Outland Living NELSON FMPPC2E-445 Owner's Manual

Fire table
Hide thumbs

Advertisement

Quick Links

Download this manual
Model number FMPPC2E-445
® Registered trademark of FMI Brands Inc.
The OUTLAND Flame mark is a registered trademark of FMI Brands Inc.
This instruction manual contains important information necessary for the proper assembly
Read and follow all warnings and instructions before assembling and using the appliance.
Follow all warnings and instructions when using the appliance.
MANUFACTURED BY FMI BRANDS INC. 101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5
USA, Canada Toll Free: 1-888-514-1663 | Email: info@outlandliving.com
Hours of Operation: 8:30AM - 4:00PM (Pacific Time)
OWNER'S MANUAL
NELSON
FIRE TABLE
and safe use of this product.
Keep this manual for future reference.
D.445.000.V0

Advertisement

loading
Need help?

Need help?

Do you have a question about the NELSON FMPPC2E-445 and is the answer not in the manual?

Questions and answers

Related Manuals for Outland Living NELSON FMPPC2E-445

Summary of Contents for Outland Living NELSON FMPPC2E-445

  • Page 1 OWNER’S MANUAL NELSON FIRE TABLE Model number FMPPC2E-445 ® Registered trademark of FMI Brands Inc. The OUTLAND Flame mark is a registered trademark of FMI Brands Inc. This instruction manual contains important information necessary for the proper assembly and safe use of this product. Read and follow all warnings and instructions before assembling and using the appliance.
  • Page 2 Installation and service must be performed by a CONSUMER: Retain this manual qualified installer, service agency, or the gas supplier. for future reference. En-1 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0 ®...
  • Page 3 Indoor storage of this appliance is permissible only if the cylinder WARNING: is disconnected and removed from the appliance. Improper installation, adjustment, alteration, service or Cylinders must be stored outdoors in a well-ventilated area out maintenance can cause injury or property damage. Read of the reach of children.
  • Page 4 (connections 1-4) ignite the appliance. See “Section 2: IGNITION”. PUSH THE KNOB IN AND QUICKLY TURN TO THE 12:00 POSITION. HOLD FOR 10 SECONDS. RELEASE. En-3 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0 ®...
  • Page 5 Spray the soap water solution on connections (5 and 6) Apply the solution to the LP gas delivery system at points: under the table. 1. Gas Hose Regulator 12. Once you have confirmed there are no gas leaks 2. Cylinder Valve Coupling (connections 1-6) your appliance is ready for use.
  • Page 6 Only use a replacement hose by OUTLAND Living. Should you have any questions or comments regarding this BURNER & ORIFICE INSPECTION appliance, please do not hesitate to contact FMI Brands Inc. at Inspect the burner prior to each use.
  • Page 7 Supplied parts & hardware list: PART # DESCRIPTION QUANTITY PICTURE PART # DESCRIPTION QUANTITY PICTURE Tabletop Assembly: M6 x 50 3pc Tabletop Frame, Integral Screw Tempered Glass Assembly Tabletop Panel, Pulse Igniter, Gas Valve, Gas Hose and Regulator, CSA Gas Hose Clip Hang Tags M5 x 16 Screw Right Leg Frame...
  • Page 8 2.2 – Remove the tape holding the silicone pads to the Leg Frames (part 2 and 3). En-7 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0 ®...
  • Page 9 2.3 – Install one leg frame with the rivet nuts facing the front side of the fire table (Right Leg Frame shown in the diagram). M6 X 50 3PC INTEGRAL SCREW ASSEMBLY (PART 5) INSTRUCTION SILICONE PAD LIP (1) M6 PLAIN WASHER FRONT (1) M6 SPLIT LOCK WASHER RIVET NUTS...
  • Page 10 3.3 – Affix the gas hose to the tabletop frame with (1) Gas Hose Clip (part 6) using (1) M5 x 16 Screw (Part 7). 3.4 – Affix the gas hose to the Leg Frame with (2) Gas Hose Clips using (2) M5 x 16 Screws. En-9 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0...
  • Page 11 STEP 4 4.1 – Turn the fire table upright. This is a two-person job. 4.2 – Use scissors to cut the two straps that hold the tempered glass panel in place. NOTE: If the fire table is rocking, adjust the threaded stainless feet on HEAVY OBJECT.
  • Page 12 Your OUTLAND Fire Table is assembled and ready for use. NOTE TO USER: Before igniting the unit for the first time, follow steps 1 through 6 in the below Ignition section. En-11 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0 ®...
  • Page 13 SECTION 2: IGNITION STEP 1 Make sure no debris or flammable material is in or near the burn area. STEP 2 Ensure that the gas valve knob is in the “OFF” position by pushing and turning clockwise until the dial stops.
  • Page 14 The thermocouple will automatically shut off the gas if the cable, or ground wire, is not connected properly. En-13 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0 ®...
  • Page 15 SECTION 2: IGNITION (continued) WHAT IS A PULSE IGNITER? A pulse igniter is a device that generates electrical pulses used to create a spark to ignite a fuel-air mixture in a burner. When the spark is produced, it jumps across the spark gap and ignites the flammable gas, initiating combustion. TIPS: PULSE •...
  • Page 16 REMOVE UPPER GAS VALVE COVER UPPER GAS VALVE COVER UPPER GAS VALVE COVER MOUNTING SCREWS REMOVE AND INSPECT BATTERY En-15 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0 ®...
  • Page 17 SECTION 3: TROUBLESHOOTING (continued) 1.4 – Locate the igniter cable coming from the burner. Ensure IF YOU GET SPARK, BUT THERE IS NO GAS, OR THE GAS KEEPS SHUTTING OFF: the small rectangular connector is attached firmly to the pulse igniter and the silicone cover is pressed up against the 1.1 –...
  • Page 18 IMPORTANT: When re-inserting the thermocouple cover into the burner, ensure the bracket slots back into the burner. The top of the bracket should be flush with the enameled burner boxes. En-17 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0...
  • Page 19 SECTION 3: TROUBLESHOOTING (continued) GOT A LOW FLAME? NOTE: Elevation and temperature affect the cylinder gas pressure and performance (flame height) of gas appliances. Your geographic location or local weather may be at fault. STEP 1 Check propane level. If less than half full replace the cylinder. Repeat the ignition sequence in section 2. STEP 2 If the propane cylinder is full and your Fire Table experiences low flame, or flame height does not appear to be normally adjusted by the gas knob, it is likely that the CSA excess flow safety device has been tripped in the hose regulator.
  • Page 20 (do not wipe in a circular motion, or against the grain, or scratches may appear). With a little ‘elbow grease’, the surface tarnish can be removed. En-19 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0...
  • Page 21 SECTION 6: DIMENSIONS [ 1143 mm ] 45” LxWxH 1143 x 686 x 379 mm (45” x 27” x 14.9”) NOTE: DIMENSIONS ARE APPROXIMATE. REAR SIDE FRONT SIDE WARNING NOTES: • Expected burn time: the anticipated burn time for your •...
  • Page 22 STEP 3 Remove the tempered glass tabletop panel and lay it flat on a piece of cardboard. STEP 4 Turn the fire table upside down. En-21 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • NELSON D.445.000.V0 ®...
  • Page 23 STEP 9 STEP 7 Leak test the connection. See section named “LEAK TEST”. Use a flashlight to look inside the burner tube. Use a long flexible pipe cleaner, or long small utensil to clean out any debris or nest material. An air tool to blow out the burner is helpful, but please STEP 10 wear eye protection.
  • Page 24 Any returns sent back to FMI Brands must be sent via prepaid freight and in the original retail packaging. Please register your OUTLAND Living product for proof of purchase and warranty at https://outlandliving.com/register-products/ For more warranty information and details please contact FMI Brands Inc.
