- Page 1 VEO-MXH48T MATRIXES 4K HDBaseT and HDMI 8x8 Matrix USER MANUAL 50-0449-0100 VEO-MXH48T...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS ..........................3 Important Remark ........................3 Important Safety Instructions ....................4 Cleaning ............................4 WARRANTY & ENVIRONMENT ....................5 PACKAGE CONTENTS ....................... 5 DESCRIPTION & FEATURES ..................... 6 Main Features ........................... 6 INSTALL & CONNECT ......................... 7 START-UP &... -
Page 3: Precautions
1. PRECAUTIONS Important Remark The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 4: Important Safety Instructions
1.2 Important Safety Instructions Read these instructions. 12. Unplug the device during lightening sorts or when unused for long 2. Keep these instructions. periods of time. 3. Heed all warnings. Refer all servicing to qualified 4. Follow all instructions. personnel. Servicing is required 5. -
Page 5: Warranty & Environment
Recycling materials and using non-contaminant components are also top priorities in our green crusade. Ecler has deeply evaluated and analyzed the environmental impacts of all the processes involved in the production of this product, including packaging, and has alleviated, reduced and/or compensated for them. -
Page 6: Description & Features
4. DESCRIPTION & FEATURES VEO-MXH48T is an 8x8 HDBaseT and HDMI matrix with support for up to 4K/UHD video resolution, 60 Hz and 4:4:4 chroma sampling. It includes 8 analogue audio inputs and 16 analogue and digital audio de-embedding outputs as well as EDID management, an LCD display and an integrated WebGUI that allows to configure and control the unit in a very user friendly way. -
Page 7: Install & Connect
5. INSTALL & CONNECT... -
Page 8: Start-Up & Operation
6. START-UP & OPERATION The unit can be controlled and configured by following the steps indicated below. In addition, if you prefer, it can also be configured by the WebGUI. 6.1 LCD Display control menu • To operate through the different menus, please use: o UP/DOWN buttons of the front panel or ▲/▼... -
Page 9: Video Switching Control
6.2 Video Switching Control The signal switch includes 8 free switching channels, which can be configured as input/output according to the requirements, forming a matrix of 1 x 8 ~ 8 x 1, which can switch any input signal to a single output or simultaneously to all outputs. •... -
Page 10: Output Signal Control
6.3 Output Signal Control This section allows to control the Output signal (Audio or Video) of each one of the 8 output signals. 6.3.1 Output Video Control This section allows you to control the operation of the video features of each of the 8 output signals. - Page 11 6.3.1.2 On/Off Video signal can be switched on and off on any output selected. By default, the output video is set to be active. Select “Output” in the menu and press “ENTER”. Then use “UP/▲ or DOWN/▼” button to select “output 1~8” or “All” (“All” means all outputs).
-
Page 12: Output Audio Control
6.3.2 Output Audio Control This section allows to enable/disable the output audio of each one of the 8 signals. A. Source This parameter allows to turn on and off the HDMI audio output signal 1. Select "Audio" from the main menu and press "ENTER". 2. -
Page 13: Input Signal Control
6.4 Input Signal Control This section allows to operate the features of each one of the 8 input signals. Select “Input” and press “ENTER”. Press “UP/▲ or DOWN/▼” button to select “Input1~8”· or “All” (“All” means all inputs). The selected input will be highlighted in white. Press “ENTER”. Press “UP/▲... - Page 14 Press “UP/▲ or DOWN/▼” button to adjust the selected item according to your choice. symbol appears next to the selected value as a confirmation of the selection and EDID details (Name, Max resolution, audio format, soundtrack) will appear next to the chosen option. B.
-
Page 15: Presets Configuration
6.5 Presets Configuration This section enables to save the settings for Video, Audio, EDID, and System in 8 different presets to effectively manage and customize your own settings. Following actions can be performed for each preset: • Clear: Delete a saved preset to free up the preset slot for future use. •... -
Page 16: Configuration
6.6 Configuration This section allows to set the device's Network parameter, RS-232 baud rate, and System parameters as well. A. RS-232 Allows to change device’s baud rate. Device’s baud rate provides 6 choices, 115200, 57600, 38400, 19200, 9600, 4800. The device is 115200 by default. 1. - Page 17 Press “UP/▲ or DOWN/▼” button to select “Network”, press “ENTER”. Press “UP/▲ or DOWN/▼” button to select DHCP and choose between “Yes/No” to turn on/off DHCP. Press “ENTER”, and the current network parameters will be displayed. Press “MENU”, to return to the previous menu, and then press “UP/▲ or DOWN/▼”...
-
Page 18: Info
4. Press “UP/▲ or DOWN/▼” button to adjust the selected item according to your choice. 5. Press “MENU”, to return to the previous menu, and then press “UP/▲ or DOWN/▼” button to select the other items. Press “ENTER”. 6. Press “UP/▲ or DOWN/▼” button to adjust the selected item according to your choice. -
Page 19: Remote Controlling
Press “ENTER” and with “UP/▲ or DOWN/▼” select the item you want to check. Press “MENU”, to return to the previous menu, and then press “UP/▲ or DOWN/▼” button to select the other items. Press “ENTER”. Press “UP/▲ or DOWN/▼” button to select item according to your choice. symbol appears next to the selected value as a confirmation of the selection. -
Page 20: Command List
6.8.2 Command List • All commands start with “#” • “_” the underline cannot be omitted. • Command head, Parameter and target need to add one “SPACE”. Command Code Description Command Return Switches Video Input channel [x] to Output channel [y] #video_d input=[x] output=[y] PARAMETERS DESCRIPTION <Output[x] : Video source>... - Page 21 Audio switch between the selected channel output [x] and channel input [y] <Output[x] : Audio Source> [Data=[y-1] : Input PARAMETERS DESCRIPTION #audio_d output=[x] source=[y] • [x]: Output channel number, ranging from [y]] 1 to 8. If [x]=0, all output • [y]: Input channel number, ranging from 1 to 8.
- Page 22 Increase or decrease the return time to the main menu of the LCD screen PARAMETERS DESCRIPTION #lcd home_time=[x] New LCD home wait: [x] [x]: • 0-254 = Return time to the main menu • 255 = always fixed in the part of the menu that has been selected Lock or unlocks front panel buttons #lock onoff=[x]...
-
Page 23: Webgui
7. WebGUI The unit can be controlled and configured by its own built-in web interface by simply typing the IP address of the chosen device into a web browser. 7.1 Change IP address of PC Before configuring the device through the website, it is necessary to configure the IP address of your computer to be in the same network segment as the device. -
Page 24: Login By Browser
7.2 Login by Browser To access VEO-MXH48T WEB settings, it is necessary to enter the base unit IP address in an internet browser. • Default IP address: 192.168.1.168 • Default username: admin • Default password: 123456 It is recommended to use Google, Firefox, IE8 and above browsers. Using other browsers may not be compatible 7.3 Status This section allows to check the status of several device settings. -
Page 25: Input
7.4 Input This section allows to rename input ports, switching video signals (opened by default), switching audio input, selecting EDID, and switching audio source signals. Rename: Modify the current name of input port, support 1~15 characters (numbers, • letters and underscores) which is synchronized with the screen. Press the “Apply” button to save changes. -
Page 26: Output
7.5 Output This section allows to output port renaming, switching output video (on by default), switching De-Embed (on by default) and Audio-Source selection (audio follow video by default). • Rename: Modify the current name of output port, support 1~15 characters (numbers, letters and underscores) which is synchronized with the screen. -
Page 27: Edid Control Management
7.6 EDID Control Management The device includes 4 EDID modes: Default EDID, User EDID, Output EDID, Temp1, control EDID by WEB and RS-232. Factory Default: Default1 4K60 444 2CH. Refer to the EDID management commands in the table below. Instructions are as follows: Send instruction: “#edid_d input=1 mode=1 data=2”. -
Page 28: Matrix
7.7 Matrix This section allows to display the input source corresponding to the current output port, Switching the input to an output port and output the image. The vertical axis indicates the selection of the input port, the horizontal axis indicates the selection of the output port, and “All”... -
Page 29: Preset
7.8 Preset Use this option to rename, saving, calling, and clearing of preset scene. The device can preset 8 scenes and support scene renaming. Clear means clears the current saved scene. • Save means save the current changed scene, the video, audio and system settings can be •... -
Page 30: Settings
7.9 Settings This section allows to modify and show network parameters and control protocol parameters TCP/UDP, modify web login account and password, reboot device, general restore factory, user restore factory. Mac address can only be displayed. It cannot be modified. •... -
Page 31: Firmware Upgrade
8. FIRMWARE UPGRADE To update the MCU and web page using the updating software, follow these steps: Connect your PC and the device using the RS-232 cable (connect to the RS-232 port named FW). Open the updating software on your PC. Click on the "Refresh"... -
Page 32: Panels & Remote Functions
9. PANELS & REMOTE FUNCTIONS 9.1 Front Panel LCD screen UP: briefly press to move up through the menu on the screen. IR receiver window LOCK: long press to lock, long press Output buttons from 1 to 8: again to unlock；when lock, all •... -
Page 33: Rear Panel
9.2 Rear Panel AUDIO IN (Analogue x8) Power On/Off IR out port x8 & All out 100-240 V AC @ 50-60Hz input. IR in port x8 & All in Grounding AUDIO OUT (Analogue x8; SPDIF x8) 10. HDMI Output×8 RS-232 port x2 (one for pass through, 11. -
Page 34: Remote Control
9.3 Remote Control 1. Power on / Standby 2. M: Turn off the HDMI output audio 3. W: Lock or Unlock panel buttons. 4. Output 1-8 5. All outputs select INPUT-Y: o Press ALL button o Press INPUT-Y button means 1 to 4 of the inputs). - Page 35 • Lock remote control: o To lock the remote control, press the "W" button. This will prevent any further input from the remote control. o To unlock the remote control, short press the "W" button again. • Turn off output channel: To turn off a specific output channel, press the corresponding output button followed by the "X"...
-
Page 36: Ir System
9.4 IR System The matrix can pass the IR signal through the IR system to the HDMI source or pass the IR signal from the HDMI source to the HDMI sink Dual way IR using: • IR IN is for HDBaseT output, “IR OUT” is for input channel •... -
Page 37: Technical Data
10. TECHNICAL DATA 10.1 Technical Specifications VEO-MXH48T Video Performances Video Input Connectors HDMI Type A Female, 18 Gbps Video Output connectors HDMI Type A Female, 18 Gbps Video Input Resolution Input support 3840x2160/60 YUV444 HDMI Video Output Resolution Output support 3840x2160/60 YUV444 HDMI ... -
Page 38: Mechanical Diagram
Dimensions (WxHxD) 482.6x88x394 mm / 19x3.46x15.51 in Shipping Dimensions (WxHxD) 530x190x570 mm / 20.87x7.48x22.44in. Weight 8.3 Kg / 18.30 lb Shipping Weight 10.9 Kg / 24.03 lb Chassis Material Metal Finished Colour Black 10.2 Mechanical Diagram All measurements are in mm. - Page 39 NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. For technical queries contact your supplier, distributor or complete the contact form on our website, Support / Technical requests. Motors, 166‐168 08038 Barcelona, Spain Tel. (+34) 932238403 information@ecler.com www.ecler.com...
