- Page 1 OPERATOR MANUAL MINIMUM DISTURBANCE SUBSOILER Min-Dis All Models SCAN ME FOR WEBSITE LINK Agriweld Ltd Main Street Garton-on-the-Wolds Driffield YO25 3ET...
- Page 2 Packer adjustment Page 20 Electric light assembly Page 21 Main assembly & parts List Page 22 2-3.5m Min-Dis grass main assembly & parts list Page 23-24 Wing pivot bushes & parts list Page 25 Packer attachment Page 26 Packer assembly & parts list...
- Page 3 It is very important to be careful when new equipment is going to be used for the first time. Incorrect mounting of equipment and operational errors can lead to expensive repair work and operational losses. Your warranty with Agriweld is not valid if the instructions in this operating manual are not followed correctly.
- Page 4 Agriweld could have detrimental effects to this machine or its functions and hence impair the active and/or passive driving and/or operational safety (accident prevention). • Agriweld shall not be liable for any damage caused by the use of spare parts, accessories and ancillary equipment not supplied and/or approved by Agriweld. •...
- Page 5 1. No responsibility will be accepted for possible dangers arising from operations complying with the designated use. 2. Agriweld shall not be liable for any damage to agricultural produce and other items, which occurs as a result of normal operating, adjustments errors, failure by any means or incorrect usage.
- Page 6 Attach the Minimum Disturbance Subsoiler (MIN-DIS) to the tractor using the tractors rear 3-point linkage. It is important to the function of the MIN-DIS to ensure that the machine is running level (parallel to the ground) to allow optimum level of soil disturbance and to prolong the lifespan of the wearing parts.
- Page 7 SHEAR BOLT SOCKET & Replacing Shear Bolts SAFETY FIRST! Ensure the tractor is stationary and on as level and firm ground as possible with the tractor engine turned off to ensure safety. After breakback, remove the broken shear bolt (1) using 2 x M20 Spanners.
- Page 8 Replacing Snap Bars SAFETY FIRST: When replacing the Snap Bar after break back, raise the legs out of work sufficiently so that the leg falls back into position to allow the Snap Bar to be replaced. SAFETY! The tractor should be stationary and on stable, level ground with the engine turned off to ensure the operator is safe to perform the adjustments required.
- Page 9 Snap Bar Parts List (quantity stated per leg) Part Number Part Name Quantity 2021_2_Test_BASE_Bar_Snap Snap Bar SB_In_ASKRT_40MM_pin_002 40mm Snap bar ----- M24 X 105mm Bolt ----- M24 Washer ----- M24 Nyloc Nut ----- M16 x 80mm bolt ----- M16 Washer ----- M16 Nyloc nut LP11Z...
- Page 10 Auto Reset Socket Assembly...
- Page 11 Auto Reset Leg Socket Parts List (Quantity Per Leg) Part Number Part Name Quantity Multi_replace_ram_pin_001 30 x 166mm Multi_replace_pivot_pin-001 30 x 190mm Multi_replace_upD_E_HD_2022_AR 30 x 134mm _pin_ram_lower_001 ------ M12 X 50mm Bolt ------ M12 Washer ------ M24 Nylock ------ M24 x 70mm Bolt ------ M24 Washer...
- Page 12 The wearing parts used on the implement can vary according to the required use although as standard the Min-Dis is fitted with a low disturbance one-piece GLS/GLX style point. Parts can be obtained through Agriweld Ltd directly or through your local dealer.
- Page 13 • Unbolt each worn point in turn to free it from the leg by removing the M10 nylock nut and the M10 x 50mm long bolt. The point will be free to remove. A new point can then be replaced into the same position using the same M10 nylock nut and M10 x 50mm long bolt.
- Page 14 If the wings appear to be sagging or uneven, Agriweld can supply adjustment stars to level the machine. Always transport a hydraulic folding Subsoiler in its folded position. Do not forget to attach the...
- Page 15 HYDRAULIC FOLDING DIAGRAM Unfold Fold 4 way diverter 50/50 flow divider Feed Feed AUTO RESET PRESSURE AMENDMENTS (Applicable to auto-reset models only) The auto reset pressure is pre-set at around 45-50 bar for dispatch. You will need to adjust this setting to your own conditions on first use.
- Page 16 Changing Auto reset pressure – connection to tractor & procedure • To increase or decrease auto reset pressure, begin by making sure the 2 hydraulic pipes for the auto-reset system are connected to the tractor hydraulics at the rear. It is not imperative which way round they are attached.
- Page 17 AUTO RESET SYSTEM – Break back adjustment continued This step is ONLY for altering the auto reset pressures outside the normal scope of adjustment. It is for increasing and decreasing maximum system pressure on gauge. Top cap Adjuster screw (Allen Key Drive) Pressure gauge 1.
- Page 18 HYDRAULIC PACKER STAND & DEPTH ADJUSTMENT – (for 3m rigid model only) The packer roller doubles up for use as a stand when the machine is not in use. Lower the packer to its lowest position (no spacers) to use as a stand. When in the stand position, it is advisable to insert the relevant number of spacers to fill the area between the rod end and cylinder –...
- Page 19 When the weight is removed from the lower pin/s remove the lower pin/s and insert them into a lower pin hole. Raise the Min-Dis so the packer then rests on the lower pins again and replace the upper pins in the relevant hole immediately above the packer depth control arm. All pins must be placed in the corresponding setting to enable the packer to run level.
- Page 20 ELECTRIC LIGHT ASSEMBLY 5 (inside junction box) Item Number Part number Description Quantity per machine 6003 Plug Junction Box LT595 LH Light inc indicator LT596 RH Light inc indicator Strip connector 6 hole strip connector...
- Page 21 MIN-DIS MAIN ASSEMBLY Item number Part number Description Quantity per machine Headstock 6M_MinDis_2020_Packer_Frame_001 Packer Roller Frame 6M_MinDis_2020_Packer_Roller_001 Packer Roller Either CAT 2 or CAT 3 option CAT 2/3 Top Link Either CAT 2 or CAT 3 option CAT 2/3 Lower...
- Page 22 2 – 3.5m MIN-DIS GRASS - MAIN ASSEMBLY Item Number Part Number Description Quantity 3mGLS_4leg_MF_001_23 Main Frame 3mGLS_4Leg_Roller_001_23 Flat Packer Auto-reset/Snap HD_AR_2023_Main Bar leg assembly STD_Scraper_updated Scraper Assembly 704/1 (40-70) Ram Hydraulic Ram Standard_disc_arm Disc bar assembly...
- Page 23 FOLDING WING PIVOT BUSHES...
- Page 24 PARTS LIST Item Part Number Description Quantity Number AW_M12x55_B M12 x 55 Bolt Main wing pivot pin 6M_MinDis_2020_Main_Pivot_Pin AW_M16_W M16 Washer AW_M16_NL M16 Nylock AW_60_50_50_Oil Oilite bush...
- Page 25 PACKER ATTACHMENT...
- Page 26 Packer Assembly & Parts List Item number Part number Description Quantity per machine AW_M16x60_CS Countersunk M16 x 60 AW_M16_W M16 Washer AW_M16_NL M16 Nyloc Bearing Packer bearing AW_PK_ST_AX Packer roller stub axle AW_M16x60 M16 x 50 bolts AW_M16x60 M16 spring washers...
- Page 27 Min-Dis Grass Flat Packer Roller The Min-Dis Grass option uses a simple flat packer with drive teeth that effectively closes the opening cut made by the leading disc and leg to leave a consolidated, level finish. This Packer Roller uses the same axle and bearing as our standard Agri-Packer. See previous...
- Page 28 Angled Clearing Disc Assembly Angled Clearing Disc Parts List to fit Disc Bar (9) Part Num Description Quantity Per Disc 466947KR Angled disc M12 x 25 fine AW_M12_FT_25 threaded Bolt AW_M12_spring M12 Spring Washer BAA-0004 Disc Bearing AW_M12_55_Bolt M12 X 55 Bolt AW_M12_Washer M12 Washer AW_M12_Nyloc...
- Page 29 SCRAPER ASSEMBLY Item Part number Description Quantity per number Scraper Mount M12X120UB M12 U bolt 6M_MinDis_2020_0699 Scraper M12 washer M12 Washer M12 Nut M12 Nut M12X35 CHS M12 cup head square 23_double_scraper_mount_0801 Scraper Mount...
- Page 30 (Zinc plated stands x 2) STABILISING LEG ASSEMBLY Item number Part number Description Quantity per machine AW_MINDIS_Stand Stands AW_19x175_P 19mm x 175mm Kramp pin LP11Z 11mm Linch pin...
- Page 31 IMPORTANT MAINTENANCE & SAFETY Regular maintenance is a prerequisite for good operational reliability. The following safety advice is to be observed before starting any maintenance, cleaning or repair work. *Trained personnel may only execute maintenance activities. Inform operating personnel before beginning special operations and maintenance work! Delegate a supervisor! If necessary, ensure that the maintenance area is adequately secured.
- Page 32 Always retighten any screwed connections that have been unscrewed during maintenance and repairs. Any safety devices removed for setting-up, maintenance or repair purposes must be refitted and checked immediately upon completion of the maintenance and repair work and prior to operation. The following areas must be kept well-greased at all times: •...
- Page 33 Braking System Maintenance and diagram Brake Drum Hydraulic Brake adjustment profile High tension spring Greasing Point Stub Axle we do not recommend tampering with the braking systems of your machine, maintenance should only be carried out in the correct manner by a qualified person. Short term maintenance typically includes;...
- Page 34 ROAD TRANSPORT REGULATIONS In accordance with The Road Vehicles Order 2003 No. 1998 Part 3 SPECIAL TYPES FOR AGRICULTURE The Department of Transport required the maximum width of an agricultural machine to be 2.55m or less. Under special circumstances, agricultural machines wider than 2.55m are permitted to use public roads. The Road Vehicles Order 2003 permits the road use of agricultural vehicles that are up to 4.3m in width, subject to terms and conditions.
- Page 38 PRODUCT DECALS Part number Description Quantity Sticker machine RHINO_AGRI_01 160x110mm Rhino cultivation oval AW_MINDISSS_PS Packer Marker Sticker GB_logo 87X55mm made in Great Britain Sticker AW_ARP Auto reset pressure sticker Read operator AW_OM_S manual sticker AW_ARPW Auto reset pressure warning AW_MIN_DIS Headstock Sticker AW_agri_packer...
- Page 39 If you have arranged your own transport and the order has been received damaged, you will need to report any damages to the haulier yourself. Agriweld will not be able to enter any claim with a haulier where transport has not been arranged by Agriweld. Thank you...
- Page 40 Manufacturer Name: Agriweld Ltd Manufacturer Address: Main Street, Garton-on-the-Wolds, Driffield, YO25 Product: Minimum Disturbance Subsoiler (MIN-DIS) All models - 3m rigid to 6m hydraulic folding 2.5m Grassland Model Snap bar shear bolt or auto reset option. Product Options: Individual Serial Number:...
- Page 41 Maintenance table Work Parts used / Name of Date Notes Undertaken parts replaced operator...
