BowFlex HVT: Why is there no power to my machine or console?
Follow this troubleshooting guide to help resolve power issues on the BowFlex HVT.
Some common complaints may include:
Machine won't turn on
Console does not light up
Console does not turn on
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
1.
Unplug the power supply from your machine and the wall outlet. Inspect the length of the cord for damage,
such as exposed wires. Check the end of the adapter and make sure that it is undamaged as well. If damage i
present, order a Power Adapter and a Power Inlet
2.
Test the wall power outlet that your machine uses with another device, such as a lamp, to ensure it is working
If the power outlet does not provide power to the new device, try plugging your machine into another outlet
and powering on [13313.B].
3.
If the issue persists or the console only lights up partially, inspect the console and console/lower chassis cable
connection. Remove the 6 screws attaching the console assembly to your machine using a Phillips head
screwdriver (reference 1). Pivot the console assembly, remove the console from the body, and unplug the
cable. Inspect the cable and cable connectors for damage. Look for cuts, crimps, and exposed wire on the
cable and bent or missing pins in the connectors. If undamaged, reconnect the cable and secure the console
assembly on your machine. Test to see if the console will light up fully [13313.C]. If the console is damaged
or the console still only lights up
damaged, order a Console
order a Lower Chassis
about:blank
BowFlex HVT:  Why is there no power to my machine or console?
partially, order a
Cable [13313.E]. If the cable coming from the body of your machine is damaged
Cable [13313.F].
(Reference 1)
Plug [13313.A].
Console [13313.D]. If the cable to the console is
ID: 13313.1
