Installation and Maintenance Instructions
WLC80BLTC
WLC80BRTC
technical data
Working Pressure Range
Maximum Static Pressure
Maximum Working
Temperature
Inlet Connection
Flow Rate
Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500.
Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions.
Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government
regulations when considering the choice of, and the installation of these products.
This product must be installed and commissioned by a qualified plumber.
For use with potable water only.
NOTE: Enware Australia advises:
1. Due to ongoing Research and Development, specifications may change without notice.
2. Component specifications may change on some export models.
I00468_19 Jun 2024
1300 369 273 | info@enware.com.au | enware.com.au
Leva 80mm Bib Tap - 15mm
®
Min 50 kPa
Max 500 kPa
800 kPa
85°C (Ceramic disc)
1/2" BSP
5 L/min (WELS 5 Star)
4 L/min (WELS 6 Star)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Watts ENWARE Wellbeing WLC80BLTC
Summary of Contents for Watts ENWARE Wellbeing WLC80BLTC
- Page 1 Wellbeing Leva 80mm Bib Tap - 15mm ® Female Installation and Maintenance Instructions WLC80BLTC WLC80BRTC technical data Working Pressure Range Min 50 kPa Max 500 kPa Maximum Static Pressure 800 kPa Maximum Working 85°C (Ceramic disc) Temperature Inlet Connection 1/2” BSP Flow Rate 5 L/min (WELS 5 Star) 4 L/min (WELS 6 Star)
- Page 2 Handle plug Tooth washer M5 Grub screw M5 Spline adaptor Lever handle 80mm SBA spindle Colour indicator ring 10 Frame (red/ yellow/ blue) 11 Aerator laminar insert 5 Screw M5x20 lpm TT Cache orange Washer (Nylon) 12 Aerator key TT Cahce www.enware.com.au Page 2 ©...
- Page 3 installation • All supply lines must be flushed thoroughly to remove debris prior to the installation of this product. Strainers (40 mesh) are recommended if debris is an ongoing problem. • A pressure reduction valve may be required to comply with the recommended maximum supply pressure and/or 1/2”...
- Page 4 5. Fit colour indicator ring [4] onto lever handle [3]. To do this, place an indicator ring on flat surface with the rebated Hot / Warm Cold edge facing up. Press the lever handle down onto the indicator ring evenly until it clips into place. SEE IMAGE 05-1 If an indicator ring needs to be removed, place lever handle on a flat surface and apply pressure to the side of the indicator ring, until the ring pops off.
- Page 5 maintenance CLEAN AERATOR Clean aerator [11] periodically. Unscrew the aerator using aerator key [12], and rinse it under running water. CLEANING Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals.
- Page 6 spare parts DESCRIPTION PART CODE Lever handle 80mm WLCS-80378 Parts: [1] [2] [3] [4-red,yellow,blue] [5] [6] [7] [8] Colour indicators Parts: [4-red,yellow,blue] LEV398 SBA hot - RTC (Clockwise to close) Parts: [5] [6] [7] [9] WLCS380RTC SBA cold - LTC (Anti-clockwise to close) Parts: [5] [6] [7] [9] WLCS380LTC Spline adaptor Parts: [8] LEVSQHEX...
- Page 7 dimensions 1/2" (BSP) INTERNAL 5/8" (BSP) 100 - 116 Clockwise to Close Anti-Clockwise to Close All measurements are in millimetres. www.enware.com.au Page 7 © Enware Pty Ltd...
- Page 8 - WATTS AUSTRALIA EFFECTIVE FROM 20 November 2023 3. Our responsibilities This Warranty Statement applies to products supplied by Australian Valve (a) In the event that the Supplier is reasonably satisfied that there is a Group Pty Ltd (ACN 068 227 270) (AVG) or Enware Pty Ltd (ACN 662...
