Summary of Contents for TP-Link TL-ST1008F
- Page 1 Machine Translated by Google Enterprise Networking Solution Installation Manual Full 10 Gigabit Ethernet switch TL-ST1008F TL-ST1005 TL-ST1008...
- Page 2 Machine Translated by Google statement Copyright © 2022 Pulian Technology Co., Ltd. All rights reserved. Without the express written permission of Pulian Technology Co., Ltd., no unit or individual may copy, copy, copy or translate part or all of the contents of this manual without authorization, and no part or all of the contents of this manual may be reproduced in any way (electronically, photocopied, recorded, etc.) for profit.
- Page 3 Introduces the installation and startup process of a full 10 Gigabit Ethernet switch If the problem still cannot be solved through the guidance of relevant documents, please contact the TP-LINK technical support service center directly and we will provide you with technical support services.
- Page 4 Machine Translated by Google Reading object This manual is suitable for the following people: Network Engineer network administrator Agreement This manual uses the following eye-catching symbols to indicate the points that should be paid attention to during operation. The meanings of these symbols are as follows: Down: This icon indicates a warning that requires attention.
- Page 5 Machine Translated by Google Table of contents Chapter 1 Product Introduction—————————————— 01 1.1 Product Introduction............01 1.2 Product appearance............01 Chapter 2 Product Installation—————————————— 05 2.1 List of items............05 2.2 Installation precautions..........05 2.3 Preparation of installation tools.............07 2.4 Product installation..........
- Page 6 TL-ST1008F TL-ST1005 TL-ST1008 1.2 Product appearance ÿ TL-ST1008F The front panel of TL-ST1008F is shown in Figure 1-1. 1 power indicator light Figure 1-1TL-ST1008F front panel diagram The rear panel of TL-ST1008F is shown in Figure 1-2. Link/Act indicator 3 system mode selection switch...
- Page 7 Gigabit optical/electrical module. Please note: The power consumption of the 10 Gigabit electrical module (TL-SM510U) is greater than that of conventional optical modules. A TL-ST1008F can only be connected to a maximum of 2 10 Gigabit electrical modules at the same time. It is recommended not to connect them side by side to avoid overheating at the access location. If it is raised too high, it will affect module performance.
- Page 8 Machine Translated by Google Full 10 Gigabit Ethernet Switch Installation Manual The rear panel of TL-ST1005 is shown in Figure 1-4. Anti-theft keyhole Power interface Figure 1-4 Schematic diagram of the rear panel of TL-ST1005 1 Link/Act indicator Indicator light working status working instructions The left light is solid green and the corresponding port connection rate is 10Gbps The left light is solid orange and the corresponding port connection rate is 5Gbps The right light is solid green and the corresponding port connection rate is 2.5Gbps...
- Page 9 Machine Translated by Google Full 10 Gigabit Ethernet Switch Installation Manual The rear panel of TL-ST1008 is shown in Figure 1-6. Anti-theft keyhole 4 power interface 5 ground posts Figure 1-6 Schematic diagram of the rear panel of TL-ST1008 1 Link/Act indicator Indicator light working status working instructions The left light is solid green and the corresponding port connection rate is 10Gbps The left light is solid orange and the corresponding port connection rate is 5Gbps...
- Page 10 Warranty Card Note: ÿ The 4 foot pads provided with TL-ST1008F have been pasted on the bottom of the switch before leaving the factory. ÿ TL-ST1008 supports rack installation. In addition to foot pads, it also provides L-shaped brackets and screws. ÿ If you find that there is a shortage or damage to parts, please contact your local dealer in time.
- Page 11 Machine Translated by Google Full 10 Gigabit Ethernet Switch Installation Manual ÿ Installation environment precautions temperature humidity To ensure long-term stable operation of the switch and extend its service life, please maintain a certain temperature and humidity in the environment. Too high or too low ambient humidity can easily cause leakage, deformation and even corrosion of metal parts in insulating materials.
- Page 12 Machine Translated by Google Full 10 Gigabit Ethernet Switch Installation Manual Lightning protection requirements When a lightning strike occurs, a strong current will be generated in an instant, and the air on the discharge path will be instantly heated to 20,000 degrees Celsius. The instantaneous high current is enough to cause fatal damage to electronic equipment.
- Page 13 Machine Translated by Google Full 10 Gigabit Ethernet Switch Installation Manual 2. Peel off the plastic protective paper of the four pads one by one, and stick them in the circular grooves located at the four corners of the bottom of the case; as shown in Figure 2-1 shown;...
- Page 14 Excellent grounding method. ÿ If you install TP-LINK enterprise-grade steel shell products in the computer room, and there is a dedicated grounding bar in the computer room, you should first consider using Use a ground wire to connect the device to the ground bar, as shown in Figure 2-4.
- Page 15 Note: ÿ Please use 10 Gigabit SFP+ optical module, TP-LINK 10 Gigabit optical module product is recommended, see Appendix B for details; ÿ Please select the optical fiber line according to the module type, multi-mode module corresponds to multi-mode optical fiber, and single-mode module corresponds to single-mode optical fiber ; ÿ Excessive bending of the optical fiber is not allowed, and its radius of curvature should not be less than 10cm;...
- Page 16 Full 10 Gigabit Ethernet Switch Installation Manual 3.3 Connect the power supply TL-ST1008F and TL-ST1005 use 12VDC 2A DC power supply: 1. Check that the selected power supply is consistent with the power requirements marked on the switch; 2. Use the original power adapter of the switch to connect the switch to the power socket, as shown in Figure 3-3.
- Page 17 ÿ Check the status of the Power indicator on the switch panel. If it is on, it means the power supply is connected correctly; if it is off, it means the power supply is abnormal; ÿ The Link/Act indicators of TL-ST1008F will all flash and then go out, indicating that the system has been initialized and can Normal use.
- Page 18 Machine Translated by Google Full 10 Gigabit Ethernet Switch Installation Manual Appendix A Technical Parameters and Specifications TL-ST1008F TL-ST1005 TL-ST1008 Product number IEEE 802.3 Ethernet Media Access Control (MAC) Protocol IEEE 802.3: Ethernet Media Access Control (MAC) Protocol IEEE 802.3u:100BASE-X Fast EthernetIEEE IEEE 802.3z: 1000BASE-X Gigabit Ethernet (fiber optic) IEEE...
- Page 19 The block determines the maximum transmission distance of the signal and the type of fiber used. The 10G SFP+ port of the TP-LINK switch is compatible with single-mode and multi-mode optical modules. It is recommended to use TP-LINK's 10G optical modules, such as TL-SM512LM-300m and TL-SM512LS-10KM.
- Page 20 Company address: 1st floor, 3-5 floors in the south section of Building 24, Industrial Factory Building 24, Shennan Road Science and Technology Park, Nanshan District, Shenzhen City, 1-4 floors in the north section of Building 28 Company website: http://www.tp-link.com.cn Technical support hotline: 400-8863-400 E-mail: smb@tp-link.com.cn...
