Outland Living MAIN STREET Owner's Manual

Fire table
Hide thumbs

Advertisement

Quick Links

Download this manual
Model number FMPPC2E-430
® Registered trademark of FMI Brands Inc.
FMI BRANDS INC.
101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5 | Toll Free 1-888-514-1663 | Fax 1-888-797-9931
OWNER'S MANUAL
MAIN STREET
FIRE TABLE
NOTICE : THIS
PRODUCT CONTAINS A
THERMOCOUPLE SAFETY
DEVICE WHICH SHUTS
OFF THE GAS. PLEASE
READ THE INSTRUCTIONS
CAREFULLY TO
UNDERSTAND HOW IT
WORKS.
D.430.000.V0

Advertisement

loading
Need help?

Need help?

Do you have a question about the MAIN STREET and is the answer not in the manual?

Questions and answers

Related Manuals for Outland Living MAIN STREET

Summary of Contents for Outland Living MAIN STREET

  • Page 1 OWNER’S MANUAL MAIN STREET FIRE TABLE NOTICE : THIS PRODUCT CONTAINS A THERMOCOUPLE SAFETY DEVICE WHICH SHUTS OFF THE GAS. PLEASE READ THE INSTRUCTIONS CAREFULLY TO UNDERSTAND HOW IT WORKS. Model number FMPPC2E-430 ® Registered trademark of FMI Brands Inc.
  • Page 2 CONSUMER: Retain this manual for Installation and service must be performed by a future reference. qualified installer, service agency, or the gas supplier. En-1 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 3 Indoor storage of this appliance is permissible only if the cylinder is WARNING: disconnected and removed from the appliance. Cylinders must be stored outdoors in a well-ventilated area out of Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the reach of children.
  • Page 4 6. The leak(s) must be stopped by tightening the loose joints, if possible, or by replacing the faulty parts(s) with the part(s) recommended by the appliance manufacturer. En-3 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 5 LP gas supply must be shut off at the cylinder valve or the cylinder Only use a replacement hose by OUTLAND Living. must be removed from the appliance until the leak(s) is corrected.
  • Page 6 Removable Side • Cross (Phillips) Screw Driver (PH2 and PH3) Panel Fixed Side Panel Gas Valve, Gas Hose and Regulator Mounting Bracket Assembly Cross Bar En-5 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 7 SECTION 1: ASSEMBLY STEP 1: DEFINE YOUR WORKING AREA Tabletop (part 2) Lay the Tabletop on a flat non-marking surface. TIP: Use cardboard or foam provided in packing box as a work surface. Assembly Work Surface (Top Packing Insert) (part 1) STEP 2: BUILD THE FRONT PANEL ASSEMBLY Assemble (1) Post 1 and (1) Post 2 to the Front Panel using (8) Identify the (2) POST 1 and (2) POST 2.
  • Page 8 Assemble (1) Post 1 and (1) Post 2 to the Rear Panel using (8) M4 x 10 Screws. Post 2 Post 1 M4 x 10 En-7 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 9 SECTION 1: ASSEMBLY (continued) STEP 5: BUILD THE REMOVABLE SIDE PANEL • Assemble the (2) Finger Lift Brackets to the Removable Side Panel using (4) M4 x 6 Flat Head Screws. • Insert the (6) Plug Bumpers in the Removable Side Panel as shown. STEP 6: BUILD THE PROPANE CYLINDER SUPPORT FRAME Assemble the (2) Crossbars to the H-Frame Cylinder Support using (4) M5 x 10 Screws.
  • Page 10 The gas valve orifice should be inside the burner tube and visible through the bug screen mesh. If your orifice and burner tube does not line up like in the image above, please call customer service. En-9 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ®...
  • Page 11 SECTION 1: ASSEMBLY (continued) STEP 7C STEP 7B Connect the round thermocouple cable to the thermocouple socket. Connect the igniter cable to the gas valve igniter. NOTE THE GAS HOSE THERMOCOUPLE SOCKET SMALL RECTANGULAR ROUND CONNECTION THERMOCOUPLE CABLE GAS VALVE IGNITER IGNITER CABLE...
  • Page 12 • Use (4) M4 x 10 screws to affix the middle holes. • Tighten the (4) screws in the slot holes En-11 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 13 SECTION 1: ASSEMBLY (continued) STEP 10: PROPANE CYLINDER ASSEMBLY Use (8) M5 x 10 Screws to fasten the LP cylinder H-Frame. Note 1: the wing nut should face toward the removable side panel. Note 2: the screws assembling the H-Frame should face the floor.
  • Page 14 STEP 14: SIDE PANEL ASSEMBLY Assemble the Removable Side Panel by resting on cross bars and pushing closed. To remove, simply use the finger-lifts and lift panel away. En-13 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 15 SECTION 1: ASSEMBLY (continued) STEP 15: GLASS ROCKS ASSEMBLY Open bag of Glass Rocks and arrange neatly and evenly in the burner tray. Ensure igniter cover is not covered by glass rocks (see photo). This helps air circulate. Take care to keep rocks out of the igniter cover.
  • Page 16 For more information about the CSA excess flow safety device see Section 3. STEP 6 Leak Test all connections. See section labeled “Leak Test”. En-15 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 17 SECTION 2: IGNITION (continued) STEP 7: IGNITION WITH THERMOCOUPLE PUSH THE KNOB IN AND QUICKLY TURN TO Your Fire Table is equipped with an auto spark ignition (piezo ignition) and 12:00 POSITION. DO NOT thermocouple. RELEASE THE GAS KNOB FOR 10 SECONDS. IMPORTANT: •...

  • Page 18: Troubleshooting

    TO THE CORRECT SOCKETS CLEAN THE THERMOCOUPLE TIP MAKE SURE THE AND IGNITER TIP SILICONE COVERS ARE PRESSED UP AGAINST THE GAS VALVE CONNECTION En-17 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 19 SECTION 3: TROUBLESHOOTING (continued) STEP 2 1. Wait until the glass rocks are cool, or wait 5 minutes for any gas to dissipate, whichever is longer. 2. Turn the gas cylinder valve to the ‘Closed’ position. 3. Open the fire table gas knob control for 3 seconds to release gas pressure. 4.
  • Page 20 It is normal that your Fire Table EFV trips if you open the propane tank valve too quickly or if you leave the Fire Table gas knob open before lighting, or both. NIPPLE WITH EXCESS FLOW LIMITING DEVICE (EFV) En-19 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 21 SECTION 4: EXTINGUISHING THE APPLIANCE STEP 1 Access the Fire Table interior. Turn the gas cylinder valve to the ‘Closed’ position. STEP 2 Turn the gas knob on the Fire Table to the ‘OFF’ position by pushing and turning the knob clockwise. STEP 3 Allow unit to cool for at least five (5) minutes before relighting.

  • Page 22: Warning Notes

    • Never leave the Fire Table unattended while in operation. away to avoid burns or clothing ignition. • Children should be supervised at all times when using this unit without exception. En-21 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • MAIN STREET ® D.430.000.V0...
  • Page 23 REMOVING INSECT NESTS STEP 4 Remove the gas valve body assembly. WARNING: STEP 5 Small critters like Use a flashlight to look inside the burner tube. Use a long flexible spiders and earwigs pipe cleaner, or long small utensil to clean out any debris or nest can quickly build nests material.
  • Page 24 Any returns sent back to FMI Brands must be sent via prepaid freight and in the original retail packaging. Please register your OUTLAND Living product for proof of purchase and warranty at https://outlandliving.com/register-products/ For more warranty information and details please contact FMI Brands Inc. at info@outlandliving.com FOR REPLACEMENT PARTS AND ACCESSORIES PLEASE VISIT WWW.OUTLANDLIVING.COM...
