Summary of Contents for Eurovema EUROFLEX HiLo SR
- Page 1 User Manual, English Work Chair HiLo SR Rev: 22/10/2024...
- Page 2 Contents INTRODUCTION ............................3 CONTACT DETAILS ........................... 3 USER INFORMATION ..........................3 SERVICE AND WARRANTY........................3 UPON DELIVERY ............................4 SAFETY RULES ............................4 SYMBOL KEY ............................5 WARNING ..............................6 REPORTING OF ACCIDENTS AND INCIDENTS ................... 7 CLEANING ..............................7 STORAGE..............................
- Page 3 Read the User Manual carefully so you can make use of all the options provided by your chair. Eurovema reserves the right to make changes to this manual and its contents.
- Page 4 Pay attention to screws or parts that become loose or fit loosely as they may impact safety. Contact the service organisation immediately. Service and maintenance must only be carried out by a Eurovema authorised technician. • Only original parts from Eurovema may be used.
- Page 5 SYMBOL KEY Warning Read User Manual Warning, risk of crushing Seat tilt Do not iron Adjustable back tilt Do not use dry cleaning solvents stronger than tetrachloroethylene Back height Do not use bleach Seat depth Armrest height Do not tumble dry Operation button, electric function Machine wash 60°...
- Page 6 Aid Centre or Eurovema Mobility AB for advice. Modifications to the product will invali- date the CE mark and Eurovema will no longer accept any liability. Modifications carried out by an authorised technician that have been agreed with Eurovema may allow the CE mark to remain valid.
- Page 7 The awarding of a CE mark shows that the product has undergone a series of risk analyses and tests, with steps taken to minimise any risks identified as far as possible. If, despite eve- rything, accidents or incidents occur, such events must be reported to Eurovema Mobility AB and the relevant national authority.
- Page 8 LABEL The label on the product contains important information. 1) Product name 2) Part number 3) Serial number UDI-PI 4) Barcode 5) Max. user weight 6) Medical device 7) CE marking 8) Read the manual before use 9) Manufacturing date 10) Manufacturer's name SECONDARY LABEL 1) Applied part type B...
- Page 9 OVERVIEW - MARKING Loose covers can be machine washed. Crush risks are reported in connection with instructions for each function that may constitute a risk of crushing. Marking appears on the chair where there is a risk of crushing.
- Page 10 OVERVIEW - SEAT 1) Seat 2) Back support 3) Armrest 4) Side support 5) Footplate 6) Handle 7) Tilt control...
- Page 11 CHASSIS OVERVIEW 1) Front wheel 2) Centrally braked wheels 3) Parking brake pedal 4) Chassis 5) Seat lift motor 6) Electronics/battery 7) Lifting piston, gas...
- Page 12 FITTING/REMOVING SEAT The seat is fitted in a quick-release mounting and is easy to fit/remove if necessary. 1) When fitting the seat, the locking levers (1) must be pushed back as shown in the figure. 2) Insert the seat from the front so that the adapter plate under the seat engages in the spacers (2) and the notches in the front edge (3).
- Page 13 BACK SUPPORT - HEIGHT The height of the back support can be adjusted using a lever. 1) Loosen the lever (1) by turning it a ½ turn anticlockwise. 2) Set desired height. 3) Lock the back by turning the screw clockwise. The back support can be further raised using an adjuster the aluminium profile.
- Page 14 BACK SUPPORT - TILT The back tilt and back cushion are individually adjustable. Adjustable back tilt 1) Fold out the locking lever (1) 2) Set desired back tilt. 3) Fold back the locking lever (1) Back cushion 1) Loosen the lever (2) by turning it one turn anticlockwise. 2) Set the desired angle of the back cushion.
- Page 15 SEAT DEPTH (BACK SUPPORT) Seat depth can be adjusted using the back support. Set the desired seat depth by moving the back support mechanism backwards or forwards. Fine adjustment is done by tilting the back cushion. 1) Fold out the locking lever (1). 2) Tilt the back mechanism backwards to increase seat depth, tilt forwards to reduce seat depth.
- Page 16 SEAT DEPTH (BACK MECHANISM) Seat depth can be adjusted by moving the entire back mechanism forwards/backwards. 1) Loosen the screws (1) on each side of the back support a few turns anticlockwise using a 5 mm Allen key. 2) To reduce seat depth, slide the back mechanism forwards. To increase seat depth, slide the mechanism backwards.
- Page 17 ARMREST - HEIGHT RAISING 1) Loosen the screws (1), (2), and (3) a few turns anticlockwise. 2) Tilt the pillar backwards at screw (1). Whilst doing this, move the armrest platform forwards and upwards to the desired height. 3) Tighten screws (1) and (2) clockwise 4) Adjust the horizontal tilt of the armrest platform and tighten screw (3) clockwise LOWERING 1) Loosen the screws (1), (2), and (3) a few turns anticlockwise...
- Page 18 ARMREST - WIDTH 1) Loosen the screw (1) a few turns anticlockwise. 2) Adjust the width to the desired position. 3) Tighten the screw clockwise.
- Page 19 SIDE SUPPORT The side support is adjustable in four dimensions - width, height, horizontal tilt, and depth. In addition to reducing seat width, the side support can also be used to provide pelvic support by being moved to the furthest position back in the seat. 1) Loosen screws (1) and (2) one turn.
- Page 20 SEAT HEIGHT - ELECTRIC AND GAS Electric 1) Seat height is controlled using the button located on the control box. Take care when lowering the seat to ensure that there is nothing gets crushed. When raising the seat with the chair under a table/desk, there is a risk that your legs may be crushed.
- Page 21 BRAKE Apply the seat brake by pressing the brake pedal rear rubber. Release the brake by pressing on the pedal front rubber. Always apply the brake before getting in or out of the chair.
- Page 22 HAND CONTROL The hand control is height-adjustable. 1) To adjust the hand control, press and hold the buttons (1). 2) Adjust to the desired position and release the buttons (1)
- Page 23 CHARGING - GENERAL To ensure full battery performance for as long as possible, it is important that the battery is charged regularly. In an average use scenario, charging the battery every other day is a good guideline. If possible, charge the battery during the day. Seat functions cannot be used whilst the battery is charging.
- Page 24 TECHNICAL DATA - CHARGER LINAC CH01 Data Facts Input voltage 100-240VAC 50-60Hz Input current Max 0.5A Output current 0.5A Output voltage 28 +0.3/-0.6V DC Operating temperature +5 - +40°C Protection class Class 2 Protective enclosure IP X4 TECHNICAL DATA - ELECTRONICS Data Facts Input voltage...
- Page 25 TECHNICAL DATA - SEAT SYSTEM Data Facts Seat (width x depth)* 26x31, 29x32, 32x36, 36x40, 40x40 cm Seat width between armrests 24 - 34.5 cm Seat depth 18 - 42 cm Seat height, gas (height to underside 29 - 62 cm of seat)* Seat height, electric (height to under- 27 - 61 cm...
- Page 26 TECHNICAL INFORMATION Data Facts Class Work Chair - ISO 180903 Weight (gas) 30 kg Weight (electric) 34 kg User weight, max. 70 kg Battery 24V 2.9 Ah AGM ENVIRONMENT Condition Temperature Humidity Atmospheric pressure Normal use 5°C - 40°C 10% - 93% RH 50kPa –...
- Page 27 Detailed diagrams can also be found on the website in the Exploded Diagrams section. www.eurovema.se Point your browser to Private individuals should contact Eurovema for more information. Eurovema will assume responsibility for destruction. Disassembled components are to be sorted in accordance with the table below.
