- Page 1 TRANSPORT BOX for John Deere 8RX Tombstone Agriweld Ltd Main Street Garton-on-the-Wolds Driffield YO25 3ET...
- Page 2 Contents Page 3 General Safety & Qualifications & Training Page 4 Unit Weight & Risks of Overloading Page 5 Pre-Use Checks & Storage Page 6 Attachment to tractor tombstone Page 7 Assembly Page 8 Parts List Page 9-10 Special Safety Instructions & Important Maintenance Page 11-12 Connecting Your LED’s Page 13 –...
- Page 3 This manual must be provided to all persons concerned who will be involved with the setting up, operation, maintenance and use of the tractor and transport box. It must be available at all times. If important safety instructions are not complied with, it can lead to the risk of injury to you and others as well as damage to property and the environment.
- Page 4 It is important to ensure any additional weight imposed when carrying tools/spares stored within the transport box is also accounted for and the additional weight does not exceed the overall maximum capacity of the tractor’s linkage/chassis.
- Page 5 When products are to be stored away when not in use, correct storage methods are important in protecting the paintwork. The product should be cleaned down thoroughly and stored inside where possible, always detach any other attachments from the Agriweld product when you have finished using them.
- Page 6 ATTACHMENT TO TRACTOR TOMBSTONE Tractor tombstone Use a forklift to pick up the transport box and position Ball as shown so the attachment hooks are located over the tractors tombstone weight carrier and lower the box until the tractor is supporting its full weight. Proceed to...
- Page 7 Transport Box Assembly...
- Page 8 Transport Box Parts List DESCRIPTION PART NUMBER QTY PER BOX Transport box body Logo Light cover 2018_TB_HNG_0414NO CUT.SLDPRT LED Side Marker AW_AMB_SM 2020_JD8RX_TB_Ass03NO CUT.SLDASM Chevron AW_CHV_STL Center securing bolt AW_M24x280_B Outer securing bolts AW_M24x200_B M24 Nuts AW_M24_NL Centre securing washer 2020_JD8RX_TB_1201_NO CUT.SLDPRT...
- Page 9 Special Safety Instructions Take extra care when connecting or disconnecting the transport box to/from the tractor. Be aware of what is under the transport box (such as your feet) before dropping it off. Do not work under a suspended load.
- Page 10 Before use, always check round the transport box to ensure no damage has occurred and that the attachment appears safe to use. • Keep the transport box clean at all times to enable users to perform easy visual check for damage/faults. Acquiring spare parts Please quote the details on the type plate(s) as well as the machine’s serial no.
- Page 11 STANDARD FIXED AMBER LED SIDE MARKER LIGHTS To connect your amber LED side marker lights, fitted as standard, you will need to wire them up to a relevant 12-24 V electrical plug, suitable for your tractors electrical supply. BLUE WIRE = EARTH (NEGATIVE -) BROWN WIRE = LIVE (POSITIVE +) AMBER LED3DV FLASHING MARKER LIGHTS:...
- Page 12 Pattern Pattern Synchronise Alternate Number ✓ ✓ Single Alert 150 – Phase 1 ✓ Single Alert 150 – Phase 2 ✓ ✓ Single Alert 75 – Phase 1 ✓ Single Alert 75 – Phase 2 ✓ ✓ Single Alert 375 – Phase 1 ✓...
- Page 16 Manufacturer’s Warranty/Guarantee Your Agriweld transport box is covered for a period of 12 months from the date of dispatch (which is recorded on our files) against faulty components and/or bad workmanship. Guarantees for overseas orders will begin when the product reaches its delivery destination as advised on the delivery/collection paperwork.
- Page 17 Stickers Quantity per Sticker Part number Description Machine AW_WB_AS Agriweld Sticker (185 mm x 85mm) AW_WB_GB Great Britain (85mm x 50mm) Sticker Serial plate Serial plate (76mmX51mm) Standard AW_CV_STL Chevron Read operator AW_OM_S manual sticker...
- Page 18 Product: JD8RX Transport Box Product Options: Tombstone/bolster mounting Individual Serial Number: Individual Product Description: Transport Box for John Deere 8RX - Tombstone Supplementary Information: Weight approx. 265kgs Date of Last Load Test: Authorised Signatory on Behalf of Manufacturer: Dawn Foster...
- Page 19 Notes This page is blank for your own notes such as servicing & fault finding...
