- Page 1 VEO-MXH44D MATRIXES HDMI 4x4 18Gbps Matrix with Audio De-embedders USER MANUAL 50-0431-0103 VEO-MXH44D...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS ..........................3 1.1 Important Remark ........................3 1.2 Important Safety Instructions ....................4 1.3 Cleaning............................4 PACKAGE CONTENTS ....................... 5 DESCRIPTION & FEATURES ..................... 5 3.1 Main Features ..........................6 INSTALL & CONNECT ......................... 6 START-UP & OPERATION ......................7 5.1 LCD Display control menu ....................... -
Page 3: Precautions
1. PRECAUTIONS Important Remark The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 4: Important Safety Instructions
1.2 Important Safety Instructions Read these instructions. 12. Unplug the device during lightening sorts or when unused for long 2. Keep these instructions. periods of time. 3. Heed all warnings. Refer all servicing to qualified 4. Follow all instructions. personnel. Servicing is required 5. -
Page 5: Package Contents
• Warranty card. 3. DESCRIPTION & FEATURES VEO-MXH44D is a 4x4 HDMI matrix that supports up to 4K/UHD video resolution at 60 Hz with 4:4:4 chroma sampling. It features 8 analogue and digital audio de-embedding outputs, along with EDID management, an LCD display, and an integrated web GUI, providing a user- friendly configuration and control interface. -
Page 6: Main Features
3.1 Main Features • It has 4 HDMI inputs that can be independently routed to 4 HDMI outputs. • Supports HDMI up to 4K @ 60Hz, YUV 4:4:4 8-bit, HDR (at 4K @ 60Hz YUV 4:2:0 10-bit). • Supports Full HD video downscaling. •... -
Page 7: Start-Up & Operation
5. START-UP & OPERATION The unit can be controlled and configured by following the steps indicated below. In addition, if you prefer, it can also be configured by the WebGUI. 5.1 LCD Display control menu • To operate through the different menus, please use: o UP/DOWN buttons of the front panel or ▲/▼... -
Page 8: Video Switching Control
5.2 Video Switching Control The signal switch includes 4 free switching channels, which can be configured as input/output according to the requirements, forming a matrix of 1 x 4 ~ 4 x 1, which can switch any input signal to a single output or simultaneously to all outputs. •... -
Page 9: Output Signal Control
5.3 Output Signal Control This section allows to manage each of the 4 output signals. 5.3.1 Output Video Control This section allows you to control the operation of the video features of each of the 4 output signals. 5.3.1.1 Switching Switch any output to one input or switch all outputs to one input. -
Page 10: Output Audio Control
5.3.1.2 On/Off Video signal can be switched on and off on any output selected. By default, the output video is set to be active. Select “Output” in the menu and press “ENTER”. Then use “UP/▲ or DOWN/▼” button to select “output 1~4” or “All” (“All” means all outputs). - Page 11 A. HDMI audio support B. De-Embed This parameter allows to turn on and off the audio extraction. Select "Audio" from the main menu and press "ENTER". Use the “UP/▲ or DOWN/▼” button to choose "De-Embed" and press "ENTER". The selected option will be highlighted in white. Use the “UP/▲...
-
Page 12: Input Signal Control
5.4 Input Signal Control This section allows to operate the features of each one of the 4 input signals. Select “Input” and press “ENTER”. Press “UP/▲ or DOWN/▼” button to select “Input1~4”· or “All” (“All” means all inputs). The selected input will be highlighted in white. Press “ENTER”. Press “UP/▲... -
Page 13: Presets Configuration
5.5 Presets Configuration This section enables to save the settings for Video, Audio, EDID, and System in 8 different presets to effectively manage and customize your own settings. Following actions can be performed for each preset: • Clear: Delete a saved preset to free up the preset slot for future use. •... -
Page 14: Configuration
5.6 Configuration This section allows to configure general settings. A. Network (DHCP switch) This section allows to enable DHCP for network configuration. • DHCP On: dynamic IP address • DHCP Off: static IP address (by default) To change the DHCP setting: 1. - Page 15 B. RS-232 (Baud rate) This section allows to adjust the serial baud rate. 1. From the main menu, select "Setup" and press "ENTER". 2. Press “UP/▲ or DOWN/▼” button to choose "Baud". 3. Press "ENTER" to enter the sub-menu. 4. Press “UP/▲ or DOWN/▼” button to select the desired baud rate, such as "9600". 5.
- Page 16 D. System Allows to set device's Reboot, Timing switch and Factory data reset. 1. Select “Config”, press “ENTER”. 2. Press “UP/▲ or DOWN/▼” button to select “System”, press “ENTER”. 3. Press “UP/▲ or DOWN/▼” button to select: • Reboot: select Yes or No. •...
-
Page 17: Info
VEO-MXH44D can be remotely controlled over RS-232 or TCP/UDP communications protocol. For RS-232 serial communication: enter the selected parameters on Series Port Setting • chapter. For TCP/UDP communication: enter the current VEO-MXH44D IP address and Port: • 5000 for TCP or 5001 for UDP commands. -
Page 18: Series Port Setting
Stop bits 1 Parity None Flow control None For a correct communication, both the host PC and VEO-MXH44D need to have the same baud rate amongst the available options. 5.8.2 Command List • All commands start with “#” • “_” the underline cannot be omitted. - Page 19 Enable or disable ARC audio on channel [x] PARAMETER DESCRIPTION #audio_d output=[x] arc=[y] <Output[x] : Audio ARC> [Data=[y-1] : Input [y]] • [x]: Output channel number, from 1 to 8. If [x]=0, all outputs • [y]: enable or disable ARC ON = 1 OFF = 0 Copy the EDID of the parameter (“mode [y]”)
- Page 20 Increase or decrease the return time to the main menu of the LCD screen PARAMETERS DESCRIPTION #lcd home_time=:[x] New LCD home wait: [x] [x]: • 0-254 = Return time to the main menu • 255 = always fixed in the part of the menu that has been selected Lock or unlocks front panel buttons PARAMETERS DESCRIPTION...
-
Page 21: Webgui
6. WebGUI The unit can be controlled and configured by its own built-in web interface by simply typing the IP address of the chosen device into a web browser. 6.1 Change IP address of PC Before configuring the device through the website, it is necessary to configure the IP address of your computer to be in the same network segment as the device. -
Page 22: Login By Browser
6.2 Login by Browser To access VEO-MXH44D WEB settings, it is necessary to enter the base unit IP address in an internet browser. • Default IP address: 192.168.1.168 • Default username: admin • Default password: admin 6.3 Status This section allows to check the status of several device settings. -
Page 23: Input
6.4 Input This section allows to rename input ports, switching video signals (opened by default), switching audio input, selecting EDID, and switching audio source signals. Rename: Modify the current name of input port, support 1~15 characters (numbers, • letters and underscores) which is synchronized with the screen. Apply: Applies the name changes. - Page 24 3. User EDID selection: Click the whitebox, select EDID, then select user1 ~ 4 in the box, and finally click apply. Click browse and select the path where the bin file is located, then select user1 ~ 4 in the box and finally click Upload. The EDID can be imported into user EDID.
-
Page 25: Output
6.5 Output This section allows to port renaming, switching output video (on by default), switching audio output (HDMI/Analog/SPDIF), ARC function (off by default). • Rename: Modify the current name of output port, support 1~15 characters (numbers, letters and underscores). • Apply: Applies the name changes. •... -
Page 26: Matrix
6.6 Matrix This section allows to display the input source corresponding to the current output port, Switching the input to an output port and output the image. The vertical axis indicates the selection of the input port, the horizontal axis indicates the selection of the output port, and “All”... -
Page 27: Preset
6.7 Preset Use this option to rename, saving, calling, and clearing of preset scene. The device can preset 8 scenes and support scene renaming. Clear means clears the current saved scene. • Save means save the current changed scene, the video, audio and system settings can be •... -
Page 28: Settings
DHCP and Gray means close DHCP). TCP port: Configure port (5000 by default) to access VEO-MXH44D. • UDP Port: Configure the port (5001 by default) to access VEO-MXH44D. • Account management: enter your account and password in the white box, Click Apply. -
Page 29: Firmware Upgrade
7. FIRMWARE UPGRADE To update the MCU and web page using the updating software, follow these steps: Connect your PC and the device using the RS-232 cable. Open the updating software on your PC. Click on the "Refresh" button to refresh the serial port list and select the correct serial port number for the device. -
Page 30: Panels & Remote Functions
8. PANELS & REMOTE FUNCTIONS 8.1 Front Panel IR receiver window. PRESET: short press to preset. Output 1-4: UP: short press to up. o short press to choose one LOCK: long press to lock, long press output, press again to cancel. again to unlock；when lock, all button is unworkable except for lock o long press to choose all output,... -
Page 31: Rear Panel
o Rear Panel Analogue audio out Ethernet port S/PDIF audio out DC12V/2A input RS-232 control HDMI output port IR-Ext HDMI input port... -
Page 32: Remote Control
8.2 Remote Control 1. Power on / Standby 2. M: Turn off the HDMI output audio 3. W: Lock or Unlock panel buttons. 4. Output 1-8 5. All outputs select INPUT-Y: o Press ALL button o Press INPUT-Y button means 1 to 4 of the inputs). 6. - Page 33 • Turn off HDMI output audio: o To mute the audio for a specific output, press the corresponding output button followed by the "M" button. o For example, to turn off the audio for output 1, press output 1 button followed by the "M"...
-
Page 34: Technical Data
RGB, YUV HDCP HDR10, Dolby Vision, HLG HDMI Distance 10m with Ecler VEO Cables (up to 1080p) 5m with Ecler VEO Cables (up to 4K) Audio Performances Audio Output Connectors 4 x 3 pin Euroblock connector, 4 x Coaxial Digital Out... -
Page 35: Mechanical Diagram
Physical Operating Temperature Min: 0°C; 32°F Max: 40°C; 104°F Operating Humidity <90% HR Installation Options Desktop Included Accessories 5 x 3 pin Euroblock connector, 1 x Remote Control, 1 x IR receiver, 1x 12V PSU Dimensions (WxHxD) 217.4 x 35 x 128.7 mm. / 8.56 x 1.38 x 5.07 in. Shipping Dimensions (WxHxD) 310 x 85 x 264 mm / 12.20 x 3.35 x 10.39 in. - Page 36 NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. For technical queries contact your supplier, distributor or complete the contact form on our website, Support / Technical requests. Motors, 166‐168 08038 Barcelona, Spain (+34) 932238403 information@ecler.com www.ecler.com...
