Note: If a temperature probe is installed in one zone, it is not possible to read or control the humidity of that zone. Airzone connection bus The zone module is a device that is connected to the Airzone connection bus of the main control board. To connect the bus, there is a 5-pin terminal. Use shielded twisted pair 4 wired cable: 2x0.22 mm...
- Page 26 Thermostat connection (only wired module) To connect the wired thermostat, there is a 4-pin terminal. Use shielded twisted pair 4 wired cable: 2x0.22 mm + 2x0.5 mm (AWG 23 – 2 wired + AWG 20 – 2 wired). Fix the wires with the screws on the terminal, following the color code.
-
Page 27: Relay Radiant Heat Control Module (Azvaf5Outputs)
For further information, see the technical datasheet. Description Control module of radiant heat for heating stages. Communications via Airzone connection bus of main control board. Powered by main control board. Mounted on DIN rail. Functionalities: • Control up to 5 heating elements by means of dry contact relays. - Page 28 6-10. Airzone connection bus The relay radiant heat control module is a device that is connected to the Airzone connection bus of the main control board. To connect the bus, there is a 4-pin terminal. Use shielded twisted pair 4 wired cable: 2x0.22 mm...
-
Page 29: Wired Thermostats
Description Blueface Zero principal thermostat Color graphic interface with capacitive screen and finished in steel and glass, for controlling zones in Airzone systems. Wired communication. Powered by zone module. Available in white or black. Functionalities: • 3 languages available (Spanish, English and French). -
Page 30: Assembly
Assembly Airzone wired thermostats are surface mounted on a support. Remember that the maximum recommended distance for this device is 40 m (131 ft). For wall mounting, follow these steps: • Separate the back part of the thermostat and make all the connections. -
Page 31: Wireless Thermostats
Description Think thermostat Graphic interface with low-energy e-ink screen, capacitive buttons and finished in steel and glass, for controlling zones in Airzone systems. Wireless communications. Powered by button battery CR2450. Available in white or black. Functionalities: • 3 languages available (Spanish, English and French). -
Page 32: Assembly
Assembly Airzone wireless thermostats are surface mounted on a support. Remember that the maximum recommended distance for this device is 10 m (33 ft). For wall mounting, follow these steps: • Separate the back part of the thermostat and insert the CR2450 button battery. -
Page 33: Fancoil Control Gateway (Azvafgtf10)
0-10 V FANCOIL CONTROL GATEWAY (AZVAFGTF10) For further information, see the technical datasheet. Description Control gateway of air-to-water zoning units. Fan control through 0-10 V output and opening- closing electrovalves. Compatible with 2 and 4-pipe installations. Externally powered at 110/230 VAC. - Page 34 Power supply It is connected through a 3-pin terminal. Use 3x1.5 mm (AWG 15 – 3 wired) cable. Fix the wires with the screws on the terminal, following the color code. Important: The connection to the external power supply must include a main switch or other method of disconnection that includes a constant separation for all polarities, in accordance with appropriate local and national regulations.
-
Page 35: 5-Relay Fancoil Control Gateway (Azvafgtf5R)
5-RELAY FANCOIL CONTROL GATEWAY (AZVAFGTF5R) For further information, see the technical datasheet. Description Control gateway of air-to-water zoning units. Control up to three fan-speeds and opening- closing electrovalves. Compatible with 2 and 4-pipe installations. Externally powered at 110/230 VAC. Mounted on DIN rail or on wall. Functionalities: •... - Page 36 Power supply It is connected through a 3-pin terminal. Use 3x1.5 mm (AWG 15 – 3 wired) cable. Fix the wires with the screws on the terminal, following the color code. Important: The connection to the external power supply must include a main switch or other method of disconnection that includes a constant separation for all polarities, in accordance with appropriate local and national regulations.
-
Page 37: Webserver Airzone Cloud
Description Webserver Airzone Cloud Wi-Fi Dual 2.4-5G Webserver for controlling Airzone systems through Airzone Cloud platform. Accessible through browser or App (available for IOS and Android). Wi-Fi connection. Powered through domotic bus of main control borad. Functionalities: •... -
Page 38: Assembly
Assembly Webserver Airzone Cloud Wi-Fi Dual 2.4-5G This device is integrated into the main control board automation bus. There is one 5-pin terminal. Disconnect it and fit the connector. Webserver HUB Airzone Cloud Dual 2.4-5G/Ethernet This device is mounted on DIN rail or on wall. It must be placed and mounted in accordance with the current electrotechnical regulations. - Page 39 Note: Remember that, for this module to work properly, all the main control boards in the installation must be addressed (see section Advanced settings) Webserver HUB Airzone Cloud Dual 2.4-5G/Ethernet Nº Description Ethernet Integration port...
-
Page 40: Configuration
2x0.22 mm (AWG 23 – 2 wired). Fix the wires with the screws on the terminal, following the color code. Configuration Webserver Airzone Cloud Wi-Fi Dual 2.4-5G To configure the device, follow the steps described in the Installation Manual. Webserver HUB Airzone Cloud Dual 2.4-5G/Ethernet... -
Page 41: Temperature Probe In Sheath (Azx6Sondprotec)
TEMPERATURE PROBE IN SHEATH (AZX6SONDPROTEC) For further information, see the technical datasheet. Description Temperature probe in metal sheath. Functionalities: • Protection probe for return water to boiler. • Configurable as remote or distributed probe. Connection The probe is installed in the temperature probe connector (AI1) of the main control board. -
Page 42: Power Supply (Azx6Power)
Blueface Zero. These values can be altered depending on the separation distance among them. Connection The 12V power supply is a device that is connected to the Airzone connection bus of the main control board. Use shielded twisted pair 4 wired cable: 2x0.22 mm + 2x0.5 mm... - Page 43 Connection of up to 10 modules without Blueface Zero Note: Do not connect the “-” pole to the “+” terminal. It may damage the device.
-
Page 44: Checking The Installation
Data reception from automation bus Blinking Green Data transmission to automation bus Blinking Main control board activity Blinking Green Data transmission to Airzone connection bus Blinking Data reception from Airzone connection bus Blinking Green stage auxiliary heat activated Switches Green... -
Page 45: Initial Setup
Initial setup Once the installation has been installed and all the elements are correctly connected, power the system for it setup. Follow the steps described in the following sections to configure all thermostats. Important: Before performing the initial setup of the system, configure firstly the secondary zones. - Page 46 • Start the radio channel search. To do so, touch the logo displayed on the thermostat. • The thermostat will display the different wireless zone modules found, with the signal level of each one of them. Select the wanted module and press “Check”, the selected module will begin to “beep”...
-
Page 47: Blueface Zero
Select the type of unit installed for each stage: • Air: Direct expansion or water Fancoil unit. • Radiant: Electric, water or air supply unit. Main ID Only if the thermostat has been configured as “Zone” previously. Select the ID of the thermostat configured as “Main” in step 6. The main thermostat will set the operation mode of the zone thermostat. -
Page 48: Think
Think Important: Use to confirm and to return in case you are in submenus. -
Page 49: Lite Thermostats
LITE THERMOSTATS To configure a Lite thermostat, follow these steps: Wired Lite thermostat • Connect the thermostat. • Press the LED to confirm the association. • The zone ID associated to the thermostat is the lowest available ID number. • If the association is successful, the LED will flash green 5 times. -
Page 50: Checking The Initial Setup
CHECKING THE INITIAL SETUP Check the following aspects: AC unit-system communication: Set the Airzone system to an operation mode other than Stop and turn on the zone to generate demand. Verify that the mode imposed on the main thermostat appears on the indoor unit thermostat and that the set point temperature changes on the same. -
Page 51: User And Zone Settings
Press and hold AIRZONE THINK THERMOSTAT Press once Press and hold Press and hold AIRZONE CLOUD Advanced system configuration can be performed from the Airzone Cloud application (see Airtools section of the Digital Support). The following parameters can be configured: •... -
Page 52: System Parameters
When the zone is Off, the damper shuts completely. Note: Changing this parameter affects all motorized dampers in the installation. Parameter not available in Airzone Think thermostat. Parameters not available in Airzone Blueface Zero and Think thermostats. - Page 53 Values: Off and 1.5 to 4 ºC / 3 to 8 ºF, in increments of 0.5 ºC / 1 ºF (by default, Off). Parameters not available in Airzone Blueface Zero and Think thermostats.
- Page 54 Parameter not available in Airzone Think thermostat. Parameters not available in Airzone Blueface Zero and Think thermostats.
- Page 55 To reconfigure the thermostats, go to the Initial setup section. Wait 60 seconds until the system restarts before connecting again. Parameter not available in Airzone Think thermostat. Parameters not available in Airzone Blueface Zero and Think thermostats.
-
Page 56: Zone Parameters
Operation mode (only if this is the master thermostat) If a Lite thermostat is configured in basic mode, no type of control will be permitted, acting only as a zone temperature probe. You can control this zone from Blueface Zero or Airzone Cloud. - Page 57 • Reset thermostat. (Not available in remote zones) This allows you to reset the thermostat by returning to the initial settings menu. Parameter not available in Airzone Think thermostat. Parameter not available in Airzone Blueface Zero thermostat.
-
Page 58: Incidences
Incidences WARNINGS In the case of Airzone Blueface Zero and Think thermostats, a warning will be displayed on the screensaver. Anti-freezing . This is displayed if the function is enabled. Unoccupied override. Displayed in case of interacting with the zone when the user mode is set to “Unoccupied”. -
Page 59: Errors
ERRORS In the case of Airzone Blueface Zero and Think thermostats, an error message will be displayed on the screensaver, on the main screen and on “User settings - Information” menu. In the case of any of the following errors, please contact your installer: Communication errors 1. - Page 60 Error 1. Thermostat (Blueface Zero) - Module This incidence does not allow the zone to be controlled. To solve this incidence, refer to the steps below: Connections: Check the polarity of the connectors of the module and the thermostat. Wiring: Check that the voltage between the poles (W/-) and (Y/-) is about 0.65 VDC. Wiring: Verify that the connection bus module-thermostat is not next to low-voltage wiring.
- Page 61 Error 1. Thermostat (Think) - Module This incidence does not allow the zone to be controlled. To solve this incidence, refer to the steps below: Thermostat status: Check the thermostat’s signal range from the module by checking the “Information” parameter (see the section System advanced settings - System parameters) or by bringing the thermostat closer to the module, if it re-establishes communication, it will be necessary to relocate the thermostat because it was not in signal range.
- Page 62 Main control board status: Check that the power supply is correct. Main control board status: Check the correct operation of the Airzone connection bus LED (D4 and D5). Connections: Verify the polarity of the main control board and thermostat connectors.
- Page 63 The system detects that the motorized element has an abnormality and blocks the opening- closing movement. Disconnect and connect the Airzone connection bus terminal and check if the error disappears, otherwise, proceed to the replacement of the device or sent it for repair.
- Page 64 The zone loses the room temperature measurement, leaving the zone unable to generate demand. In the event of such an incident, the device must be replaced or sent for repair. Error 9. Gateway - Airzone system The system loses communication with the gateway and therefore with the AC unit. The system will open all its zones and disable control from the system’s thermostats, thus allowing the AC...
- Page 65 Indoor unit: Check whether the AC unit operates properly independently of the system. To do so, disconnect the AC unit from the Airzone system and activate the unit from the AC unit’s thermostat. Connections: Check that the polarity of the connections to the gateway and indoor unit is correct.
- Page 66 Module status: Check that the power supply is correct. Module and main control board status: Correct operation of the Airzone connection bus LED (D3 y D4). Connections: Check that the polarity of the connections of the module and the main control board is correct.
- Page 67 Error 17. Lutron gateway - Main control board Webserver configured as Lutron The system loses communication with the Webserver. Check that the Webserver is properly connected to the main control board’s automation bus.
-
Page 68: Navigation Trees
Navigation trees AIRZONE BLUEFACE ZERO THERMOSTAT Screensaver Time and date Relative humidity Current zone Operation mode Room temperature Weather information Press any place on the screen Main screen Operation User mode Airflow control Current zone mode • • • Cool... -
Page 69: Airzone Think Thermostat
AIRZONE THINK THERMOSTAT to confirm and to return in case you are in submenus. Screensaver Max. /Min. temperature Weather information Zone status Airzone Press Main screen Informative icons Capacitive icons Operation Configuration User mode Airflow control mode menu • •... - Page 70 airzonecontrol.com Marie Curie, 21 29590 Málaga Spain v 100...
