Delfield ACR-26S Specifications

Short Form Specifications

Exterior Body: Construction of 20-gauge stainless steel and 2" (5.08cm)
of high density foamed in place polyurethane insulation provides durability
and energy savings. A rear handle with rubber end bumpers combined
with flush recessed handle grips on the side make positioning the unit easy.
The unit is mounted on 4" (10.2cm) diameter casters (with brakes) with
an overall height of 5.37" (13.6cm), and rolls where needed for loading,
storage or serving. Unit is wired with cord and plug.
Doors: The fully insulated door is constructed of 20-gauge stainless steel with
magnetic catch, and opens 270 degrees for ease in loading or unloading.
Specify left or right hinging when ordering. Doors can be field reversed with
hinges ordered from the factory. A security lock is standard.
Interior Cabinet: 22-gauge stainless steel construction, sealed joints and
seams provide the ACR-26S with a strong and durable interior. Corners
are rounded for ease of cleaning and conforms to NSF standards. Interior
air ducts on the left, right and top provide proper air flow to the cabinet.
The interior is designed for use with 18" x 26" (46cm x 58cm) trays on
adjustable slides spaced 3.75" (9.5cm) apart. Interior panels and brackets
are removable for easy cleaning.
Air Curtain: When the door is open, Delfield's patented air curtain design
directs cold air across the cabinet opening, keeping hot air out and cold
air in for extended periods of time. The unit will maintain a maximum
of 45°F box temperature at 70°F ambient with the door open and all
trays fully behind the air curtain, during peak production times, quickly
returning to a normal 36°F. With the door closed, a maximum 40°F at
100°F ambient is maintained (normal operation) while running only 15%
in an 85° room.
Refrigeration: The base of the cabinet houses the condensing unit.
Louvered front and rear panels provide ventilation, as well as easy access
for cleaning and servicing the condensing unit and electrical wiring.
The refrigeration system uses HFC-404A refrigerant. Compressor is 1/2
horsepower (120v-60c-1ph).
Microprocessor: Solid state control with temperature and time display,
clean condenser alert and self diagnostic functions.
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • (800) 733-8821 • Fax (800) 669-0619 • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
PROJECT
ITEM #
QUANTITY
APPROVAL
ACR-26S
Air Curtain Refrigerator
Model ACR-26S
DATE
