CO-OPM-PONX / Interactive Operating Manual
1.0 Introduction
1.1 Description
1.2 Special Features
1.3 Specifications
1.4 Accessories
1.5 Powering
1.6 Meter Care
2.0 Getting Started
2.1 Explanation of Operating Keys 4
2.2 Meter Port Assignments
2.3 Menu
2.4
PON Power Meter: Measurements (PPM)
2.5
Visual Fault Locator: Function (VFL)
Wavelength Specific Optical Testing and Measurement Equipment
Best viewed with Adobe Acrobat Reader
2
2
2
2
3
3
3
4
5
5
6
7
ChallengerOptics.com
Getting Started continued
2.6 Meter Setup Function
2.6.1 Thresholds
Setting Threshold Limits 9
Selecting Threshold Group10
2.6.2 Setting Date and Time 11
2.6.3 Setting Stand By
2.7 Saved Record Review/Delete Function13
2.7.1 CHECK / Review Record 14
2.7.2 DELETE / Record
2.7.3 DELETE ALL / Record
3.0 Software
4.0 Maintenance
Technical Parameter
8
9
12
14
14
15
15
16
