- Page 1 MOTORCYCLE INSTALLATION GUIDE COMPONENTS LIGHT STRIPS AURA BLUETOOTH CONTROL BOX VARIOUS EXTENSION WIRES POWER HARNESS WITH ON/OFF SWITCH ZIPTIES Y-SPLITTERS...
- Page 2 INSTALLATION STEP 1 Inspect kit to ensure all contents was included. STEP 2 Decide where to locate the light strips and ensure wiring has enough length for control box to be installed in desired location. EXTENSION WIRE EXTENSION WIRE AUXILIARY Y-SPLITTER WIRE FUSE...
- Page 3 BRIGHTNESS AUX WIRING FOR A BRAKE LIGHT You may choose the desired color choice directly on the OPT7 CONNECT app. This feature will activate when the aux wiring is connected to the trigger wire for positive (+) wire of your brake light wire.
- Page 4 SET BRAKE LIGHT COLOR CONNECTED 1. Press DOOR ASSIST button. DOOR WHITE ASSIST 2. Choose the red color. 3. Press ‘’SAVE’’ to complete. RANDOM PRESET MODE SAVE BRIGHTNESS STEP 5 After testing, secure the control box in a desire location using the Velcro or zip-ties provided.
- Page 5 DISCLAIMER OPT7 Lighting is not liable for damages or personal injuries while installing this product. The Installation Guide is intended as assistance to reduce setup time. OPT7 Lighting assumes no responsibility for improper installation. If you are unfamiliar with your vehicle or inexperienced with aftermarket upgrades, please seek professional assistance.
