Summary of Contents for Siku 100 AC AS
- Page 1 AXIAL FAN 100 AC AS User’s manual...
- Page 2 The manual contains information about the purpose, technical details, operating principle, design, and installation of the 100 AC AS unit (-s) and all of its (their) modifications. Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
- Page 3 READ THE USER’S MANUAL CAREFULLY BEFORE PROCEEDING WITH INSTALLATION WORKS. COMPLIANCE WITH THE MANUAL REQUIREMENTS ENSURES RELIABLE OPERATION AND LONG SERVICE LIFE OF THE UNIT. KEEP THE USER’S MANUAL AVAILABLE AS LONG AS YOU USE THE UNIT. YOU MAY NEED TO RE- READ THE INFORMATION ON THE PRODUCT SERVICING.
- Page 4 of any foreign objects that can damage the impeller blades. While mounting the unit, avoid compression of the casing! Deformation of the casing may result in motor jam and excessive noise. Misuse of the unit and any unauthorised modifications are not allowed.
- Page 5 characteristics, design, or configuration of its products at any time in order to incorporate the latest technological developments. Never touch the unit with wet or damp hands. Never touch the unit when barefoot. This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for...
- Page 6 Ensure that the unit is switched off from the supply mains before removing the guard. THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE. DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.
- Page 7 DELIVERY SET - 1 pc. Screws with dowels - 4 pcs. Plastic screwdriver - 1 pc. (only for the models with a timer) User’s manual - 1 pc. Packing box - 1 pc. BRIEF DESCRIPTION The products described herein is an axial fan for exhaust ventilation of small to medium-sized premises heated during winter. The fan is designed for connection to 100 mm air ducts.
- Page 8 DESIGNATION KEY 100 AC AS Extra options: _: basic modification (turning on and off ) T1-i: turn-on delay timer, turn-off delay timer and interval timer TH: humidity sensor, turn-on and turn-off delay timer Motor type: _: single-speed Duo: two-speed motor...
- Page 9 FAN SETUP : to adjust the humidity set point turn the control knob H clockwise to increase and counter-clockwise to decrease the humidity sensor set point, adjustable from 60% up to 90%. : turning of the interval timer on and its adjustment is performed with the potentiometer T .
- Page 10 MAINTANANCE The fan maintenance periodicity is at least once per 6 months. Maintenance steps: • Cut off power supply to the fan and make that the power is disconnected (Fig. 17). • Take off the front panel and clean the fan with a soft dry cloth or a brush (Fig. 18). •...
- Page 11 MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/ EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
- Page 12 • Redesign or engineering changes to the unit. • Replacement and use of any assemblies, parts and components not approved by the manufacturer. • Unit misuse. • Violation of the unit installation regulations by the user. • Violation of the unit control regulations by the user. •...
- Page 13 ø99...
- Page 15 100 AC AS 100 AC AS T1-i Fan does not run Activation of the interval S switch is ON timer (6/12/24 hours) Activation of the turn-on Fan runs delay timer for 60 seconds Activation of the turn-off delay timer (2…30 minutes)
- Page 16 100 AC AS Duo T Off 6/12/24 hours Interval timer Fan runs with Fan does not run low speed Activation of the interval S switch is ON S switch is ON timer (6/12/24 hours) Activation of the turn-on delay Activation of the turn-on...
- Page 17 100 AC AS TH Fan does not run S switch is ON Activation of the turn-on delay timer for 60 seconds Switch S is OFF during Humidity is above countdown of the turn-on set point delay timer Fan runs S switch is OFF...
- Page 18 100 AC AS Duo TH Fan does not run S switch is ON Activation of the turn-on delay timer for 60 seconds Switch S is OFF during Humidity is above countdown of the turn-on set point delay timer Fan runs with...
- Page 23 Approval mark Sold (name and stamp of the seller) Manufacturing date Sales date...
- Page 24 Acceptance certificate T1-i 100 AC AS Duo The fan is recognized as serviceable. SIKU164EN-04...
