- Page 1 Machine Translated by Google Enterprise Networking Solution Installation Manual Fully 10 Gigabit Layer 3 managed switch TL-ST5008 TL-ST5012 TL-ST5012F TL-ST5016F...
- Page 2 Machine Translated by Google statement Copyright © 2024 Pulian Technology Co., Ltd. All rights reserved. Without the express written permission of Pulian Technology Co., Ltd., no unit or individual may copy, copy, copy or translate part or all of the contents of this manual without authorization, and no part or all of the contents of this manual may be reproduced in any way (electronically, photocopied, recorded, etc.) for profit.
- Page 3 Introduces how to take lightning protection measures during equipment installation to avoid equipment damage due to lightning strikes. If the problem still cannot be solved through the guidance of relevant documents, please contact TP-LINK technical support service directly. Center, we will provide you with technical support services.
- Page 4 Machine Translated by Google Appendix D: Product warranty card. Appendix E: Declaration of Toxic and Hazardous Substances Content. Note: ÿTo avoid possible equipment damage and personal injury before and during the installation of the equipment, please read the relevant contents of this manual carefully. Reading object This manual is suitable for the following people: Network Engineer...
-
Page 5: Table Of Contents
Machine Translated by Google Table of contents Chapter 1 Product Introduction—————————— 01 1.1 Product Introduction............01 1.2 Product appearance............01 Chapter 2 Product Installation—————————— 08 2.1 List of items............08 2.2 Installation Precautions..........08 2.3 Preparation of installation tools..........10 2.4 Product installation............10 Chapter 3 Hardware Connection——————————... -
Page 6: Chapter 1 Product Introduction
Product model Gigabit RJ45 port 10 Gigabit RJ45 port 10 Gigabit SFP+ port Full 10 Gigabit Layer 3 managed switch TL-ST5016F Full 10 Gigabit Layer 3 managed switch TL-ST5008 Full 10 Gigabit Layer 3 managed switch TL-ST5012 Full 10 Gigabit Layer 3 managed switch TL-ST5012F 1.2 Product appearance... - Page 7 Machine Translated by Google Layer 3 managed switch installation manual The front panel of TL-ST5012F is shown in the figure below. 1 mode switching button 2 indicator lights 1 Type-C Console port 16 10Gbps SFP+ ports 1 RJ45 Management port 6 1 USB port Figure 1-2TL-ST5012F front panel diagram 1 Mode switching button The...
- Page 8 Note: Due to differences in compatibility and drivers of USB devices from different manufacturers, TP-LINK does not guarantee that USB devices from all manufacturers can be used normally on the TL-ST5016F. If a USB device cannot be used normally, it is not a switch failure. In this case, please try to use a USB device from another manufacturer.
- Page 9 Note: Due to differences in compatibility and drivers of USB devices from different manufacturers, TP-LINK does not guarantee that USB devices from all manufacturers can be used normally on the TL-ST5012. If a USB device cannot be used normally, it is not a switch failure. In this case, please try to use a USB device from another manufacturer.
- Page 10 Machine Translated by Google Layer 3 managed switch installation manual The front panel of TL-ST5008 is shown in the figure below. 1 indicator light Mode switch 3 1 USB ports 4 8 10Gbps adaptive RJ45 ports 5 1 Type-C Console port...
- Page 11 Due to differences in compatibility and drivers of USB devices from different manufacturers, TP-LINK does not guarantee that USB devices from all manufacturers can be used normally on the TL-ST5008. If a USB device cannot be used normally, it is not a switch failure. In this case, please try to use a USB device from another manufacturer.
- Page 12 The rear panel of TL-ST5012 is shown in the figure below. 2 power sockets post 1 Lightning protection grounding Figure 1-7 Rear panel diagram The rear panel of TL-ST5008 is shown in the figure below. 3 anti-theft lock holes 1Lightning protection grounding post Power outlet Figure 1-8 Rear panel diagram 1Lightning protection terminal Please use yellow and green double-colored copper core wires for grounding to prevent lightning strikes.
-
Page 13: Chapter 2 Product Installation
Note: ÿ TL-ST5008/TL-ST5012/TL-ST5012F does not provide Console cable. ÿThe above diagram is for reference only, please refer to the actual product. ÿIf you find any shortage or damage of parts, please contact your local dealer in time. - Page 14 Machine Translated by Google Layer 3 managed switch installation manual temperature humidity To ensure long-term stable operation of the switch and extend its service life, please maintain a certain temperature and humidity in the environment. Too high or too low ambient humidity can easily cause leakage, deformation and even corrosion of metal parts in insulating materials.
-
Page 15: Preparation Of Installation Tools
Machine Translated by Google Layer 3 managed switch installation manual ÿ Rational wiring to avoid internal induction lightning; ÿ When wiring outdoors, it is recommended to use a signal lightning protector. Note: For detailed lightning protection measures, please refer to the "Lightning Protection Installation Manual". Installation table Whether the switch is installed in a rack or on another level bench, please note the following: ÿ... - Page 16 Machine Translated by Google Layer 3 managed switch installation manual 3. Turn the switch over and place it firmly on the table. Note: Leave a 5-10cm gap around the switch case to ensure heat dissipation and air circulation. Avoid placing other heavy objects on the surface of the switch. ÿ...
-
Page 17: Chapter 3 Hardware Connection
Machine Translated by Google Layer 3 managed switch installation manual Chapter 3 Hardware Connection 3.1 Connect the RJ45 port As shown in the figure below, connect the switch and the peer device through the RJ45 port. RJ45 port Crystal Head RJ45 port Figure 3-1 RJ45 port connection diagram 3.2 Connect the SFP+ port... -
Page 18: Connect The Power Cord
Machine Translated by Google Layer 3 managed switch installation manual Figure 3-3RJ45 Console port connection diagram The Type-C Console port connection diagram is as follows. Figure 3-4Type-C Console port connection diagram 3.4 Connect the power cord 1. Check that the selected power supply is consistent with the power requirements marked on the switch; 2. -
Page 19: Device Initialization
Machine Translated by Google Layer 3 managed switch installation manual 3.5 Device initialization After the switch is powered on, it will automatically initialize. At this time, the indicator light will appear as follows: ÿ Check the status of the PWR indicator light on the switch panel. If it is on, it means the power supply is connected correctly. If it is off, it means the power supply is abnormal. ÿ Check the status of the SYS indicator light on the switch panel. -
Page 20: Chapter 4 Configuration Guide
192.168.0.x ("x" is any value between 2-25 4, and cannot be 251) , the subnet mask is set to 255.255.255.0. ÿ The fixed IP of the service port of TL-ST5008/TL-ST5012/TL-ST5012F is 10.18.18.251. When the computer is connected to the switch service port, the computer IP address needs to be set to: 10.18.18.x ("x"... -
Page 21: Local Login
1. Refer to Chapter 3.3 Connecting the Console Port for instructions on connecting the console port of the switch to the computer. 2. If you use the Type-C Console port, you need to install the "TP-LINK USB serial port driver". - Page 22 Open the computer's terminal emulation program (such as the Hyperterminal program) and configure the following parameters: ÿ Baud rate: TL-ST5012/TL-ST5008 baud rate is 38400bps; TL-ST5016F baud rate is 115200bps ÿ Data bits: 8 bits ÿ Parity check: None ÿ Stop bit: 1 bit ÿ Data flow control: None 4.
-
Page 23: Remote Login
Machine Translated by Google Layer 3 managed switch installation manual 4.3 Remote login The CLI can be accessed by logging into the switch remotely using a telnet connection through the Ethernet port. To connect to the switch via telnet, please refer to the following steps: 1. -
Page 24: Cloud Management
Figure 4-10 Entering the cloud management configuration page Note: You can also download the TP-LINK Shangyun APP, identify the QR code on this interface, and configure it in the APP. This manual uses the Web interface as an example for explanation. - Page 25 Machine Translated by Google Layer 3 managed switch installation manual 3. Click Project Centralized Management > Device List > Add Device, enter the MAC address, device name, and user The name, password, group, and MAC address can be obtained by scanning the QR code on the product specification label, or you can query it through the switch web page.
-
Page 26: Appendix A Common Troubleshooting
Machine Translated by Google Layer 3 managed switch installation manual Appendix A Common Troubleshooting Problem 1. Forgot the switch username and password (how to restore factory settings). Please follow the steps below: 1. Connect the serial port of the configuration computer to the Console port of the switch, and open the successfully configured hypervisor. level terminal;... -
Page 27: Appendix B Technical Parameters And Specifications
Machine Translated by Google Layer 3 managed switch installation manual Appendix B Technical Parameters and Specifications TL-ST5012 Product number TL-ST5016F/TL-ST5012F Technical Standard IEEE 802.3: Ethernet Media Access Control (MAC) Protocol IEEE 802.3: Ethernet Media Access Control (MAC) Protocol IEEE 802.3z: 1000BASE-X Gigabit Ethernet (fiber) IEEE 802.3bz: IEEE 802.3u: 100BASE-TX Fast Ethernet IEEE 802.3ab: 1000BASE-T Gigabit Ethernet IEEE 802.3an: 10GBASE- 2.5G/5GBASE-T Ethernet IEEE 802.3ae: 10GBASE-... - Page 28 Machine Translated by Google Layer 3 managed switch installation manual TL-ST5008 Product number Technical Standard IEEE 802.3: Ethernet Media Access Control (MAC) Protocol IEEE 802.3u:100BASE-X Fast Ethernet (twisted pair or fiber optic) IEEE 802.3ab:1000BASE-T Gigabit Ethernet IEEE 802.3an:10GBASE-T 10G Ethernet IEEE 802.3bz:2.5G/5GBASE-T Ethernet...
-
Page 29: Appendix C Supplementary Instructions For Connecting The Sfp+ Port
SM512LM-300m and TL-SM512LS-10KM. TP-LINK optical modules are used in conjunction with TP-LINK series switches and use optical fiber transmission to expand the scope of the local area network and expand the bandwidth. It is suitable for large and medium-sized local areas. -
Page 30: Appendix D Product Warranty Card
Before you send the product for repair, please call our company's technical support hotline: 400-8863-400 to confirm the product failure. You can also send an email to fae@tp- link.com.cn for technical support. At the same time, we will publish the developed product drivers and the latest version upgrade software on our official website: www.tp-link.com.cn as soon as possible for your free download. - Page 31 Machine Translated by Google Layer 3 managed switch installation manual Appendix E Toxic and Hazardous Substance Content Statement Toxic and Hazardous Substance Content Statement 26...
- Page 32 Company address: 1st floor, 3-5th floor of the south section of Building 24, Industrial Factory Building 24, Shennan Road Science and Technology Park, Nanshan District, Shenzhen City, 1st-4th floor of the north section of Building 28 Technical support hotline: 400-8863-400 Company website: http://www.tp-link.com.cn Technical support email: smb@tp-link.com.cn 7103506385 REV3.2.0...
