Product End-of-Life Disassembly Instructions
Product Category: Notebooks and Tablet PCs
Marketing Name / Model
[List multiple models if applicable.]
HP EliteBook 830 G5 Notebook PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
Components, parts and materials containing
EL-MF877-00
Template Revision B
Notes
With a surface greater than 10 sq cm
All types including standard alkaline and lithium coin
or button style batteries
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
Includes background illuminated displays with gas
discharge lamps
power cord
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
PSG instructions for this template are available at
EL-MF877-01
Quantity
of items
included
in product
2
2
0
1
0
0
0
1
0
0
0
0
0
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HP EliteBook 830 G5
Summary of Contents for HP EliteBook 830 G5
- Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
- Page 2 refractory ceramic fibers Components, parts and materials containing radioactive substances 2.0 Tools Required List the type and size of the tools that would typically be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description Tool Size (if applicable)
- Page 3 MANUFACTURING PROCESS INSTRUCTIONS MECHANICAL ASSEMBLY MODEL : Skyfire/Longhaul Skyfire/Longhaul DIS ASS'Y SOP Sub-assembly name: Skyfire/Longhaul DIS ASS'Y SOP Document No.: Vick Weng Written by: Revision: 1.00 Date: 2017/12/18 Page: 1 of 29 A.Current station version list: Station VersionStation VersionStation VersionStation VersionStation V ersion StationVersion 1.00 1.00 1.00...
- Page 4 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 1(1/1) Station : Loosen screw Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen screw*8. Torsion：2.0 ± 0.2 kgf．cm Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver...
- Page 5 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 2(1/1) Station : Disassemble bottom case Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Use plastic stick to disassemble bottom case. Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Plastic stick...
- Page 6 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 3(1/1) Station : Disassemble Battery Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disconnect battery cable(Fig.1). 2.Loosen Battery screw*5(T8)(Fig.2). Torsion：2.0 ± 0.2 kgf．cm 3.Remove battery(Fig.3). Fig.1 Fig.2 Fig.3 Notes : If finding anything uncommon, notice foreman or assistant at once.
- Page 7 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 4(1/1) Station : Disassemble DDR/NFC Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble DDR(Fig.1). 2.Disassemble NFC FFC, NFC module, NFC antenna(Fig.2). Fig.1 Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Auditor ：...
- Page 8 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 5(1/1) Station : Disassemble WWAN/WLAN/SSD Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble WLAN/WWAN cable from module & hook(Fig.1). 2.Loosen WLAN/WWAN/SSD screw, then remove WLAN/WWAN/SSD module from M/B(Fig.2). ...
- Page 9 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 6(1/1) Station : Name Ver. : 1.00 Date : 2017/12/18 Disassemble Power FFC FAN/LVDS CABLE Step： 1.Disassemble Power FFC/FAN cable(Fig.1/Fig.2) 2.Disassemble LVDS/Camera cable, then remove cable from hook(Fig.3~5). Fig.3 Fig.1 Fig.4 Fig.2...
- Page 10 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 7(1/1) Station : Loosen hinge screw Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen hinge screw*5(M2.5*4.0)(Fig.1/Fig.2). Torsion：3.0 ± 0.2 kgf．cm 2.Open base unit to 90 degree, then separate panel set &...
- Page 11 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 8(1/1) Station : Loosen K/B screw Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen K/B screw*2(M2.0*3.0). Torsion：1.5 ± 0.2 kgf．cm Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver...
- Page 12 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 9(1/1) Station : Disassemble K/B Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Use plastic stick to push the K/B(Fig.1). 2.Turn the computer over, then disassemble K/B(Fig.2). 3.Disassemble K/B FFC, backlight FPC, PS FFC, then remove K/B(Fig.3~5).
- Page 13 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 10(1/1) Station : Loosen screw Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen screw*4(M2.0*3.0). Torsion：1.5 ± 0.2 kgf．cm Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver...
- Page 14 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 11(1/1) Station : Disassemble Thermal & FAN Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Turn the computer over. 2.Loosen thermal/FAN screw*7. Torsion：1.5 ± 0.2 kgf．cm 3.Remove thermal & FAN module. Pick up Thermal position Notes : If finding anything uncommon, notice foreman or assistant at once.
- Page 15 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 12(1/1) Station : Disassemble USB Bracket & FFC Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen USB bracket screw*1(tM2.0*3.0)(Fig.1). Torsion：1.5 ± 0.2 kgf．cm 2.Disassemble USB bracket(Fig.1). 3.Disassemble MSC FFC/Finger Pinter FPC(Fig.2/Fig.3). Fig.1 Fig.2 Fig.3...
- Page 16 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 13(1/1) Station : Loosen RJ45 screw Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen RJ45 screw*5(M2.0*4.0). Torsion：1.5 ± 0.2 kgf．cm Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver...
- Page 17 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 14(1/1) Station : Disassemble RJ45 frame Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble RJ45 frame(Fig.1). 2.Disassemble speaker cable(Fig.2). 3.Disassemble sub battery cable, then disassemble sub battery from hook(Fig.3). Fig.3 Fig.2 Fig.1...
- Page 18 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 15(1/1) Station : Loosen M/B screw Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen M/B screw*6(M2.0*3.0). Torsion：1.5 ± 0.2 kgf．cm Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver...
- Page 19 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 16(1/1) Station : Disassemble M/B Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble Smart Card FFC(Fig.1). 2.Disassemble M/B from top case(Fig.2). Fig.1 Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Auditor ：...
- Page 20 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 17(1/1) Station : Disassemble Finger Printer Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen Finger Pinter screw*1(M2.0*2.0). Torsion：1.5 ± 0.2 kgf．cm 2.Disassemble finger printer or dummy from top case. Notes : If finding anything uncommon, notice foreman or assistant at once.
- Page 21 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 18(1/1) Station : Disassemble SMC/B Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen SMC screw*3(M2.0*2.0), then remove SMC/B from top case(Fig.1). Torsion：1.5 ± 0.2 kgf．cm Dummy Smartcard loosen screw*1(Fig.2) Smartcard Fig.1 dummy Smartcard...
- Page 22 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 19(1/1) Station : Disassemble Speaker Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble pick button FPC(Fig.1). 2.Loosen speaker screw*2(M2.0*2.0), then remove speaker from top case(Fig.2). Torsion：1.5 ± 0.2 kgf．cm Fig.1 Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once.
- Page 23 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 20(1/1) Station : Disassemble Power/B, Pick button Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen Power/B screw*1(M2.0*3.0), then disassemble Power/B from top case(Fig.1/Fig.2). 2.Loosen pick button screw*4(M2.0*3.0), then disassemble pick button from top case(Fig.3).
- Page 24 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 21(1/1) Station : Disassemble Click pad Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen screw*5(M2.0*2.0), then remove click pad. Torsion：1.5 ± 0.2 kgf．cm Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver...
- Page 25 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 22(1/1) Station : Disassemble Hinge cap Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble hinge cap in order. Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Auditor ：...
- Page 26 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 23(1/1) Station : Disassemble Bezel Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble bezel in order. Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Auditor ：...
- Page 27 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 24(1/1) Station : Loosen LCM screw Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen LCM screw*4(M2.0*2.0), then remove LCM from rear case. Torsion：2.0 ± 0.2 kgf．cm Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Electric cross screwdriver...
- Page 28 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 25(1/1) Station : Disassemble LCM Cable Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble LCM cable(Fig.1). 2.Disassemble camera cable from hook(Fig.2). Fig.1 Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Auditor ：...
- Page 29 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 26(1/1) Station : Disassemble Camera, ALS/B, MIC/B Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble camera cable from camera. 2.Disassemble camera, ALS/B, MIC/B. Notes : If finding anything uncommon, notice foreman or assistant at once. Holding fixture list (holding fixture standard) Holding fixture list (holding fixture standard) Auditor ：...
- Page 30 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 27(1/1) Station : Disassemble WLAN/WWAN cable Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Disassemble WLAN cable from hook, then remove antenna from rear case(Fig.1/Fig.2). 2.Disassemble WWAN cable from hook, then remove antenna from rear case(Fig.3/Fig.4).
- Page 31 Standard Operation Procedure Document No. : Skyfire Longhaul DIS ASS’Y SOP 28(1/1) Station : Disassemble Hinge Name Ver. : 1.00 Date : 2017/12/18 Step： 1.Loosen hinge screw*6(M2.5*10), then disassemble hinge from rear case. Torsion：3.0 ± 0.2 kgf．cm Fig.1 Fig.2 Notes : If finding anything uncommon, notice foreman or assistant at once.
