NGCK-AT #510 • AUTO IGNITION + THERMOCOUPLE • INPUT RATING: 50,000 Btu/h
PROPANE TO NATURAL GAS APPLIANCE
APPLIANCE MODELS ACCEPTABLE TO BE USED WITH THIS KIT
TICK
SERIES NAME
OUTLAND FIRE TABLE
WARNING:
This conversion kit shall be installed by a qualified service
agency in accordance with the manufacturer's Instructions
and all applicable codes and requirements of the Authority
Having Jurisdiction. If the information in these instructions
is not followed exactly, a fire, explosion or production of
carbon monoxide may result causing property damage,
personal injury or loss of life. The qualified service agency
is responsible for the proper installation of this kit. The
installation is not proper and complete until the operation
of the converted appliance is checked as specified in the
manufacturer's instructions supplied with the kit.
® Outland Living and the Outland Flame are registered trademarks of FMI Brands Inc.
FIRE TABLE
CONVERSION KIT
NGCK-AT 510 (AUTO IGNITION + THERMOCOUPLE MODELS)
FMI BRANDS INC.
101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5 | Email: info@outlandliving.com
USA, Canada Toll Free: 1-888-514-1663 | Tel: (+1) 778-294-0988
Hours of Operation: 8:30AM - 4:00PM (Pacific Time) | Customer Service in English only
MODEL NUMBERS
FMPPC2E-420
SERIES NUMBERS
420
D.510.000.V2 (English)
Advertisement
Related Manuals for Outland Living 420 Series
Summary of Contents for Outland Living 420 Series
- Page 1 101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5 | Email: info@outlandliving.com USA, Canada Toll Free: 1-888-514-1663 | Tel: (+1) 778-294-0988 Hours of Operation: 8:30AM - 4:00PM (Pacific Time) | Customer Service in English only ® Outland Living and the Outland Flame are registered trademarks of FMI Brands Inc. D.510.000.V2 (English)
- Page 2 2.5 in x 4 in (63.5 mm x 101.6 mm) TAG 1, SIDE 2 • ÉTIQUETTE 1 / CÔTÉ 2 8. Marking and Warning Label - Hang Strap En-2 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E-420 ® TABLE DE FEU OUTLAND FMPPC2E-420...
- Page 3 OUTLAND PROPANE TO NATURAL GAS APPLIANCE CONVERSION KIT MANUAL OUTLAND PART NUMBER: 510 Tested by CSA International NATURAL GAS CONVERSION KIT RATINGS ANS Z21.97-2017/CSA 2.41-2017 Outdoor Decorative Gas Appliances GAS ORIFICE SIZE* 3.5 mm *Injector size marked clearly on the gas valve orifice. MANIFOLD PRESSURE 7 in WC INLET PRESSURE...
- Page 4 Close the valve on the LP (propane) cylinder. b. Disconnect and remove the LP cylinder from the fire table. CLOSE VALVE ON LP (PROPANE) CYLINDER DISCONNECT AND REMOVE LP CYLINDER FROM FIRE TABLE En-4 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E-420 ®...
- Page 5 STEP 3 a. Disconnect the igniter cable. Slide protective cap back to expose the cable connection. Grasp the cable at the base and pull firmly. b. Disconnect the thermocouple cable. Grasp the cable at the base and pull firmly. c. Disconnect the thermocouple ground DISCONNECT THE wire.
- Page 6 Attach the gas knob by aligning the flat side keyway to the flat side of the gas valve stem GAS HOSE IGNITER COUPLING and firmly press-fitting. En-6 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E-420 ®...
- Page 7 STEP 6 (continued) Note: Ensure the arrow on the knob Assemble the natural gas valve (part 2). aligns with the OFF indicator on the valve cover when the valve is set in NATURAL the closed position. To check, push GAS VALVE and turn the knob clockwise until it stops.
- Page 8 If, for some reason, after applying the heat shrink tubing, there are visible gaps or exposed air holes around the venturi connection area, we suggest you use common high heat electrical tape to close those gaps. En-8 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E-420 ®...
- Page 9 STEP 10 WARNING: Attach the natural gas hose (part 4). Pay attention not to cross thread the If the natural gas hose is not preassembled to coupling during tightening. Do not over the natural gas valve, remove the yellow cap tighten.
- Page 10 Low Pressure Low Pressure (.5 PSIG) NG/LP (.5 PSIG) NG/LP supply is Gas Hose with Gas Hose with closed OFF. Quick-Disconnect Quick-Disconnect Inlet Fitting Inlet Fitting En-10 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E-420 ®...
- Page 11 STEP 16 STEP 17 Attach the gas hose Turn on the gas flow from your source valve. to your installed quick-disconnect natural gas source (house line). STEP 18 LEAK TEST: Mix a solution of liquid soap and water in a QUICK- spray bottle and perform a leak test on all DISCONNECT...
- Page 12 For more information about the thermocouple please see section “What is a Thermocouple?”. En-12 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E-420 ®...
- Page 13 STEP 20 (continued) The appliance should light within the first three tries. Never let the gas knob flow open for more than 5 seconds without lighting. If the gas does not ignite within 5 seconds turn off the valve, wait 5 minutes for the gas to dissipate.
- Page 14 Canada V3Z 1A5 • 1.888.514.1663 50 000 TAG 1, SIDE 2 • ÉTIQUETTE 1 / CÔTÉ 2 TAG 2, SIDE 2 • ÉTIQUETTE 2 / CÔTÉ 2 En-14 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E-420 ®...
- Page 15 STEP 21 (continued) IN STRICT COMPLIANCE WITH CSA GUIDELINES, THE RESPONSIBLE PARTY SHALL AFFIX THE MARKING & WARNING LABEL IN CLOSEST PROXIMITY TO EXISTING PRODUCT RATING PLATE, IN A CONSPICUOUS PLASTIC HANG STRAP LOCATION, ON THE APPLIANCE BEING CONVERTED: After Steps A and B above are complete, affix the label on the appliance, using the supplied hang strap, in the location as shown on the applicable model appliance picture below.
-
Page 16: Handle With Care
Should you have any questions or comments regarding this appliance, please do not hesitate to contact FMI Brands Inc. at 1-(888) 514-1663 or e-mail to info@outlandliving.com. FOR REPLACEMENT PARTS AND ACCESSORIES PLEASE VISIT WWW.OUTLANDLIVING.COM En-16 NATURAL GAS CONVERSION KIT - OUTLAND LIVING FIRE TABLE - FMPPC2E-420 ®...
