Summary of Contents for TP-Link TL-ST2005
- Page 1 Machine Translated by Google Enterprise Networking Solution Installation Manual Full 10G Cloud Managed Switch TL-ST2005 TL-ST2008 TP-LINK Business Network TP-LINK Business Cloud APP...
-
Page 2: Table Of Contents
Machine Translated by Google Table of contents Chapter 1 Product Introduction———————————— 01 Product Introduction............01 1.2 Cloud Management...........01 Local management..........02 1.4 Product appearance............02 Chapter 2 Product Installation———————————— 06 2.1 List of items..........06 2.2 Installation Precautions..........06 2.3 Product Installation............07 Appendix A Common Troubleshooting——————————... -
Page 3: Chapter 1 Product Introduction
Cloud APP and TP-LINK Business Cloud Platform, making it easier to use. *The product-related illustrations in this manual are for illustration only. Please refer to the actual model. If there is no explanation, TL-ST2005 will be used as an example. -
Page 4: Local Management
3. Set the user name and password, and click "OK" to log in to the switch local management interface. noodle. 1.4 Product appearance ÿ Front panel The front panel of TL-ST2005 is shown in Figure 1-2. Indicator light 5 10Gbps RJ45 ports USB port... - Page 5 Always on USB connection is normal Off USB is not connected or connected abnormally Table 1-1 Description of working status of indicator lights 2 10Gbps RJ45 ports TL-ST2005 has 5 10G RJ45 ports, and TL-ST2008 has 8 10G RJ45 ports. Product Introduction 03...
- Page 6 Cloud management mode In this mode, TL- ST2008 supports cloud management. Users can remotely manage the switch through Shangyun APP or TP-LINK commercial cloud platform, or log in to http://10.18.18.251 to enter the local WEB interface to manage the switch.
- Page 7 Figure 1-5 Schematic diagram of the rear panel of TL-ST2008 1 Power interface The DC power interface of TL-ST2005 is connected to the 12VDC/2.5A DC power supply. 2Anti -theft lock hole uses an anti-theft lock chain, one end is inserted into the lock hole, and the other end is fixed on an immovable object to prevent the switch from being accidentally moved.
-
Page 8: Chapter 2 Product Installation
Machine Translated by Google Full 10 Gigabit Cloud Management Switch Installation Manual Chapter 2 Product Installation 2.1 Item list TL-ST2005 item list is as follows: ÿ Switch (1 unit) ÿ Power adapter (1 piece) ÿ Installation manual (1 copy) The TL-ST2008 item list is as follows: ÿ... -
Page 9: Product Installation
ÿ Desktop Installation TL-ST2005/TL-ST2008 supports desktop installation. The 4 foot pads of TL-ST2005 have been pasted in the circular grooves at the four corners of the bottom of the case when they leave the factory (the 4 foot pads of TL-ST2008 need to be pasted in the circular grooves at the four corners of the bottom of the case by yourself), and you can directly place the switch steadily on the desktop. - Page 10 Machine Translated by Google Full 10G Cloud Managed Switch Installation Manual ÿ 19-inch standard rack installation TL-ST2008 supports rack installation. 1. Check the grounding and stability of the rack; 2. Install the two L-shaped angle irons in the accessories on both sides of the switch panel, and use the accessories to Fix with the screws provided in Figure 2-2;...
-
Page 11: Appendix A Common Troubleshooting
Machine Translated by Google Full 10 Gigabit Cloud Management Switch Installation Manual Appendix A Common Troubleshooting Problem 1. Forgot the switch username and password (how to restore factory settings). Press and hold the Reset button until all port indicators turn on and off. After releasing it, the switch will restart and restore to factory default settings. -
Page 12: Appendix B Technical Parameters Specifications
Machine Translated by Google Full 10G Cloud Managed Switch Installation Manual Appendix B Technical Parameters and Specifications TL-ST2005 TL-ST2008 Parameter item Technical Standard IEEE 802.3: Ethernet Media Access Control (MAC) Protocol IEEE 802.3u:100BASE-X Fast Ethernet (twisted pair or fiber) IEEE 802.3ab:1000BASE-T Gigabit Ethernet IEEE... -
Page 13: Appendix C Declaration Of Toxic And Hazardous Substances
Machine Translated by Google Full 10 Gigabit Cloud Management Switch Installation Manual Appendix C Declaration of Toxic and Hazardous Substances Toxic and Hazardous Substances Statement 11... -
Page 14: Appendix D Product Warranty Card
Before you send the product for repair, please call our company's technical support hotline: 400-8863-400 to confirm the product failure. You can also send an email to fae@tp-link.com.cn for technical support. At the same time, we will publish the developed product drivers and the latest version upgrade software on our official website: www.tp-link.com.cn as soon as possible for your free download. - Page 15 ÿ The mailing costs for returned products are unilaterally borne by the sender. ÿ For any other promises made by the distributor to you that are not guaranteed by TP-LINK Technology Co., Ltd., TP-LINK Technology Co., Ltd. The company does not assume any responsibility.
- Page 16 Related documents In addition to this installation manual, we also provide electronic versions of the User Manual and Lightning Protection Installation Manual. For the latest product information, please visit http://www.tp-link. com.cnÿ Company address: 1st floor, 3-5 floors in the south section of Building 24, Industrial Factory...
