WEEE DISASSEMBLY INSTRUCTIONS
SUPERMICRO ASG-1115S-NE316R ENCLOSURE
Abstract
This document provides clear guidance for end-of-life recyclers on how to identify
and disassemble reportable materials in compliance with the Waste Electrical and
Electronic Equipment (WEEE) directive.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Supermicro ASG-1115S-NE316R
Summary of Contents for Supermicro ASG-1115S-NE316R
- Page 1 WEEE DISASSEMBLY INSTRUCTIONS SUPERMICRO ASG-1115S-NE316R ENCLOSURE Abstract This document provides clear guidance for end-of-life recyclers on how to identify and disassemble reportable materials in compliance with the Waste Electrical and Electronic Equipment (WEEE) directive.
- Page 2 Table of Contents Product Views ............................3 Reportable Materials on ASG-1115S-NE316R ..................4 Disassemble Instructions .......................... 5 3.3 Step-by-Step Disassembly Instructions ....................8 Removing Cable and Chassis Top Cover ..................8 Removing Hard Disk Drive (HDD) / Solid State Drive (SDD) ............9 Removing Power Supply ......................
- Page 3 1. Product Views Front view Rear view Product construct view...
- Page 4 2. Reportable Materials on ASG-1115S-NE316R According to Article 8(2) and Annex VII of WEEE directive 2012/19/EU, below materials and components should be selectively treated. Description Notes Quantity Printed Circuit Boards (PCB) or With a surface greater than 10 sq cm 2.4,3.5,4.2,4.1,6.1, 8.2,...
- Page 5 3. Disassemble Instructions The intent of this document is to provide guidance to recyclers on the presence of materials and components at the product / family level, as required by the EU WEEE Directive 2012/10/EU. This document should also help direct recyclers to proper methods for removing parts and general product disassembly instructions.
- Page 6 Chassis Cable Backplane *2 Air Shroud Plastics Cover Cable *8 Motherboard Battery Add-On Card Riser Card Screw, Stand-off...
- Page 7 Power Supply Power Enclosure*2 Screw and Standoff*2 Set Power Supply Module*2 Storage Card and CPU Heat Sink Processor Hard Drive*2 AIOM *2 DIMM *3 Set Power Cable...
- Page 8 3.3 Step-by-Step Disassembly Instructions 1. Removing Cable and Chassis Top Cover 1. Use the operating system to power down the system. 2. After the system has completely shut-down, disconnect the power cords from the power supply modules. 3. Remove all cables/ unit from the server IO port. 4.
- Page 9 2. Removing Hard Disk Drive (HDD) / Solid State Drive (SDD) 1. Push the release button on the drive carrier, which will extend the drive bay handle 2. Use the drive bay handle to pull the drive carrier out of the chassis 3.
- Page 10 6. Use a cross screwdriver to remove screws and lift off the PCB Description Dummy Tray HDD/ SSD Hard Drive Enclosure Hard Drive PCB 3. Removing Power Supply 1. Press the release tab on the failed power supply. 2. Use the handle to gently slide the power supply out the back of the chassis. 3.
- Page 11 4. Cut the power leads connected to the fan and lift the main board from the chassis Description Power Supply Power Enclosure Fan Cable Power Module PCB Capacitor 4. Removing Backplane 1. Remove the backplane screws from the chassis Description Backplane 5.
- Page 12 2. Lift the fan out of the chassis. Description Cooling Fan 6. Removing AIOM Card 1. Release thumbscrew and pull the AIOM out of chassis. 2. Press the pin and remove the pin and take the PCB from AIOM...
- Page 13 Press the pin Description AIOM Card AIOM PCB 7. Removing the Air shroud, Riser 1. Lift the air shroud out of the chassis by hand 2. Remove screws each from the riser card bracket 3. Take the riser card and bracket away from the chassis Description Air shroud Riser Card...
- Page 14 8. Removing Processor 1. Unscrewing the screw and remove the heat sink from CPU package. 2. Unscrewing the CPU package screw, then lift up the force frame and rail frame . 3. Pull up the CPU from rail frame. Note: Please handle the processor with care to avoid damaging it or its pins Description Heat Sink Processor...
- Page 15 9. Removing DIMM 1. Hand press both release tabs on the ends of the DIMM module to unlock it 2. Once the DIMM module is loose, remove it from the memory slot Description DIMM 10. Removing Motherboard 1. Remove screws, lift out motherboard 2.
