Model number FMPPC2E-435
Patent Pending. ® Registered trademark of FMI Brands Inc.
The OUTLAND Flame mark is a registered trademark of FMI Brands Inc.
MANUFACTURED BY FMI BRANDS INC. 101 – 3570 194 Street, Surrey, BC, Canada V3Z 1A5
USA, Canada Toll Free: 1-888-514-1663 | Tel: (+1) 778-294-0988 | Email: info@outlandliving.com
Hours of Operation: 8:30AM - 4:00PM (Pacific Time) | Customer Service in English only
OWNER'S MANUAL
FRASER
FIRE TABLE
NOTICE : THIS
PRODUCT CONTAINS A
THERMOCOUPLE SAFETY
DEVICE WHICH SHUTS
OFF THE GAS. PLEASE
READ THE INSTRUCTIONS
CAREFULLY TO
UNDERSTAND HOW IT
WORKS.
D.435.000.V0
Advertisement
Table of Contents
Related Manuals for Outland Living FRASER FMPPC2E-435
Summary of Contents for Outland Living FRASER FMPPC2E-435
- Page 1 OWNER’S MANUAL FRASER FIRE TABLE NOTICE : THIS PRODUCT CONTAINS A THERMOCOUPLE SAFETY DEVICE WHICH SHUTS OFF THE GAS. PLEASE READ THE INSTRUCTIONS CAREFULLY TO UNDERSTAND HOW IT Model number FMPPC2E-435 WORKS. Patent Pending. ® Registered trademark of FMI Brands Inc. The OUTLAND Flame mark is a registered trademark of FMI Brands Inc.
- Page 2 CONSUMER: Retain this manual for Installation and service must be performed by a future reference. qualified installer, service agency, or the gas supplier. En-1 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0...
- Page 3 Indoor storage of this appliance is permissible only if the cylinder is WARNING: disconnected and removed from the appliance. Cylinders must be stored outdoors in a well-ventilated area out of Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the reach of children.
- Page 4 6. The leak(s) must be stopped by tightening the loose joints, if possible, or by replacing the faulty parts(s) with the part(s) recommended by the appliance manufacturer. En-3 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0...
- Page 5 LP gas supply must be shut off at the cylinder valve or the cylinder Only use a replacement hose by OUTLAND Living. must be removed from the appliance until the leak(s) is corrected.
-
Page 6: Table Of Contents
Required Tools (Not Supplied): • Cross (Phillips) Screw Driver (PH2 and PH3) Post A Post B Gas Valve, Gas Hose and Regulator Mounting Bracket Assembly Cross Bars En-5 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0... -
Page 7: Assembly Work 1 Surface
SECTION 1: ASSEMBLY STEP 1: DEFINE YOUR WORKING AREA Lay the Tabletop on a flat non-marking surface. TIP: Use cardboard provided in packing box as a work surface. Tabletop (part 2) Assembly Work Surface (Top Packing Insert) (part 1) STEP 2: BUILD THE TABLETOP ASSEMBLY Slots 2.1 –... - Page 8 (with integral split lock washers and flat washers). & flat washers) Tighten Firmly. 2.4 – Complete the Tabletop Assembly. Repeat Steps 2.2-2.3 to attach the second Tabletop Side. Fasten screws firmly. En-7 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0...
-
Page 9: Front Panel
SECTION 1: ASSEMBLY (continued) STEP 3A: ASSEMBLE LEG POSTS TO THE FRONT PANEL Identify (2) Post A and (2) Post B. IMPORTANT! Note the direction of Post B the pins on Post (pin on left hand side) A and B during installation. -
Page 10: Gas Valve, Gas
The gas valve orifice should be inside the burner tube and visible through the bug screen mesh. If your orifice and burner tube does not line up like in the image above, please call customer service. En-9 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ®... - Page 11 SECTION 1: ASSEMBLY (continued) STEP 5C STEP 5B Connect the round thermocouple cable to the thermocouple socket. Connect the igniter cable to the gas valve igniter. NOTE THE SMALL HOSE THERMOCOUPLE SOCKET RECTANGULAR CONNECTION ROUND THERMOCOUPLE CABLE GAS VALVE IGNITER MAKE SURE THE SILICONE COVER ON THE IGNITER CABLE...
- Page 12 Do not fully tighten the screws. Leave at least 3 mm (1/8”) gap between the screw head and the Post. M4x10 Screws 3 mm (1/8”) En-11 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0...
- Page 13 SECTION 1: ASSEMBLY (continued) STEP 8: ASSEMBLE THE SIDE PANELS TO THE POSTS Using the U-slots Make sure the two screw on the Side Panels, holes in the middle are hang the Side aligning with the screw Panels between holes on the Posts. the front and back Posts.
-
Page 14: Propane Cylinder
Once all connections are verified to be secure, place the propane cylinder in the Propane Cylinder H-Frame Support ring. Hand tighten the cylinder collar to affix cylinder. Removable Rear Panel Detail A Tighten cylinder collar En-13 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0... - Page 15 SECTION 1: ASSEMBLY (continued) STEP 15: GLASS ROCKS ASSEMBLY Open bag of Glass Rocks and arrange neatly and evenly in the burner tray. Ensure igniter cover is not covered by glass rocks (see photo). This helps air circulate. Take care to keep rocks out of the igniter cover.
- Page 16 CSA excess flow safety device in the gas regulator. For more information about the CSA excess flow safety device see Section 3. STEP 6 Leak Test all connections. See section labeled “Leak Test”. En-15 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0...
- Page 17 SECTION 2: IGNITION (continued) STEP 7: IGNITION WITH THERMOCOUPLE PUSH THE KNOB IN AND QUICKLY TURN TO Your Fire Table is equipped with an auto spark ignition (piezo ignition) and 12:00 POSITION. DO NOT thermocouple. RELEASE THE GAS KNOB FOR 10 SECONDS. IMPORTANT: •...
- Page 18 ARE FIRMLY ATTACHED TO THE CORRECT SOCKETS CLEAN THE THERMOCOUPLE TIP MAKE SURE THE AND IGNITER TIP SILICONE COVERS ARE PRESSED UP AGAINST THE GAS VALVE CONNECTION En-17 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0...
- Page 19 SECTION 3: TROUBLESHOOTING (continued) STEP 2 Wait until the glass rocks are cool, or wait 5 minutes for any gas to dissipate, whichever is longer. Turn the gas cylinder valve to the ‘Closed’ position. Open the fire table gas knob control for 3 seconds to release gas pressure. Close gas knob.
- Page 20 It is normal that your Fire Table EFV trips if you open the propane tank valve too quickly or if you leave the Fire Table gas knob open before lighting, or both. NIPPLE WITH EXCESS FLOW LIMITING DEVICE (EFV) En-19 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0...
- Page 21 SECTION 4: EXTINGUISHING THE APPLIANCE STEP 1 Access the Fire Table interior. Turn the gas cylinder valve to the ‘Closed’ position. STEP 2 Turn the gas knob on the Fire Table to the ‘OFF’ position by pushing and turning the knob clockwise. STEP 3 Allow unit to cool for at least five (5) minutes before relighting.
- Page 22 • Never leave the Fire Table unattended while in operation. away to avoid burns or clothing ignition. • Children should be supervised at all times when using this unit without exception. En-21 OWNER & SAFETY MANUAL • OUTLAND LIVING • FIRE TABLE • FRASER ® D.435.000.V0...
- Page 23 REMOVING INSECT NESTS STEP 4 Remove the gas valve body assembly. WARNING: STEP 5 Small critters like Use a flashlight to look inside the burner tube. Use a long flexible spiders and earwigs pipe cleaner, or long small utensil to clean out any debris or nest can quickly build nests material.
- Page 24 Any returns sent back to FMI Brands must be sent via prepaid freight and in the original retail packaging. Please register your OUTLAND Living product for proof of purchase and warranty at https://outlandliving.com/register-products/ For more warranty information and details please contact FMI Brands Inc. at info@outlandliving.com FOR REPLACEMENT PARTS AND ACCESSORIES PLEASE VISIT WWW.OUTLANDLIVING.COM...
