Wi-Fi HaLow™ Access Point
AP-150AH
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HaLow AP-150AH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Silex technology HaLow AP-150AH

Summary of Contents for Silex technology HaLow AP-150AH

  • Page 1 Wi-Fi HaLow™ Access Point AP-150AH User's Manual...
  • Page 2 Copyright© 2024 Silex Technology, Inc. All rights reserved. WA108190XX...

  • Page 3: Table Of Contents

    Index 1. Introduction ................1 1-1. Introduction ............................2 1-1-1. About the Notation ........................2 1-1-2. Disclaimers .............................2 1-1-3. Trademarks .............................2 1-1-4. Glossary ............................3 1-2. Safety Instructions ..........................5 1-3. Notes on Usage .............................9 1-3-1. Use of Radio Waves ........................9 1-3-2. Notes on Security ........................10 1-3-3.
  • Page 4 3-4-2. Displaying a Web Page by Using AMC Manager® ............38 3-5. Configuration Using AMC Manager®..................40 3-5-1. Create Configuration File ....................... 40 3-5-2. Apply Configuration File ......................42 4. Establishing Network for Long Distance Transfer ....46 4-1. Changing Network Settings ......................47 4-2.
  • Page 5 6-3-1. Initialization Using the Push Switch on AP-150AH ............78 6-3-2. Initialization from the Web Page ..................79 A. List of All Settings ..............80 A-1. Device Configuration ........................81 A-2. 900MHz AP ............................83 A-2-1. 900MHz AP ..........................83 A-2-2.

  • Page 6: Introduction

    AP-150AH User's Manual 1. Introduction Introduction Thank you for purchasing the Access Point "AP-150AH". This manual provides information on how to configure and use AP-150AH. Please read the 1-2. Safety Instructions carefully before using AP-150AH.

  • Page 7: Introduction

    OS version upgrades, modifications, and other changes. - Although every effort was made to prepare this manual with the utmost accuracy, Silex Technology will not be held liable for any damages as a result of errors, setting examples, or other content.

  • Page 8: Glossary

    AP-150AH User's Manual 1. Introduction 1-1-4. Glossary The following explains the technical terms used in this manual. Please refer to this as you read this manual. Terms Explanation Web Page AP-150AH's Web interface to use for configuration. Name of the device that the users can specify. Host Name The initial value is set based on the MAC address, but the users can change to make it easier to identify and manage.
  • Page 9 AP-150AH User's Manual 1. Introduction Terms Explanation This is the frequency range to use for wireless LAN. Each channel is 20MHz for the 2.4GHz and 5GHz bands, and 1MHz for the 900MHz band. Bandwidth Setting a large value for the bandwidth will increase the amount of data that can be communicated at once, and will enable high-speed communication.

  • Page 10: Safety Instructions

    AP-150AH User's Manual 1. Introduction 1-2. Safety Instructions This page provides the safety instructions for safe use of AP-150AH. To ensure safe and proper use, please read the following information carefully before using AP-150AH. The safety instructions include important information on safe handling of AP-150AH and on general safety issues.

  • Page 11: Product Installation

    AP-150AH User's Manual 1. Introduction Product installation Warning * Do not place any objects on top of AP-150AH. It may cause fire, electrical shock or malfunction. * Do not cover or wrap AP-150AH with cloth such as blankets or tablecloths. Accumulated heat may cause fire, accident, or malfunction.
  • Page 12 AP-150AH User's Manual 1. Introduction Measures for abnormal operations Warning * In the following cases, turn off the connected device and remove the power supply cable or plug. Failure to follow these instructions may cause fire or an electrical shock. - When AP-150AH emits a strange smell, smoke or sound or becomes too hot to touch.
  • Page 13 * When removing AP-150AH, be sure to unplug the power supply cable and power plug of both AP-150AH and the connected device beforehand. * Be sure to use the AC adapter specified by Silex Technology. Failure to do so may cause malfunction.

  • Page 14: Notes On Usage

    AP-150AH User's Manual 1. Introduction 1-3. Notes on Usage 1-3-1. Use of Radio Waves If there is reinforced concrete/metal between wireless devices, they may not connect AP-150AH can connect through wood or glass, but may have troubles connecting through reinforced concrete/metal.

  • Page 15: Notes On Security

    AP-150AH User's Manual 1. Introduction 1-3-2. Notes on Security Because a wireless LAN uses electromagnetic signals instead of a LAN cable to establish communication with network devices, it has the advantage of allowing devices to connect to the network easily. However, a disadvantage of this is that within a certain range, the electromagnetic signals can pass through barriers such as walls, and if security countermeasures are not implemented in some way, problems such as the following may occur.

  • Page 16: Standards Compliance

    (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Silex Technology America, Inc. https://www.silextechnology.com/ FCC Rules Part 15 FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 17 AP-150AH User's Manual 1. Introduction antenna or transmitter. FCC Rules Part 15 Subpart C §15.247 and Subpart E This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.
  • Page 18 AP-150AH User's Manual 1. Introduction Type d’antenne Gain l'impédance 900MHz : 3 , 4dBi Antenne à tige(X9000984-4GDSMB) 50Ω RSS-102 Issue 5 §2.6 This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the ISED radio frequency (RF) Exposure rules. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.

  • Page 19: About Ap-150Ah

    AP-150AH User's Manual 2. About AP-150AH About AP-150AH...

  • Page 20: Image Of Using Ap-150Ah

    AP-150AH can connect up to 30 IEEE 802.11ah wireless station devices to establish the network with a long communication distance. If the Silex Technology’s EX-150AH is used together, data of 2.4/5GHz wireless station devices can be transferred over a long distance.

  • Page 21: Features

    AP-150AH can be mounted on a wall using Bracket Type VI (optionally available) . Unified device management utility "AMC Manager®" AMC Manager® provides the following functions. - Remote control and monitoring - Bulk configuration and version update - For details on AMC Manager®, please visit the Silex Technology's website. Note...

  • Page 22: Parts And Functions

    AP-150AH User's Manual 2. About AP-150AH 2-3. Parts and Functions External Dimensions Unit: mm *) Reference dimensions...
  • Page 23 AP-150AH User's Manual 2. About AP-150AH Parts and Functions (1) DC connector Connect the power supply cable. PIN Number Signal Name Description DC 12V-24V DC connecter : S03B-PASK-2 (JST) To connect to this connector, please use JST PAP-03V-S. (2) DC connector (USB Type-C) This is a USB Type-C power connector.
  • Page 24 AP-150AH User's Manual 2. About AP-150AH (5) LED 4 (Orange) (6) LED 5 (Green) Shows the Wired LAN device connection status. LED 4 LED 5 Explanation Connected in 100BASE -TX network Connected in 10BASE -T network device Wired LAN is not connected.
  • Page 25 AP-150AH User's Manual 2. About AP-150AH (7) LED 1 (POWER) The meaning of the LED status is as follows. Color Light Explanation Green Powered on Powered off (8) LED 2 (IEEE 802.11ah wireless LAN) The meaning of the LED status is as follows. Color Light Explanation...
  • Page 26 AP-150AH User's Manual 2. About AP-150AH (9) LED 3 (Wired LAN) The meaning of the LED status is as follows. Color Light Explanation Has connected to the wired LAN device Green An IP address has been assigned. Has connected to the wired LAN device Orange An IP address has been assigned.
  • Page 27 AP-150AH User's Manual 2. About AP-150AH Default SSID : silex-ah-150-conn Key : LetMeConnect_SX150AH Authentic : WPA3-Personal E/A : XXXXXXXXXXXX S/N : YYYYYYYYY (10) (10) Product label The following settings are described. Default SSID SSID for 900MHz band Pre-Shared Key Authentic Authentication mode MAC address of AP-150AH The format of MAC address is "E/A: 1CBCECXXXXXX".

  • Page 28: Specifications

    AP-150AH User's Manual 2. About AP-150AH 2-4. Specifications 2-4-1. Hardware Specifications Push Switch LED 1 (Green/Orange/Red) LED 2 (Green/Orange/Red) LED 3 (Green/Orange/Red) LED 4 (Orange) LAN Port LED 5 (Green) DC connector Operating voltage DC12V to DC24V Power supply USB Type-C connector Operating voltage DC5V Temperature -20 °C to 40 °C...
  • Page 29 AP-150AH User's Manual 2. About AP-150AH Wireless network interface Bandwidth 900MHz 903.5, 904.5, 905.5, 906.5, 907.5, 908.5, 909.5, 910.5, 911.5, 912.5, 913.5, 914.5, 915.5, 916.5, 1MHz bandwidth 917.5, 918.5, 919.5, 920.5, 921.5, 922.5, 923.5, IEEE 802.11ah 924.5, 925.5, 926.5 Channel 905.0, 907.0, 909.0, 911.0, 913.0, 915.0, 917.0, 2MHz bandwidth 919.0, 921.0, 923.0, 925.0...

  • Page 30: Software Specifications

    AP-150AH User's Manual 2. About AP-150AH 2-4-2. Software Specifications Network layer ICMP Transport layer TCP/IP DHCP(Client/Server) HTTP/HTTPS(Server) Application layer DNS(Client) TFTP SXSMP Microsoft Edge Recommended Web browser Google Chrome...

  • Page 31: Power Supply

    AP-150AH User's Manual 2. About AP-150AH 2-5. Power Supply AP-150AH can receive electrical power in the following two ways: - Power supply (DC 12V to 24V) - USB Type-C connector Sample connection1: When using a power supply Connect the power supply cable to the DC connector of AP-150AH. Sample connection2: When using a USB Type-C power connector Connect the USB Type-C power connector to the USB Type-C connector of AP-150AH.

  • Page 32: Optional Utilities

    AMC Manager® (paid version). This manual uses AMC Manager® Free for explanation. - If you want to use AMC Manager® (paid version), you need to purchase the license key. For how to purchase the license key, please contact Silex Technology. See C. Product Information and Customer Services for the contact information.

  • Page 33: How To Download Amc Manager

    AP-150AH User's Manual 2. About AP-150AH 2-6-2. How to Download AMC Manager® AMC Manager® can be downloaded from the Silex Technology’s website. Access the URL below to download it. https://www.silextechnology.com/ When the website is displayed, click Support Center in the bottom of the page.

  • Page 34: Configuration

    AP-150AH User's Manual 3. Configuration Configuration...

  • Page 35: Configuration Methods

    AP-150AH User's Manual 3. Configuration 3-1. Configuration Methods Following configuration methods are available: - Configure using the AP-150AH's Web page Access the AP-150AH's Web page to configure it. If you know the IP address of AP-150AH, you can configure it from your PC without AMC Manager®. - Configure using AMC Manager®...

  • Page 36: Connecting Ap-150Ah And Pc

    AP-150AH User's Manual 3. Configuration 3-2. Connecting AP-150AH and PC For configuration of AP-150AH, connect the PC to wired LAN. The following explains the connection procedure. Connect AP-150AH and PC using a LAN cable. Connect the power supply cable. Change the network settings of the PC to allow accessing AP-150AH. Example: When there is no DHCP server in your environment, the default IP address of AP-150AH is "192.168.20.1".

  • Page 37: About Ap-150Ah's Web Page

    AP-150AH User's Manual 3. Configuration 3-3. About AP-150AH's Web page The following shows the Web page structure. (6) (7)
  • Page 38 AP-150AH User's Manual 3. Configuration (1) Page menu If clicked, the configuration page is changed. (2) Tab The tab is displayed when there are multiple pages for the configuration. If the tab is clicked, the configuration page is changed. (3) Configuration page Each setting can be configured.
  • Page 39 AP-150AH User's Manual 3. Configuration Menu Explanation Maintenance Restart Restarts AP-150AH. Setting Initialization Restores all settings to the factory defaults and restarts AP-150AH. Firmware Update Updates the firmware. Downloads the log of AP-150AH. Logout Log out of the Web page.

  • Page 40: Displaying The Ap-150Ah's Web Page

    AP-150AH User's Manual 3. Configuration 3-4. Displaying the AP-150AH's Web Page The Web page can be displayed by the following methods. Display the Web page using a method appropriate for your environment. - Displaying a Web Page by entering the IP address directly Connect AP-150AH and PC on wired LAN, and enter the IP address of AP-150AH to the Web browser to display the Web page.

  • Page 41: Displaying A Web Page By Entering An Ip Address To Web Browser

    AP-150AH User's Manual 3. Configuration 3-4-1. Displaying a Web Page by Entering an IP Address to Web Browser By entering the IP address of AP-150AH to the address bar of your Web browser, the Web page can be accessed. - The following instructions will use Microsoft Edge and Windows 10 as examples. The display may vary depending on the OS or Web browser version.
  • Page 42 AP-150AH User's Manual 3. Configuration When the login page is displayed, enter the configured password and click Login. Web page has been displayed.

  • Page 43: Displaying A Web Page By Using Amc Manager

    AP-150AH User's Manual 3. Configuration 3-4-2. Displaying a Web Page by Using AMC Manager® The Web page of AP-150AH can be accessed using AMC Manager®. Start AMC Manager® in the PC. The device list of AMC Manager® shows the discovered AP-150AH units. Device list - If the AP-150AH is not displayed on the device list, click the icon Refresh ( - It may take approximately 1 min to show them on the device list depending on your environment.
  • Page 44 AP-150AH User's Manual 3. Configuration The login password configuration page appears. Enter the password to configure for AP-150AH and click Submit. When the login page is displayed, enter the configured password and click Login. Web page has been displayed.

  • Page 45: Configuration Using Amc Manager

    AP-150AH User's Manual 3. Configuration 3-5. Configuration Using AMC Manager® For configuration using AMC Manager®, create a configuration file first, and then apply it to AP-150AH. The following explains the procedure. 3-5-1. Create Configuration File Click Start - silex Tools - AMC Manager. The AMC Manager®...
  • Page 46 AP-150AH User's Manual 3. Configuration In the Create Configuration File window, check the check box of the items you want to use for the configuration file, edit the settings and click Save. In the dialog to save the configuration file, specify the file name and click Save. - When AP-150AH is used for the first time, the login password needs to be set.

  • Page 47: Apply Configuration File

    AP-150AH User's Manual 3. Configuration 3-5-2. Apply Configuration File Connect the PC to AP-150AH. For details on the connection method, see 3-2. Connecting AP-150AH and PC. Select the AP-150AH unit to configure from the device list of AMC Manager®, and click the icon Configure multiple devices in bulk( For bulk configuration, the configuration file is used to send the settings to the devices.
  • Page 48 AP-150AH User's Manual 3. Configuration The selected file is displayed at Configuration File Name. Click IP Configuration for the IP address configuration. When you are using the DHCP server to automatically configure the IP address, skip this and go on to 6. In the IP Address Configuration window, specify the range of IP address to configure for AP-150AH, and click OK.
  • Page 49 AP-150AH User's Manual 3. Configuration The IP addresses to configure are pre-assigned and displayed under New IP Address. Check the check boxes of AP-150AH units to configure (1) and click Configure Now (2).
  • Page 50 AP-150AH User's Manual 3. Configuration The configuration performs and the result is displayed. Click Close. When there are more AP-150AH units to configure, repeat the process of 1 to 8 and configure them one by one. The configuration has now been completed.

  • Page 51: Establishing Network For Long Distance Transfer

    AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer Establishing Network for Long Distance Transfer...

  • Page 52: Changing Network Settings

    AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer 4-1. Changing Network Settings The following explains how to change the network settings for the wired LAN side of AP-150AH. Display the AP-150AH's Web page. - For how to display the AP-150AH Web page, see 3-4. Displaying the AP-150AH's Web Page. Note Click System Configuration - Device Configuration from the page menu.
  • Page 53 AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer Check the settings and click Submit. The completion page is displayed. Click Restart. The new settings will take effect after AP-150AH is restarted. - If you do not want to apply the configuration change, reset it to the previous settings and click Submit at the bottom right of the Web page.

  • Page 54: Configuring Ieee 802.11Ah Settings

    AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer 4-2. Configuring IEEE 802.11ah Settings By using the IEEE 802.11ah wireless station device and AP-150AH, it is possible to establish a network that can transfer data to a remote location after it is sent from devices connected to the IEEE 802.11ah wireless station device.

  • Page 55: Network Authentication

    AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer The 900MHz AP page is displayed. Change SSID, Channel(MHz), etc. under Wireless LAN appropriately for the wireless network where AP-150AH is connected. If WPA3-Personal is selected for Network Authentication, the settings of Security Configuration are displayed.
  • Page 56 AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer Change the setting at Extension Configuration as necessary. - For details on each configuration item, see A-2-1. 900MHz AP. Note Check the settings and click Submit.
  • Page 57 AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer The completion page is displayed. Click Restart. The new settings will take effect after AP-150AH is restarted. - If you do not want to apply the configuration change, reset it to the previous settings and click Submit at the bottom right of the Web page.

  • Page 58: Configuring Napt And Dhcp Server

    AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer 4-3. Configuring NAPT and DHCP Server If a wireless network environment is established by enabling the NAPT function of AP-150AH, the wired LAN and wireless LAN of AP-150AH will be separated. For the connected wireless station devices, AP-150AH assigns an IP address as a DHCP server and which can reduce the number of use of IPv4 address in the network.

  • Page 59: Configuring Ap-150Ah

    AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer - When the NAPT function is enabled, AP-150AH operates as a DHCP server. To assign an IP address to EX-150AH, select ENABLE for DHCP Client on EX-150AH. - When the NAPT function is enabled, an IP address of AP-150AH must be registered to each device as the default gateway.
  • Page 60 AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer The NAPT Settings page is displayed. Select ENABLE for NAPT. - By defaults, NAPT is set to ENABLE. - For details on each configuration item, see A-2-2. NAPT Settings. Note Set the IP address of AP-150AH to use for a private network, and configure the DHCP server function.
  • Page 61 AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer Select ENABLE for Port Forwarding. Configure the detailed settings for the port forwarding function. Enter the following settings and click Add. Setting Item Explanation Destination (IP Address : Port) Set the IP address and port number as forwarding destination. Set the number of port to receive data.
  • Page 62 AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer Confirm that the entered information is added to Registered Information, and click Submit. - Click Delete under Registered Information to delete the registered information. Note The completion page is displayed. Click Restart.

  • Page 63: Configuring Ex-150Ah

    AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer 4-3-2. Configuring EX-150AH The following explains how to configure EX-150AH. Display the EX-150AH's Web page. - For how to display the EX-150AH Web page, see EX-150AH User's Manual. Note Click System Configuration - Device Configuration from the page menu.
  • Page 64 AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer - When you do not want to use the IP address assigned by AP-150AH, configure the following settings. Note Setting Item Setting Value DHCP Client DISABLE The value that can communicate with NAPT IP IP Address Address that you have checked at the step 5 of 4-3-1.
  • Page 65 AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer The restart progress page is displayed. When the login page is displayed, the configuration is completed.

  • Page 66: Configuring Other Devices

    AP-150AH User's Manual 4. Establishing Network for Long Distance Transfer 4-3-3. Configuring Other Devices To use the NAPT function, an IP address of AP-150AH needs to be set as the default gateway for EX-150AH and other devices that communicate via AP-150AH. Device Default gateway setting The value set to NAPT IP Address that you have checked at the step 5 of 4-3-...

  • Page 67: Basic Functions

    AP-150AH User's Manual 5. Basic Functions Basic Functions...

  • Page 68: Checking Status For Connected Wireless Station Devices

    AP-150AH User's Manual 5. Basic Functions 5-1. Checking Status for Connected Wireless Station Devices The operating status of the connected IEEE 802.11ah wireless station device can be checked on the Web page. The status includes MAC address of devices and the radio strength. This chapter describes how to check the operating status of the IEEE 802.11ah wireless station device.

  • Page 69: Using Dhcp Client Function

    AP-150AH User's Manual 5. Basic Functions 5-2. Using DHCP Client Function If the DHCP client function is enabled, the necessary communication information can be obtained from the DHCP server. For how to enable it, see 4-1. Changing Network Settings. - By defaults, DHCP Client is set to ENABLE. - When NAPT is set to ENABLE and the information is obtained from the DHCP server, such information Note will be used for the wired LAN side of AP-150AH, not for the wireless LAN side.

  • Page 70: Mac Address Filter Setting

    AP-150AH User's Manual 5. Basic Functions 5-3. MAC Address Filter Setting By configuring the MAC Address Filter, it is possible to block access from particular IEEE 802.11ah wireless station devices to AP-150AH. IEEE 802.11ah wireless station device 1 MAC Address ： 1c:bc:ec:44:55:66 AP-150AH ×...

  • Page 71: Mac Address Filter

    AP-150AH User's Manual 5. Basic Functions 5-3-2. MAC Address Filter Register the MAC Address of devices to allow/deny access to AP-150AH. Up to 30 MAC Addresses can be registered. To register, create a list of MAC Addresses as a text file and import it to AP-150AH from the Web page. To change the contents of the MAC Address list, update the MAC Address list file accordingly and import it again.

  • Page 72: Mac Address Filter Settings

    AP-150AH User's Manual 5. Basic Functions 5-3-3. MAC Address Filter Settings Following explains how to configure the MAC Address filter. Display the AP-150AH's Web page. - For how to display the AP-150AH Web page, see 3-4. Displaying the AP-150AH's Web Page. Note Click System Configuration - 900MHz AP from the page menu.
  • Page 73 AP-150AH User's Manual 5. Basic Functions Check the configuration file you have selected is displayed at the New Configuration File field. Click Submit. The completion page is displayed. Click Restart. The restart progress page is displayed. When the login page is displayed, the configuration is completed.

  • Page 74: Login Password Setting

    AP-150AH User's Manual 5. Basic Functions 5-4. Login Password Setting The following explains how to change the AP-150AH's login password. Display the AP-150AH's Web page. - For how to display the AP-150AH Web page, see 3-4. Displaying the AP-150AH's Web Page. Note Click System Configuration - Login Password from the page menu.
  • Page 75 AP-150AH User's Manual 5. Basic Functions The completion page is displayed. Click Restart. The new settings will take effect after AP-150AH is restarted. - If you do not want to apply the configuration change, reset it to the previous settings and click Submit at the bottom right of the Web page.

  • Page 76: Maintenance Functions

    AP-150AH User's Manual 6. Maintenance Functions Maintenance Functions...

  • Page 77: Restarting

    AP-150AH User's Manual 6. Maintenance Functions 6-1. Restarting This chapter explains how to restart AP-150AH. 6-1-1. Manual Restart at the Unit Side Restart by Unplugging the Power Supply Cable Remove the power supply cable of AP-150AH and re-insert it again. - When the power is supplied from the USB Type-C power connector, unplug the USB Type-C cable and plug it again.

  • Page 78: Restart By Using The Push Switch

    AP-150AH User's Manual 6. Maintenance Functions Restart by Using the Push Switch Make sure that AP-150AH is turned on, press and hold the push switch (1) and release it in 4 sec (2). - If the push switch is held down for 5 sec or longer, AP-150AH will be initialized. AP-150AH will restart.

  • Page 79: Remote Restart From The Web Page

    AP-150AH User's Manual 6. Maintenance Functions 6-1-2. Remote Restart from the Web Page Display the AP-150AH's Web page. - For how to display the AP-150AH Web page, see 3-4. Displaying the AP-150AH's Web Page. Note Click Maintenance - Restart from the page menu. When the Restart page is displayed, click Yes.

  • Page 80: Updating Firmware

    AP-150AH User's Manual 6. Maintenance Functions 6-2. Updating Firmware This chapter explains how to update the AP-150AH firmware. - The firmware update takes a time if it is done over IEEE 802.11ah wireless network. 6-2-1. Downloading the Firmware The latest firmware file can be downloaded from our website. See the instructions below to download the firmware file.

  • Page 81: Updating The Firmware

    AP-150AH User's Manual 6. Maintenance Functions 6-2-2. Updating the Firmware Display the AP-150AH's Web page. - For how to display the AP-150AH Web page, see 3-4. Displaying the AP-150AH's Web Page. Note Click Maintenance - Firmware Update from the page menu.
  • Page 82 AP-150AH User's Manual 6. Maintenance Functions A confirmation dialog is displayed. Click OK The firmware update will begin. When the login page is displayed, the firmware update is completed. Check the version information at the bottom left of the login page.

  • Page 83: Factory Default Configuration

    AP-150AH User's Manual 6. Maintenance Functions 6-3. Factory Default Configuration This chapter explains how to reset AP-150AH to the factory default settings. 6-3-1. Initialization Using the Push Switch on AP-150AH Press and hold the push switch of AP-150AH and release it in 5 sec or longer to start the factory default configuration.

  • Page 84: Initialization From The Web Page

    AP-150AH User's Manual 6. Maintenance Functions 6-3-2. Initialization from the Web Page Display the AP-150AH's Web page. - For how to display the AP-150AH Web page, see 3-4. Displaying the AP-150AH's Web Page. Note Click Maintenance - Setting Initialization from the page menu.

  • Page 85: List Of All Settings

    AP-150AH User's Manual A. List of All Settings List of All Settings...

  • Page 86: A-1. Device Configuration

    AP-150AH User's Manual A. List of All Settings A-1. Device Configuration General Configuration Item Host Name Set the host name. Details Be sure to use a unique name that is not used by other devices. Range 1 to 32 characters Default Value AP150-xxxxxx (xxxxxx is the last 6 digits of the MAC address, and letters are uppercase) The following symbols and spaces cannot be used.
  • Page 87 AP-150AH User's Manual A. List of All Settings Item IP Address Set the IP address. Details If the DHCP Client is enabled on your network, the IP address obtained from it will be applied. 0.0.0.0 to 255.255.255.254 Range * IP addresses of "x.x.x.255", "0.x.x.x" (except for 0.0.0.0), and "127.x.x.x" cannot be used. * It is impossible to use IP addresses with the same network address as NAPT IP Address.

  • Page 88: A-2. 900Mhz Ap

    AP-150AH User's Manual A. List of All Settings A-2. 900MHz AP A-2-1. 900MHz AP Wireless LAN Item Channel(MHz) Details Set the channel to use for the IEEE 802.11ah wireless LAN. The configurable setting will differ depending on the Channel Bandwidth. When Channel Bandwidth is 1MHz : 903.5 / 904.5 / 905.5 / 906.5 / 907.5 / 908.5 / 909.5 / 910.5 / 911.5 / 912.5 / 913.5 / 914.5 / 915.5 / 916.5 / 917.5 / 918.5 / 919.5 / 920.5 / 921.5 / 922.5 / 923.5 / 924.5 / 925.5 / 926.5...

  • Page 89: Security Configuration

    AP-150AH User's Manual A. List of All Settings Security Configuration Item Pre-Shared Key Details Set the Pre-Shared Key when the Network Authentication is WPA3-Personal. Range 8 to 63 characters Default Value LetMeConnect_SX150AH Note This setting must be the same as that of your device you wish to connect to. Extension Configuration Item Beacon Interval(ms)

  • Page 90: A-2-2. Napt Settings

    AP-150AH User's Manual A. List of All Settings A-2-2. NAPT Settings NAPT Settings Item NAPT Details Enable/Disable the NAPT function. Range ENABLE/DISABLE Default Value ENABLE Item NAPT IP Address This setting is displayed when NAPT is ENABLE. Set the IP address to use for the wireless LAN side when the NAPT function is enabled. Details * IP addresses of "x.x.x.255", "0.x.x.x"...
  • Page 91 AP-150AH User's Manual A. List of All Settings Port Forward Configuration Item Port Forwarding Details Enable/Disable the Port Forwarding function. Range ENABLE/DISABLE Default Value DISABLE Add Configuration Item Destination (IP Address : Port) Details Set the IP address and port number of the destination device for port forwarding function. IP Address : 0.0.0.1 to 255.255.255.255 Range Port : 1 to 65535...

  • Page 92: A-2-3. Mac Address Filter

    AP-150AH User's Manual A. List of All Settings A-2-3. MAC Address Filter MAC Address Filter Item MAC Address Filter Configure the access control setting for all MAC addresses. DISABLE : MAC address filter function is disabled. Details ALLOW : Allows access only from the devices registered to MAC address filter list. DENY : Denies access from the devices registered to MAC address filter list.

  • Page 93: A-3. Server Certificate

    AP-150AH User's Manual A. List of All Settings A-3. Server Certificate Server Certificate Create Item Common Name Details Set a name of AP-150AH. Range 1 to 64 characters Default Value AP150-xxxxxx (xxxxxx is the last 6 digits of the MAC address, and letters are uppercase) Item Organizational Unit Name Details...

  • Page 94: A-4. Login Password

    AP-150AH User's Manual A. List of All Settings A-4. Login Password Please input the password. Item New Password Set the login password for AP-150AH. Details The password is used for authentication when the user tries to update settings from a Web browser or to use AMC Manager®.

  • Page 95: Troubleshooting

    AP-150AH User's Manual B. Troubleshooting Troubleshooting This chapter provides the solutions for possible troubles you may experience when you are configuring or using the AP-150AH.

  • Page 96: B-1. Problems During The Setup

    AP-150AH User's Manual B. Troubleshooting B-1. Problems During the Setup I don't know the IP Address of AP-150AH. Use "AMC Manager®". AMC Manager® can search for AP-150AH units connected to a network. For Solution details, see 3-5. Configuration Using AMC Manager®. An error occurs when accessing the Web page of AP-150AH.
  • Page 97 AP-150AH User's Manual B. Troubleshooting How should I determine the way to assign an IP address to AP-150AH? There are two ways to assign an IP address to AP-150AH; one is to Get IP address automatically from DHCP server and the other is to Assign IP address manually. Choose the way to assign an IP address according to your environment.

  • Page 98: B-2. Problems On Wireless Access Point Function

    AP-150AH User's Manual B. Troubleshooting B-2. Problems on Wireless Access Point Function I cannot connect to AP-150AH wirelessly. Please check the operation status and configuration of AP-150AH. The wireless LAN setting may differ between AP-150AH and the connected IEEE 802.11ah compliant device. Connect a LAN cable to AP-150AH and check the wireless LAN settings.
  • Page 99 AP-150AH User's Manual B. Troubleshooting I cannot access the device that is connected to AP-150AH via wired LAN. The device may be connected to a network different from the private network that is established using the NAPT function of AP-150AH. - When using a private IP network using the NAPT function of AP-150AH When your device is accessing from outside the private IP network, connect it wirelessly to AP- 150AH to join the private IP network.

  • Page 100: Product Information And Customer Services

    AP-150AH User's Manual C. Product Information and Customer Services Product Information and Customer Services C-1. Product Information The services below are available from the Silex Technology website. For details, please visit the Silex Technology website. https://www.silextechnology.com/ - Latest firmware download...
