  • Page 1 Industrial Access Point AP-800AX User's Manual...
  • Page 2 Copyright© 2023 Silex Technology, Inc. All rights reserved. WA107720XA...

  • Page 3: Table Of Contents

    2-6. DFS Function ............................32 3. How to Configure ..............33 3-1. Configuration Methods ........................34 3-2. Configuration Using AP-800AX's Web Page ................35 3-2-1. AP-800AX Web Page ........................ 35 3-2-2. Displaying the AP-800AX's Web Page ................35 Displaying Web Page Using Configuration Mode ..............36...
  • Page 4 4-2. Connection Using Smart Wireless Setup .................. 73 4-2-1. Checking Settings ........................73 4-2-2. Making a Connection Using SET Switch ................74 4-2-3. Making a Connection Using AP-800AX's Web Page ............. 75 5. Product Installation ..............77 5-1. Installation Methods for Stable Wireless ................... 78 5-2.
  • Page 5 7-4-1. VLAN Feature ..........................135 7-4-2. VLAN Configuration........................136 How to check the VLAN information on network ..............136 How to configure the VLAN setting on AP-800AX ..............137 How to connect AP-800AX to a trunk port of VLAN HUB ..........140 7-5. Device Filter Setting ........................141...
  • Page 6 7-5-1. MAC Address Filter Setting ....................141 Filter Type ............................141 MAC Address List ..........................142 MAC Address Filter Settings ......................143 7-5-2. Protocol Filter Setting ......................147 7-6. IEEE 802.1X Authentication ......................149 7-6-1. Network Configuration ......................149 7-6-2. IEEE 802.1X Authentication ....................149 7-6-3. IEEE 802.1X Authentication Settings ................150 7-7.
  • Page 7 9-2-1. Downloading the Firmware ....................182 9-2-2. Updating the Firmware ......................183 9-3. Factory Default Configuration ....................185 9-3-1. Initialization Using the RESET Switch on AP-800AX ...........185 9-3-2. Initialization from the Web Page ..................187 9-4. Configuration Import/Export Using Configuration File ............189 9-4-1. Configuration Import/Export ....................189 9-4-2.
  • Page 8 C. Troubleshooting ..............239 C-1. Problems During the Setup ......................240 C-2. Problems on Wireless Access Point Feature ................243 C-3. Problems for Connecting Multiple AP-800AX Units ............245 C-4. Checking Troubles on the Event Logs ..................246 D. Product Information and Customer Services ....... 247 D-1.

  • Page 9: Introduction

    AP-800AX User's Manual 1. Introduction Introduction Thank you for purchasing the industrial Access Point "AP-800AX". This manual provides information on how to configure and use AP-800AX. Please read the 1-2. Safety Instructions carefully before using AP-800AX.

  • Page 10: Introduction

    : This symbol indicates important information that needs to be observed when operating AP-800AX. Make sure to read this information for safe and proper use. : This symbol indicates information that is useful when using AP-800AX. If you experience difficulties operating AP-800AX, please refer to this information Note first.

  • Page 11: Glossary

    Since a transmission rate is automatically changed depending on whether radio waves are received or not, an unintended transmission rate may be selected. By using the rate survey function of AP-800AX to perform a communication test on each MCS, you can select an appropriate transmission rate.

  • Page 12: Safety Instructions

    This page provides the safety instructions for safe use of AP-800AX. To ensure safe and proper use, please read the following information carefully before using AP-800AX. The safety instructions include important information on safe handling of AP- 800AX and on general safety issues.
  • Page 13 - Near strong electromagnetic sources (magnet, radio, wireless device, etc.) * When installing AP-800AX on a wall or in a high place, make sure that it is securely fixed so that it will not fall due to the weight of the cables.
  • Page 14 AP-800AX User's Manual 1. Introduction Warning * Do not move AP-800AX as long as the AC adapter is connected to. Doing so may damage the AC adapter cable, resulting in fire or electric shock. Caution * AP-800AX may become hot when it is in operation. Be careful when moving or disconnecting AP-800AX.
  • Page 15 * When AP-800AX will not be used for an extended time, disconnect and unplug the power cable. If the connected device is a PoE device, unplug the LAN cable. * Be sure to use the AC adapter specified by Silex Technology. Failure to do so may cause malfunction.

  • Page 16: Notes On Usage

    When using AP-800AX near the following devices - Microwave oven, industrial/scientific equipment, etc. The above devices use the same radio frequency band as the wireless LAN. Using AP-800AX near the above devices may cause radio wave interference. As the result, communication may be lost, the speed may slow down, or the operation of the above devices may be adversely affected.
  • Page 17 1. Introduction Wireless devices using 2.4GHz band The same frequency band of AP-800AX is used for a microwave, industry, science, medical equipment and licensed in room or low power (non-licensed) radio stations. - Before you use AP-800AX, check that it does not interfere with other devices.

  • Page 18: Notes On Security

    AP-800AX User's Manual 1. Introduction 1-3-2. Notes on Security Because a wireless LAN uses electromagnetic signals instead of a LAN cable to establish communication with network devices, it has the advantage of allowing devices to connect to the network easily. However, a disadvantage of this is that within a certain range, the electromagnetic signals can pass through barriers such as walls, and if security countermeasures are not implemented in some way, problems such as the following may occur.

  • Page 19: Standards Compliance

    AP-800AX User's Manual 1. Introduction 1-3-3. Standards Compliance Notice to US Customers Contains FCC ID : N6C-AP800AX FCC Rules, Part 15 §15.19(a)(3) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
  • Page 20 AP-800AX User's Manual 1. Introduction FCC Rules Part 15 Subpart E §15.407(g) Frequency Tolerance: +/-20 ppm FCC Rules Part 15 Subpart C §15.247(g) / Subpart E This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
  • Page 21 AP-800AX User's Manual 1. Introduction RSS-Gen Issue5 §6.8 This radio transmitter 4908A-AP800AX has been approved by Innovation, Science and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device.
  • Page 22 AP-800AX User's Manual 1. Introduction RSS-102 Issue 5 §2.6 This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the ISED radio frequency (RF) Exposure rules. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.

  • Page 23: About Ap-800Ax

    AP-800AX User's Manual 2. About AP-800AX About AP-800AX...

  • Page 24: Features

    As Multi SSID is supported, up to 8 wireless interfaces can be used (4 for 2.4GHz and 4 for 5GHz). - Wall-mountable AP-800AX can be mounted on a wall using Bracket Type XI (optionally available) or a DIN rail mounting plate (commercially-available).
  • Page 25 2. About AP-800AX - PoE (Power over Ethernet) As PoE+ is supported, AP-800AX can receive power by connecting a LAN cable to a PoE+ power supply device such as a PoE HUB or PoE injector, without using an AC adapter.
  • Page 26 - Bulk configuration and version update - Visualization of the AMC Mesh network using Mesh Monitor (option utility) - For details on AMC Manager® and Mesh Monitor, please visit the Silex Technology's website. Note - Supports "AMC Cloud" the Web application that can operate on the cloud.

  • Page 27: Parts And Functions

    AP-800AX User's Manual 2. About AP-800AX 2-2. Parts and Functions External Dimensions (82.5) DC12V LAN/PoE RESET Reference dimensions...
  • Page 28 Smart Wireless Setup is in progress (2-second cycle) Smart Wireless Setup has failed. (Turns off in 3 minutes) * If Smart Wireless Setup is executed while someone is logging to the AP-800AX's Web page, the priority is given to the login of the Web page.
  • Page 29 5GHz band is displayed. • If all of the POWER LED, SETTING LED and MODE LED turn red together, AP-800AX is malfunctioning. In this case, please contact Silex Technology. For the contact information, refer to D-2. Customer Support Center.
  • Page 30 2. About AP-800AX (7) Reset Switch(RESET) By using the RESET switch, AP-800AX can be switched to the configuration mode or be reset to the factory default settings. For details, refer to 3-2. Configuration Using AP- 800AX's Web Page, and 9-3. Factory Default Configuration.
  • Page 31 Authentication mode Encryption Encryption mode Password Login password. By default, no password is set to AP-800AX. This is the MAC address of AP-800AX. The format of MAC address is "E/A: 1CBCECXXXXXX". The last 6 digits are the Product number (serial number).

  • Page 32: Specifications

    AP-800AX User's Manual 2. About AP-800AX 2-3. Specifications 2-3-1. Hardware Specifications 1GByte Memory SPI Flash ROM 32MByte NAND Flash ROM 256MByte Antenna Pole antenna x 2 Reset Switch Push Switch Set Switch Status (Green) LAN Port Link (Orange) Others POWER (Green/Red)
  • Page 33 AP-800AX User's Manual 2. About AP-800AX Wireless network interface US/Canada Bandwidth 5GHz 36, 40, 44, 48 IEEE 802.11a 52, 56, 60, 64 Channel 100, 104, 108, 112, 116, 132, 136, 140, 144 149, 153, 157, 161, 165 Bandwidth 2.4GHz IEEE 802.11b...

  • Page 34: Software Specifications

    AP-800AX User's Manual 2. About AP-800AX 2-3-2. Software Specifications Network layer IPv4 ICMP Transport layer DHCP(Client/Server) TCP/IP DNS(Client) NTP(Client/Server) HTTP (Server) Application layer HTTPS(Server) SNMP(Server) Syslog(Server) SXSMP(Server) Microsoft Edge Recommended Web browser Google Chrome...

  • Page 35: Configuration Utility

    AMC Manager® is the unified device management utility that provides remote status monitoring and individual/bulk configuration for Silex devices over an IP network. It can display the operating status of AP-800AX on the list and such information can be used conveniently for device management.
  • Page 36 AP-800AX User's Manual 2. About AP-800AX For AMC Manager®, there are a free version "AMC Manager® Free" and a non-free version "AMC Manager®". When a non-free version is used, more devices can be managed and configured at once and the plug-in utilities such as Mesh Monitor, etc. can be used.

  • Page 37: Mesh Monitor

    Monitor. The connection line is displayed based on the connection information of AP- 800AX. Also, a history of AMC Mesh network transition and AP-800AX's operating status can be checked, which is useful for identifying the cause of trouble. - Mesh Monitor is a plug-in utility of AMC Manager®. To install it, another license key needs to be purchased.

  • Page 38: Power Supply

    - The AC adapter does not come with AP-800AX. It is optionally available. - Please remember that power is supplied from the AC adaptor if it is connected to AP-800AX. - PoE is a technology to supply electrical power over Ethernet cable (Category 5e or above).
  • Page 39 LAN cable Connect to the “LAN/PoE” port. Sample connection3: When using an AC adapter (option) Connect the AC adapter to AP-800AX and AC plug to an outlet. AP-800AX Outlet AC Adaptor - Use the AC adapter that you have purchased from Silex Technology.

  • Page 40: Dfs Function

    Once radar waves are detected, the channel will not be available for 30 mins. (* This time period differs depending on the country.) - The 5GHz LED flashes red if radar waves are detected when AP-800AX is powered on or is in operation.

  • Page 41: How To Configure

    AP-800AX User's Manual 3. How to Configure How to Configure...

  • Page 42: Configuration Methods

    Following configuration methods are available: - Configure using the AP-800AX's Web page Access the AP-800AX's Web page to configure it. If you know the IP address of AP-800AX, you can configure it from your PC without AMC Manager®. - Configure using AMC Manager®...

  • Page 43: Configuration Using Ap-800Ax's Web Page

    Displaying Web Page Using Network Connection Connect AP-800AX and PC via a wired LAN to display the Web page. It is possible to connect two or more AP-800AX units to a wired LAN to configure them at once. Start from this when you connect AP-800AX to your existing wired LAN.

  • Page 44: Displaying Web Page Using Configuration Mode

    - PoE+ HUB or PoE injector (When using an AC adapter, use the AC adapter (optionally available).) - Use a PoE HUB as the power supply for AP-800AX. Do not connect the PoE HUB to the network when using configuration mode.
  • Page 45 AP-800AX User's Manual 3. How to Configure Connect one end of LAN cable to the PC and the other end to "LAN" port of AP-800AX. AP-800AX Connect to the “LAN” port. LAN cable - When an AC adapter is used, you can also connect it to the "LAN/PoE" port of AP-800AX.
  • Page 46 AP-800AX User's Manual 3. How to Configure After AP-800AX is turned on, press and hold the RESET switch with a pointed object such as a pen. Keep holding it, and when the MODE LED blinks orange, release the switch (it takes about 5 sec until the MODE LED blinks).
  • Page 47 AP-800AX User's Manual 3. How to Configure When the login page is displayed, enter the configured password and click Login. - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note Web page has been displayed.

  • Page 48: Displaying Web Page Using Network Connection

    Connect AP-800AX and PC via a wired LAN to display the Web page. It is possible to connect two or more AP-800AX units to a wired LAN to configure them at once. Start from this when you connect AP-800AX to your existing wired LAN.
  • Page 49 Connect to the “LAN/PoE” port. LAN cable - When using an AC adapter, connect the AC adapter to AP-800AX and the AC adapter’s plug to an outlet. Note - To connect two or more AP-800AX units, repeat the process at 2-3.
  • Page 50 The device list of AMC Manager® shows the discovered AP-800AX units. Device list - If the AP-800AX is not displayed on the device list, click the icon Refresh ( - It may take approximately 1 min to show them on the device list depending on your Note environment.
  • Page 51 AP-800AX User's Manual 3. How to Configure When the login page is displayed, enter the password and click Login. - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note Web page has been displayed.

  • Page 52: Displaying Web Page By Smart Wireless Setup

    - PoE+ HUB or PoE injector (When using an AC adapter, use the AC adapter (optionally available).) - Move AP-800AX closer to the PC you are using for configuration so that they can communicate properly. - By default, wireless interface 1 (5GHz) is set as wireless interface that can use Smart Wireless Setup.
  • Page 53 Connect to the “LAN/PoE” port. LAN cable - When using an AC adapter, connect the AC adapter to AP-800AX and the AC adapter’s plug to an outlet. Note - To connect two or more AP-800AX units, repeat the process at 2-3.
  • Page 54 Click the network icon on the notification area (system tray) of the PC to view the wireless networks. Select the SSID configured on AP-800AX from a list and click Connect. - If Connect automatically is checked, your PC will automatically connect to AP-800AX every time it restarts. Note...
  • Page 55 The device list of AMC Manager® shows the discovered AP-800AX units. Device list - If the AP-800AX is not displayed on the device list, click the icon Refresh ( - It may take approximately 1 min to show them on the device list depending on your environment.
  • Page 56 Note When the login page is displayed, enter the password and click Login. - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note Web page has been displayed.

  • Page 57: Configuration Using Ap-800Ax's Web Page

    AP-800AX User's Manual 3. How to Configure 3-2-3. Configuration Using AP-800AX's Web Page After login, you can change AP-800AX settings from the Web pages. The following image shows the page structure for each configuration page. (1) Page menu If clicked, the configuration page is changed.
  • Page 58 - When the settings are not applied to AP-800AX, the following notes are displayed on top of the configuration page and the menu. Click "Apply Config" to go to the configuration page Note at which you can apply the configuration or restart AP-800AX.
  • Page 59 Configure the settings about wired LAN and Conf. LED management. DHCP Server Configure the settings about DHCP server. VLAN Set the VLAN ID for SSID of AP-800AX's wireless LAN. SNMP Configure the SNMP settings. Log Output Configure the settings to output logs to the Syslog server.

  • Page 60: Changing Network Settings

    Refer to Changing Network Settings and Changing Wireless LAN Settings respectively for how to configure basic settings using the Web page. Changing Network Settings The following explains how to change the TCP/IP setting of AP-800AX that is required to access via wired or wireless LAN. Display the AP-800AX's Web page.
  • Page 61 AP-800AX User's Manual 3. How to Configure The Network Configuration page is displayed. Change the settings at IP Configuration appropriately for the network where AP- 800AX is installed. - For details on each configuration item, refer to A-1-1. Network Configuration.
  • Page 62 Do it later when all necessary settings are configured. When the Apply Config page is displayed, click Restart. The new settings will take effect after AP-800AX is restarted. - If you do not want to apply the configuration change, reset it to the previous settings and click Save Config at the bottom right of the Web page.
  • Page 63 AP-800AX User's Manual 3. How to Configure A progress bar appears. The configuration is complete when the progress bar reaches the right end.

  • Page 64: Changing Wireless Lan Settings

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - Wireless General from the page menu.
  • Page 65 The screen below is an example to use only 100ch, 104ch, and 108ch outdoors. When the channel is set to AUTO, an appropriate channel will be selected when AP-800AX is turned on, but if the channels are unchecked in the Available Channel List, they will be excluded from the selection, so that the users can avoid the channels that are used for other purposes.
  • Page 66 AP-800AX User's Manual 3. How to Configure When finished entering the settings, click Save Config at the bottom right of the page. - If other settings are clicked from the left menu before clicking Save Config, the entered values will be cleared. Be sure to click Save Config, to save the current values when you move to the other page.
  • Page 67 AP-800AX User's Manual 3. How to Configure - If WPA2-Enterprise, WPA3-Enterprise, WPA/WPA2-Enterprise, WPA2/WPA3-Enterprise, or WPA3-Enterprise 192bit-security is selected for Network Authentication, the settings Note of RADIUS Server Configuration are displayed. For details, refer to 7-6. IEEE 802.1X Authentication. - If IEEE 802.11r Fast Transition is enabled, the settings of Mobility Domain are displayed.
  • Page 68 AP-800AX User's Manual 3. How to Configure The Extension Configuration 5GHz page is displayed. Configure the settings at Extension Configuration, QoS(WMM) Configuration, Unicast Transmit Rate Configuration, Spatial Reuse Configuration. - For details on each configuration item, refer to A-2-6. Wireless Detail - Extension Configuration 5GHz.
  • Page 69 AP-800AX User's Manual 3. How to Configure The Security Configuration 5GHz page is displayed. Configure the privacy separator function and MAC address filter for each wireless interface. - For details on the privacy separator, refer to 7-9. How to Filter Communication between Wireless Station Devices.
  • Page 70 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 71: Configuration Using Amc Manager

    3. How to Configure 3-3. Configuration Using AMC Manager® 3-3-1. How to Download AMC Manager® AMC Manager® can be downloaded from the Silex Technology’s website. Access the URL below to download it. https://www.silextechnology.com/ When the website is displayed, click Support Center from the top menu.

  • Page 72: Connecting Ap-800Ax And Pc

    Connect to the “LAN/PoE” port. - When DHCP Client is set to DISABLE on AP-800AX, change the IP address of the PC to the one that is communicable with AP-800AX. - When DHCP Client is set to ENABLE on AP-800AX, change the IP address setting of the PC to Obtain an IP address automatically.

  • Page 73: Individual Configuration Using Amc Manager

    3. How to Configure 3-3-3. Individual Configuration Using AMC Manager® Start AMC Manager® in the PC. When AMC Manager® is started, AP-800AX is displayed in a device list. Select AP-800AX (1) and click the icon Configure the device ( )(2).
  • Page 74 When the password configuration is finished, AP-800AX is restarted. Click Close when the window below appears. From the AMC Manager® main window, select AP-800AX again and click the icon Configure the device ( When the password entry screen is displayed, enter the password that you have set at 2,...
  • Page 75 Check the check boxes of the items to update, and change the values (3). - The setting whose check box is checked will be configured to AP-800AX. For the setting you do not want to change, clear the check box.
  • Page 76 AP-800AX User's Manual 3. How to Configure The configuration result is displayed. AP-800AX will automatically restart and operate with the new settings. Click Close.

  • Page 77: Bulk Configuration Using Amc Manager

    3. How to Configure 3-3-4. Bulk Configuration Using AMC Manager® For how to configure multiple AP-800AX units at once using AMC manager®, refer to AMC Manager® User's Manual. - AMC Manager® User's Manual can be downloaded from the Silex Technology's website.

  • Page 78: How To Connect Wireless Station Devices

    AP-800AX User's Manual 4. How to Connect Wireless Station Devices How to Connect Wireless Station Devices...

  • Page 79: Connecting Pc

    4. How to Connect Wireless Station Devices 4-1. Connecting PC The following explains how to connect your PC to AP-800AX as a wireless station device. - Before you begin, get the SSID and security key configured on AP-800AX. - The following explanation uses Windows 10 for an example. When an operating system other Note than Windows 10 is used, the procedure may differ.
  • Page 80 AP-800AX User's Manual 4. How to Connect Wireless Station Devices Enter the Pre-Shared key to Security key and click Next. When a message Do you want to allow your PC to be discoverable by other PCs and devices on this network? appears, click No.

  • Page 81: Connection Using Smart Wireless Setup

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - Wireless Detail - Smart Wireless Setup from the page menu.

  • Page 82: Making A Connection Using Set Switch

    - To use this configuration method, the wireless station device must support Wi-Fi Protected Setup (WPS). Press and hold the SET switch(Smart Wireless Setup switch) of AP-800AX, and release it when the SETTING LED flashes orange. SETTING LED (Blinks in Orange) Push the SET switch.

  • Page 83: Making A Connection Using Ap-800Ax's Web Page

    Setup (WPS). - This configuration method cannot be used when AP-800AX is operating in Configuration Mode. For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page - Displaying Web Page Using Network Connection. Display the AP-800AX's Web page.
  • Page 84 4. How to Connect Wireless Station Devices Press the wireless setup switch also on your wireless station device. AP-800AX will start to communicate with your wireless station device and configure the same wireless settings. The SETTING LED will turn green when the configuration is completed.

  • Page 85: Product Installation

    AP-800AX User's Manual 5. Product Installation Product Installation...

  • Page 86: Installation Methods For Stable Wireless

    - For how to mount AP-800AX to the wall, refer to 5-2. Mounting AP-800AX to Wall. - By limiting the transmission rate of AP-800AX, wireless communication may be improved.
  • Page 87 Direction of antenna By adjusting the direction of the antenna appropriately for the installation location, the wireless communication may be improved. Rotate the antenna about 45 degrees as follows. When placing AP-800AX vertically When placing AP-800AX horizontally 45 ° 45 °...

  • Page 88: Mounting Ap-800Ax To Wall

    AP-800AX User's Manual 5. Product Installation 5-2. Mounting AP-800AX to Wall There are the following methods to mount AP-800AX on the wall. Recommended methods: - Mounting the unit using brackets - Attaching to DIN rails Quick method: - Attaching the unit using screws...

  • Page 89: Wall Mounting With Bracket

    5. Product Installation 5-2-1. Wall Mounting with Bracket Align the bracket (Bracket Type XI) with the screw holes on the back of AP-800AX and fasten them with screws. (* The bracket is optionally available.) After attaching the bracket to AP-800AX, hold it to the wall and mark the positions of the four screw holes.
  • Page 90 Align the screw holes of the bracket with the anchors inserted at step 2 and screw them. - Silex Technology is not responsible for any damages caused by insufficient mounting. Make sure that AP-800AX is securely fixed to the wall so that it does not fall due to the weight of the product and cables.

  • Page 91: Attaching To Din Rail

    5. Product Installation 5-2-2. Attaching to DIN Rail Attach DIN rail mounting plates (commercially available) to the back of AP-800AX. DIN rail mounting plate - DIN rail and DIN rail mounting plate are not contained in the product package. They need to be purchased separately.

  • Page 92: Wall Mounting With Screws

    AP-800AX User's Manual 5. Product Installation 5-2-3. Wall Mounting with Screws Prepare two screws to attach AP-800AX to the wall. Screw size Φ3.7mm or less 2.4mm or less Φ6mm to 7mm * For the screw length, select it according to the material and thickness of the wall.
  • Page 93 Leave at least 8mm gap from the wall to the screw head. To mount AP-800AX to the wall, align the screws of the wall with the screw holes of AP- 800AX and move the unit down along the wall to fix it.

  • Page 94: Placing Ap-800Ax Onto Table

    - Do not place AP-800AX onto a tilted or unstable place. Connect AP-800AX and PoE HUB using a LAN cable. AP-800AX PoE HUB Connect to the “LAN/PoE” port. LAN cable - When using an AC adapter, connect the AC adapter to AP-800AX and the plug to an outlet.

  • Page 95: Network Expansion Using Multiple Ap-800Ax Units

    AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units Network Expansion Using Multiple AP-800AX Units...

  • Page 96: About Amc Mesh

    AMC Mesh is composed of one RootAP (running as a host device) and plural Repeater APs (running as station devices). - Please check that all AP-800AX Access Points are running on the same version of firmware. - When both 5GHz and 2.4GHz bands are checked at Mesh Frequency Band of the AMC Mesh function, 2.4GHz band connection will be used for redundancy of 5GHz band.
  • Page 97 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units AMC Mesh function supports two ways of communication method; one is to fix the destination by registering the MAC Address, and the other one is to switch the destination automatically according to the wireless status. As shown in the image below, even if the relay device fails, communication can continue by using other relay devices.
  • Page 98 6-3. Establishing a Network That Changes Communication Route Automatically. To create an AMC Mesh network where the destination of AP-800AX is fixed by registering the MAC Address, see 6-4. Establishing a Network That Fixes Communication Route.

  • Page 99: Necessary Preparations

    Prepare the followings to proceed the configuration and installation easily. 6-2-1. Preparing Floor Plan Image Please prepare the floor plan image of the floor where AP-800AX units are to be installed, which meets the following conditions. - The scale is clearly indicated, or approximate distance / area can be confirmed.

  • Page 100: Determination Of Unit Locations

    6. Network Expansion Using Multiple AP-800AX Units 6-2-2. Determination of Unit Locations First of all, allocate the AP-800AX unit that connects to the backbone network, and then allocate other units by keeping 20m interval starting from the first unit. Make sure that each unit is allocated within a distance of 20m from the other one so that radio signals can reach.
  • Page 101 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units - First, install AP-800AX that connects to the backbone network, and then install Repeater APs. Note...

  • Page 102: Establishing A Network That Changes Communication Route Automatically

    First, configure the RootAP, and then configure the Repeaters. - Since the destination device is not fixed, AP-800AX may connect to an unexpected device if the installation position and communication route are not planned in advance. Refer to 6-2.
  • Page 103 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units The AMC Mesh Configuration page is displayed. Under General Configuration, select RootAP for Mesh Mode, configure each setting and click Save Config. - To connect to an existing wired LAN, select ENABLE for Network Loop Avoidance.
  • Page 104 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 105: Preparation For Repeater Settings

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - Wireless General from the page menu.

  • Page 106: Repeater Settings

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - AMC Mesh from the page menu.
  • Page 107 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units For the following settings, configure the same setting as the destination RootAP or Repeater (hereafter referred to as ‘host AP’), and click Save Config. - Mesh Group Name - Mesh Encryption Key...
  • Page 108 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units The Wireless General Configuration page is displayed. For the following settings, configure the same setting as the host AP, and click Save Config. - Wireless Mode - Channel Bandwidth - Available Channel List - If other settings are clicked from the left menu before clicking Save Config, the entered values will be cleared.
  • Page 109 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 110: Establishing A Network That Fixes Communication Route

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - AMC Mesh from the page menu.
  • Page 111 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.
  • Page 112 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units The configuration load message is displayed. When the screen changes, it is finished.

  • Page 113: Preparation For Repeater Settings

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - Wireless General from the page menu.
  • Page 114 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units From the page menu, click System under Status. The System Status page is displayed. Make a note of the followings. - MAC Address...

  • Page 115: Repeater Settings

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - AMC Mesh from the page menu.
  • Page 116 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units For the following settings, configure the same setting as the host AP, and click Save Config. - Mesh Group Name - Mesh Encryption Key - Network Loop Avoidance - Destination MAC Address - If other settings are clicked from the left menu before clicking Save Config, the entered values will be cleared.
  • Page 117 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units The Wireless General Configuration page is displayed. For the following settings, configure the same setting as the host AP, and click Save Config. - Wireless Mode - Channel Bandwidth - Available Channel List - If other settings are clicked from the left menu before clicking Save Config, the entered values will be cleared.
  • Page 118 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 119: Checking Connection Status With Led

    The following explains how to install AP-800AX using this function. First, install AP-800AX (operating as RootAP) that connects to the backbone network, and then install AP-800AX (operating as Repeater) in order of proximity to the RootAP that is connected to the backbone network.
  • Page 120 - No reinforcing bars, metal and concrete walls or poles are installed in front of the radio emission portion. - Not too far away from the other AP-800AX units. Repeat 1-4 and adjust the unit location one by one. When the adjustment is finished for all units, fix them to the location.

  • Page 121: What If Connection Fails

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - Wireless General from the page menu.
  • Page 122 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units The Wireless General Configuration page is displayed. Check the following settings. - Wireless Mode - Channel Bandwidth - Channel - Available Channel List...

  • Page 123: How To Check The Settings On Host Ap

    The following explains how to check the Repeater settings or RootAP settings on the host - This method cannot be used when AP-800AX is operating in Configuration Mode. For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page - Displaying Web Page Using Network Connection.
  • Page 124 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units Click Wireless LAN - AMC Mesh from the page menu. The AMC Mesh Status page is displayed. See the number of Repeaters that are connected as wireless station devices. Check that too many wireless station devices and APs are NOT connected, which exceeds the maximum number of connectable devices.
  • Page 125 AP-800AX User's Manual 6. Network Expansion Using Multiple AP-800AX Units The AMC Mesh Configuration page is displayed. Under General Configuration, check that RootAP or Repeater is selected for Mesh Mode. Click Wireless Conf. - Wireless General from the page menu.

  • Page 126: Checking Connection Status On Web Page

    6. Network Expansion Using Multiple AP-800AX Units 6-7. Checking Connection Status on Web Page To see if AP-800AX is connected in AMC Mesh mode properly, check the status page on the Web page in the order from the station AP to the host AP.
  • Page 127 3 at the host AP's Web page. - AP-800AX uses two MAC Addresses when connected in AMC Mesh. As they are generated based on the MAC Address of AP-800AX, those addresses are different from the one that you can find Note on the system status page and the product label.

  • Page 128: Basic Functions

    AP-800AX User's Manual 7. Basic Functions Basic Functions...

  • Page 129: Ip Address Configuration Using Ap-800Ax As A Dhcp Server

    • It is impossible to assign the IP address whose first number is 0-127. - To assign an IP address to your PC automatically using the DHCP server feature of AP-800AX, your PC must be set to Obtain an IP address automatically.

  • Page 130: Dhcp Server Function Settings

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Detail Conf. - DHCP Server from the page menu.
  • Page 131 Do it later when all necessary settings are configured. When the Apply Config page is displayed, click Restart. The new settings will take effect after AP-800AX is restarted. - If you do not want to apply the configuration change, reset it to the previous settings and click Save Config at the bottom right of the Web page.

  • Page 132: Time Settings

    7-2-1. Time Sync with NTP Server NTP Feature AP-800AX can get the time information from the NTP server in the wired LAN network. - When there is no NTP server in the network, the system time will start from 0.
  • Page 133 AP-800AX User's Manual 7. Basic Functions The Time Configuration page is displayed. Configure each setting and click Save Config. - If other settings are clicked from the left menu before clicking Save Config, the entered values will be cleared. Be sure to click Save Config to save the current values when you move to the other page.
  • Page 134 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 135: Time Setting On Web Page

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click General Conf. - Time from the page menu.
  • Page 136 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 137: Transmission Rate Setting For Stable Communication

    - To use the rate survey function, make sure that only one wireless station device is connected to AP-800AX. - The wireless station device must have an IP address that can communicate with AP-800AX. - When the connected wireless station device supports only IEEE 802.11a/b/g, the rate survey function cannot be used.
  • Page 138 AP-800AX User's Manual 7. Basic Functions The Rate Survey page is displayed. Enter the IP address of the wireless station device connected to AP-800AX in Station IP Address and click Survey Start. The Survey Result page is displayed. Check the result and set the transmission rate according to the environment.

  • Page 139: Applying Transmission Rate

    Note - There are no obstacles between AP-800AX and the wireless station. - AP-800AX and wireless station are not too far (recommended distance is 20m or shorter). - Available channel and bandwidth setting are properly configured. This document explains a method for Disabling the transmission rate causing a large number of failures as example.

  • Page 140: Disabling The Transmission Rate Causing A Large Number Of Failures

    AP-800AX User's Manual 7. Basic Functions Disabling the transmission rate causing a large number of failures The procedure for disabling the transmission rate causing a large number of failures is explained by using the below survey result as an example.
  • Page 141 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.
  • Page 142 AP-800AX User's Manual 7. Basic Functions The configuration load message is displayed. When the screen changes, it is finished.

  • Page 143: Network Separation Using Vlan

    7-4. Network Separation Using VLAN 7-4-1. VLAN Feature A VLAN ID can be set to the SSID of wireless LAN structured by AP-800AX. If AP-800AX is used with the switching HUB that supports tagged-VLAN (hereinafter the "VLAN HUB"), you can establish the virtual network groups.

  • Page 144: Vlan Configuration

    AP-800AX User's Manual 7. Basic Functions 7-4-2. VLAN Configuration This chapter explains how to install AP-800AX to where network groups have already been established using a VLAN HUB. How to check the VLAN information on network Check the information below of the existing network.

  • Page 145: How To Configure The Vlan Setting On Ap-800Ax

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Detail Conf. - VLAN from the page menu.
  • Page 146 VLAN ID of the devices connected to the HUB that you have checked beforehand. - After VLAN feature is enabled, you will not be able to configure AP-800AX via the network with a different VLAN ID from management VLAN ID.
  • Page 147 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 148: How To Connect Ap-800Ax To A Trunk Port Of Vlan Hub

    Establish the Virtual Network Groups - After the VLAN feature is enabled, you will not be able to configure AP-800AX via the network with a different VLAN ID from management VLAN ID. If you are not sure of the VLAN ID of the management VLAN, you will need to initialize the settings and reconfigure AP-800AX.

  • Page 149: Device Filter Setting

    AP-800AX User's Manual 7. Basic Functions 7-5. Device Filter Setting It is possible to block access from particular devices to AP-800AX. MAC Address filter can respectively be set for a wireless interface. 7-5-1. MAC Address Filter Setting Filter Type By registering the MAC Address to a list, access of devices is allowed or denied based on the filter type below.

  • Page 150: Mac Address List

    By registering the vendor code portion (first 6 digits) of the MAC Address, it is possible to control access from devices with the registered vendor code. To register, create a list of MAC Addresses as a text file and import it to AP-800AX from the Web page.

  • Page 151: Mac Address Filter Settings

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - Wireless Detail - Security 5GHz/Security 2.4GHz from the page menu.
  • Page 152 AP-800AX User's Manual 7. Basic Functions Select Filter Type for MAC Address Filter. Click Choose File and specify a file containing a list of the MAC Addresses. Check the configuration file you have selected is displayed at the New Configuration File field.
  • Page 153 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.
  • Page 154 AP-800AX User's Manual 7. Basic Functions The configuration load message is displayed. When the screen changes, it is finished.

  • Page 155: Protocol Filter Setting

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Security - Access Control from the page menu.
  • Page 156 Do it later when all necessary settings are configured. When the Apply Config page is displayed, click Restart. The new settings will take effect after AP-800AX is restarted. - If you do not want to apply the configuration change, reset it to the previous settings and click Save Config at the bottom right of the Web page.

  • Page 157: Ieee 802.1X Authentication

    To use the IEEE 802.1X authentication, a RADIUS server is needed. 7-6-1. Network Configuration Connect the AP-800AX to a network as below when you use the IEEE 802.1X authentication. IP Address of RADIUS server and port number of EAPOL can be set.

  • Page 158: Ieee 802.1X Authentication Settings

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - SSID Management 5GHz/SSID Management 2.4GHz from the page menu.
  • Page 159 - After AP-800AX is powered on, it switches the authentication server back to the primary server every 10 minutes. The authentication server is switched to the primary server even if...
  • Page 160 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 161: Fast Roaming For Wireless Station Devices

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - SSID Management 5GHz/SSID Management 2.4GHz from the...
  • Page 162 Select ENABLE for IEEE 802.11r Fast Transition and enter the value at Mobility Domain. Setting the same value on multiple AP-800AX units will simplify the authentication process when wireless station device roams between AP-800AX units. When finished entering the settings, click Save Config at the bottom right of the page.
  • Page 163 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 164: How To Disable Smart Wireless Setup

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - Wireless Detail - Smart Wireless Setup from the page menu.
  • Page 165 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 166: How To Filter Communication Between Wireless Station Devices

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Wireless Conf. - Wireless Detail - Security 5GHz/Security 2.4GHz from the page menu.
  • Page 167 AP-800AX User's Manual 7. Basic Functions Choose ON for Privacy Separator. Click Save Config at the bottom right of the page. - If other settings are clicked from the left menu before clicking Save Config, the entered values will be cleared. Be sure to click Save Config to save the current values when you move to the other page.
  • Page 168 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 169: Monitoring Operating Status

    AP-800AX User's Manual 7. Basic Functions 7-10. Monitoring Operating Status AP-800AX supports the SNMP function that can retrieve various status information using the SNMP manager. By configuring the SNMP settings, operating status for the SNMP- compatible devices can be monitored.
  • Page 170 - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Detail Conf. - SNMP from the page menu.
  • Page 171 Do it later when all necessary settings are configured. When the Apply Config page is displayed, click Restart. The new settings will take effect after AP-800AX is restarted. - If you do not want to apply the configuration change, reset it to the previous settings and click Save Config at the bottom right of the Web page.

  • Page 172: Led Light Off Setting

    7. Basic Functions 7-11. LED Light OFF Setting If the LED Off mode is enabled, all LEDs are turned off after AP-800AX is powered on. By enabling this setting, the power consumption can be reduced when there is no need to check the LED status.
  • Page 173 Do it later when all necessary settings are configured. When the Apply Config page is displayed, click Restart. The new settings will take effect after AP-800AX is restarted. - If you do not want to apply the configuration change, reset it to the previous settings and click Save Config at the bottom right of the Web page.
  • Page 174 AP-800AX User's Manual 7. Basic Functions A progress bar appears. The configuration is complete when the progress bar reaches the right end.

  • Page 175: Login Password Setting

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Security - Password from the page menu.

  • Page 176: Administrative Functions

    AP-800AX User's Manual 8. Administrative Functions Administrative Functions...

  • Page 177: Monitoring Status For Wireless Station Devices

    The status includes MAC address of devices and the radio strength. - This method cannot be used when AP-800AX is operating in Configuration Mode. For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page - Displaying Web Page Using Network Connection.

  • Page 178: Checking The Logs

    - Display may vary depending on the Web browser. - The log must record the correct time. For how to set the time of AP-800AX, see 7-2-1. Time Sync with NTP Server. 8-2-1. Saving the Logs to Syslog Server The following describes the procedure for outputting and saving the AP-800AX’s event logs...
  • Page 179 - When you are to continue the configuration on other pages, you do not have to click Apply Config yet. Note Do it later when all necessary settings are entered. When the Apply Config page is displayed, click Restart. The new settings will take effect after AP-800AX is restarted.
  • Page 180 AP-800AX User's Manual 8. Administrative Functions - If you do not want to apply the configuration change, reset it to the previous settings and click Save Config at the bottom right of the Web page. Remember that the changes will take effect Note after the restart.

  • Page 181: Downloading The Logs

    Details of each log are as follows. System Log Power-on status, operating status, etc. of AP-800AX are saved as a log file. In case of a network trouble, you can check the operating status by referring the retrieved system logs.
  • Page 182 AP-800AX User's Manual 8. Administrative Functions The Log page is displayed. Click Execute at Output system logs to a file. The message for compressed file of all system logs appears. Click Open file or ". . ." for the desired option.

  • Page 183: How To Download Event Log

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Status - Log from the page menu.

  • Page 184: Monitoring Communication Status By Linking To Amc Cloud

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Detail Conf. - Cloud from the page menu.
  • Page 185 If these are changed, it will be applied on both pages. - It is recommended to configure the NTP setting to get the correct time when AP-800AX has received the data. For the configuration method, refer to 7-2-1. Time Sync with NTP Server.
  • Page 186 AP-800AX User's Manual 8. Administrative Functions A progress bar appears. The configuration is complete when the progress bar reaches the right end.

  • Page 187: Maintenance Functions

    AP-800AX User's Manual 9. Maintenance Functions Maintenance Functions...

  • Page 188: Restarting

    - Before you start, please make sure that no PCs are currently linked. 9-1-1. Manual reboot at the unit side Remove a LAN cable (the one connects to PoE HUB) from "LAN/PoE" port of AP-800AX and re-insert it again. AP-800AX...

  • Page 189: Remote Restart From The Web Page

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Maintenance - Restart from the page menu.

  • Page 190: Updating Firmware

    AP-800AX User's Manual 9. Maintenance Functions 9-2. Updating Firmware This chapter explains how to update the AP-800AX firmware. Firmware 9-2-1. Downloading the The latest firmware file can be downloaded from our website. See the instructions below to download the firmware file.

  • Page 191: Updating The Firmware

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Maintenance - Firmware Update from the page menu.
  • Page 192 AP-800AX User's Manual 9. Maintenance Functions Click Update. Click OK in a confirmation message. The firmware update will begin. When the login page is displayed, the firmware update is completed. See the top right of the login page and check the version information is changed.

  • Page 193: Factory Default Configuration

    - Before you start, please make sure that no PCs are currently linked. - Do not turn off AP-800AX while resetting to factory default. - Do not press the RESET switch to turn on AP-800AX again after the factory default configuration. 9-3-1. Initialization Using the RESET Switch on AP-800AX Remove a LAN cable (the one connects to PoE HUB) from AP-800AX.
  • Page 194 When the SETTING LED turns orange (1), release the RESET switch (2). (2) Release the RESET switch (1) Check the SETTING LED turns orange The factory default configuration begins. When the POWER LED of AP-800AX turns green, the factory default configuration is completed. POWER LED...

  • Page 195: Initialization From The Web Page

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Maintenance - Initialize Settings from the page menu.
  • Page 196 - Since the IP address of AP-800AX is also reset to the default one when the factory default configuration is finished, the password configuration page may not be displayed correctly on the PC. In such a case, change the IP address of AP-800AX or of the PC so that they can communicate each other.

  • Page 197: Configuration Import/Export Using Configuration File

    AP-800AX con g.txt - The configuration file you can import to AP-800AX must be the one you had exported from AP- 800AX. - After the configuration file is exported, please do not change the file name as well as edit the information.

  • Page 198: Import/Export From Web Page

    - When AP-800AX has the factory default settings, the password configuration page is displayed. Enter the password and click Submit. Note - For how to display the AP-800AX Web page, see 3-2-2. Displaying the AP-800AX's Web Page. Click Maintenance - Save Config - Export Configuration from the page menu.

  • Page 199: Importing Configuration File

    Click Maintenance - Save Config - Import Configuration from the page menu. The Import Configuration page is displayed. Click Choose File and specify the imported configuration file (config.txt). - The configuration file you can import to AP-800AX must be the one you had exported from AP-800AX. Note Check the configuration file you have selected is displayed at the New Configuration File field.
  • Page 200 - If the other settings have been changed in the previous steps, a restart confirmation message may appear. In that case, click Restart on the message to restart AP-800AX. The configuration is complete when the restart progress bar reaches the right end.

  • Page 201: List Of All Settings

    AP-800AX User's Manual A. List of All Settings List of All Settings...

  • Page 202: A-1. General Configuration

    AP-800AX User's Manual A. List of All Settings A-1. General Configuration The following describes the basic setting items that can be configured on the Web page. A-1-1. Network Configuration IP Configuration Item DHCP Client When this setting is enabled, an IP address is automatically obtained from a DHCP server.
  • Page 203 AP-800AX User's Manual A. List of All Settings Item DNS Server (Primary) Set a primary DNS server address. Details When DHCP Client is enabled, the DNS server address obtained by DHCP will be applied. Range 0.0.0.0 to 255.255.255.255 Default Value 0.0.0.0...

  • Page 204: A-1-2. Time Configuration

    A. List of All Settings A-1-2. Time Configuration Time Configuration Item Current Time Change the time setting of AP-800AX. Details Check the Use time information below check box and specify the time. Range 2020/01/01 00:00:00 to 2036/01/01 00:00:00 Default Value * Displays the time when the time configuration page is accessed.

  • Page 205: A-2. Wireless Configuration

    AP-800AX User's Manual A. List of All Settings A-2. Wireless Configuration The following describes the wireless setting items that can be configured on the Web page. A-2-1. Wireless General Configuration 5GHz Configuration Item Wireless Mode Details Select the IEEE 802.11 wireless mode.
  • Page 206 The channel you can use will differ depending on the country. * If W53 or W56 channels are used when AP-800AX is turned on or a particular radar is detected, wireless communication is lost for certain period of time (*).
  • Page 207 Set the transmission strength for wireless LAN. When the strength is reduced, AP-800AX's radio communication range will be Details shortened and the area where AP-800AX can be searched will be narrowed. Narrowing down the search area may avoid causing interference to other wireless networks.
  • Page 208 AP-800AX User's Manual A. List of All Settings 2.4GHz Configuration Item Wireless Mode Details Select the IEEE 802.11 wireless mode. 802.11ax : Uses IEEE 802.11ax, IEEE 802.11n, IEEE 802.11b or IEEE 802.11g. 802.11n/b/g : Uses IEEE 802.11n, IEEE 802.11b or IEEE 802.11g.
  • Page 209 Set the transmission strength for wireless LAN. When the strength is reduced, AP-800AX's radio communication range will be Details shortened and the area where AP-800AX can be searched will be narrowed. Narrowing down the search area may avoid causing interference to other wireless networks.

  • Page 210: A-2-2. Ssid Management 5Ghz

    (xxxxxx is the last 6 digits of the MAC Address.) Item Stealth Mode Enable/Disable the Stealth Mode when the Interface is enabled. If the Stealth Mode is enabled, AP-800AX is not discovered by the Access Point Details search. * Also, the Smart Wireless Setup function cannot be used.
  • Page 211 AP-800AX User's Manual A. List of All Settings Item Network Authentication Select the network authentication mode that will be used to connect to your wireless devices when the Interface is enabled. Details To ensure a secure network, it is recommended to use WPA/WPA2/WPA3. For IEEE 802.11n/802.11ac/802.11ax, only AES can be used.
  • Page 212 AP-800AX User's Manual A. List of All Settings Item IEEE 802.11r Fast Transition Enable/Disable the IEEE 802.11r fast roaming function when the Network Authentication is WPA2-Personal / WPA3-Personal / WP2/WPA3-Personal / WPA2-Enterprise / WPA3-Enterprise / WPA2/WPA3-Enterprise. This is the function to realize high-speed roaming.
  • Page 213 AP-800AX User's Manual A. List of All Settings WPA/WPA2/WPA3 Configuration This needs to be set only when the network authentication is WPA2-Personal, WPA3- Personal, WPA/WPA2-Personal, WP2/WPA3-Personal, WPA2-Enterprise, WPA3-Enterprise, WPA/WPA2-Enterprise, WPA2/WPA3-Enterprise or WPA3-Enterprise 192bitsecurity. Item Encryption Mode Select the encryption mode to use for WPA2-Personal, WPA3-Personal, WPA/...
  • Page 214 AP-800AX User's Manual A. List of All Settings RADIUS Server Configuration (Primary Server / Secondary Server) This needs to be set only when the network authentication is WPA2-Enterprise, WPA3-Enterprise, WPA/WPA2-Enterprise, WPA2/WPA3-Enterprise, WPA3-Enterprise 192-bit security. Item Server IP Details Set the IP Address of RADIUS server.

  • Page 215: A-2-3. Ssid Management 2.4Ghz

    (xxxxxx is the last 6 digits of the MAC Address.) Item Stealth Mode Enable/Disable the Stealth Mode when the Interface is enabled. If the Stealth Mode is enabled, AP-800AX is not discovered by the Access Point Details search. * Also, the Smart Wireless Setup function cannot be used.
  • Page 216 AP-800AX User's Manual A. List of All Settings Item Network Authentication Select the network authentication mode that will be used to connect to your wireless devices when the Interface is enabled. Details To ensure a secure network, it is recommended to use WPA/WPA2/WPA3. For IEEE 802.11n/802.11ax, only AES can be used.
  • Page 217 AP-800AX User's Manual A. List of All Settings Item IEEE 802.11r Fast Transition Enable/Disable the IEEE 802.11r fast roaming function when the Network Authentication is WPA2-Personal / WPA3-Personal / WP2/WPA3-Personal / WPA2-Enterprise / WPA3-Enterprise / WPA2/WPA3-Enterprise. This is the function to realize high-speed roaming.
  • Page 218 AP-800AX User's Manual A. List of All Settings WPA/WPA2/WPA3 Configuration This needs to be set only when the network authentication is WPA2-Personal, WPA3- Personal, WPA/WPA2-Personal, WP2/WPA3-Personal, WPA2-Enterprise, WPA3-Enterprise, WPA/WPA2-Enterprise, WPA2/WPA3-Enterprise or WPA3-Enterprise 192bitsecurity. Item Encryption Mode Select the encryption mode to use for WPA2-Personal, WPA3-Personal, WPA/...
  • Page 219 AP-800AX User's Manual A. List of All Settings RADIUS Server Configuration(Primary Server / Secondary Server) This needs to be set only when the network authentication is WPA2-Enterprise, WPA3- Enterprise, WPA/WPA2-Enterprise, WPA2/WPA3-Enterprise or WPA3-Enterprise 192bitsecurity. Item Server IP Details Set the IP Address of RADIUS server.

  • Page 220: A-2-4. Amc Mesh Configuration

    AP-800AX User's Manual A. List of All Settings A-2-4. AMC Mesh Configuration General Configuration Item Mesh Mode Set the AMC Mesh operation mode to make communication between the Access Points. Details The AMC Mesh network consists of one RootAP (host) and plural Repeater APs (station).

  • Page 221: A-2-5. Rate Survey

    -90 to 0 Default Value Item Max Hop Number Specify the maximum number of hops to allow between RootAP and AP-800AX when the Mesh Mode is Repeater. Details By increasing the number of hops, the AMC Mesh network can be expanded but throughput and latency decrease.

  • Page 222: A-2-6. Wireless Detail

    (first 6 digits) of the MAC address, it is possible Details to control access from devices with the registered vendor code. To register, create a list of MAC Addresses as a text file and import it to AP-800AX from the Web page. 00:00:00:00:00:01 to FF:FF:FE:FF:FF:FF...

  • Page 223: Extension Configuration 5Ghz

    AP-800AX User's Manual A. List of All Settings Extension Configuration 5GHz Extension Configuration Item Beacon Interval(msec) Details Set the beacon transmission interval (millisec). Range 20 to 1000 Default Value Item DTIM Details Set the DTIM interval for a wireless LAN.
  • Page 224 AP-800AX User's Manual A. List of All Settings Item Short Guard Interval Enable/Disable the Short Guard Interval (ON/OFF). If this is enabled (ON), higher throughput could be achieved. Details This can be set only when the Wireless Mode is 802.11n/a or 802.11ac.
  • Page 225 AP-800AX User's Manual A. List of All Settings QoS (WMM) Configuration (for AP) Item Details Change the QoS setting for BE(Best Effort) of WMM-EDCA. ECWmin : 1 to 15 ECWmax : 1 to 15 AIFSN : 1 to 15 Range...
  • Page 226 AP-800AX User's Manual A. List of All Settings QoS (WMM) Configuration (for Station) Item Details Change the QoS setting for (BE: Best Effort) of WMM-EDCA. ECWmin : 1 to 15 ECWmax : 1 to 15 AIFSN : 1 to 15...
  • Page 227 AP-800AX User's Manual A. List of All Settings Item Details Change the QoS setting for (VO: Voice) of WMM-EDCA. ECWmin : 1 to 15 ECWmax : 1 to 15 AIFSN : 1 to 15 Range TxOPLimit : 0 to 8192 : ON/OFF * TxOPLimit must be a multiple of 16.
  • Page 228 A. List of All Settings Spatial Reuse Configuration Item Spatial Reuse This is the function to transmit radio waves from AP-800AX without handling carrier sensing, when other IEEE 802.11ax compatible devices have signal strength lower the threshold. Details Chances of transmission can be increased even in congested wireless network, which leads to improvements on throughput.

  • Page 229: Security Configuration 2.4Ghz

    (first 6 digits) of the MAC address, it is possible Details to control access from devices with the registered vendor code. To register, create a list of MAC Addresses as a text file and import it to AP-800AX from the Web page. 00:00:00:00:00:01 to FF:FF:FE:FF:FF:FF...

  • Page 230: Extension Configuration 2.4Ghz

    AP-800AX User's Manual A. List of All Settings Extension Configuration 2.4GHz Extension Configuration Item Beacon Interval(msec) Details Set the beacon transmission interval (millisec). Range 20 to 1000 Default Value Item DTIM Details Set the DTIM interval for a wireless LAN.
  • Page 231 AP-800AX User's Manual A. List of All Settings Item Short Guard Interval Enable/Disable the Short Guard Interval (ON/OFF). If this is enabled (ON), higher throughput could be achieved. Details This can be set only when the Wireless Mode is 802.11n/b/g.
  • Page 232 AP-800AX User's Manual A. List of All Settings QoS (WMM) Configuration(for AP) Item Details Change the QoS setting for BE(Best Effort) of WMM-EDCA. ECWmin : 1 to 15 ECWmax : 1 to 15 AIFSN : 1 to 15 Range TxOPLimit : 0 to 8192 *TxOPLimit must be a multiple of 16.
  • Page 233 AP-800AX User's Manual A. List of All Settings QoS (WMM) Configuration(for Station) Item Details Change the QoS setting for (BE: Best Effort) of WMM-EDCA. ECWmin : 1 to 15 ECWmax : 1 to 15 AIFSN : 1 to 15 TxOPLimit...
  • Page 234 AP-800AX User's Manual A. List of All Settings Item Details Change the QoS setting for (VO: Voice) of WMM-EDCA. ECWmin : 1 to 15 ECWmax : 1 to 15 AIFSN : 1 to 15 Range TxOPLimit : 0 to 8192 : ON/OFF *TxOPLimit must be a multiple of 16.
  • Page 235 A. List of All Settings Spatial Reuse Configuration Item Spatial Reuse This is the function to transmit radio waves from AP-800AX without handling carrier sensing, when other IEEE 802.11ax compatible devices have signal strength lower the threshold. Details Chances of transmission can be increased even in congested wireless network, which leads to improvements on throughput.

  • Page 236: Smart Wireless Setup

    WirelessLAN 2.4GHz I/F 1 / WirelessLAN 2.4GHz I/F 2 / WirelessLAN 2.4GHz I/F 3 / WirelessLAN 2.4GHz I/F 4 Default Value WirelessLAN 5GHz I/F 1 Smart Wireless Setup Execute This is not displayed when AP-800AX is operating in Configuration Mode. Item Push Button Click Execute to start the Smart Wireless Setup. Details...

  • Page 237: A-3. Detail Configuration

    DISABLE LED Management Item LED OFF mode When this setting is enabled, all LEDs of AP-800AX turn off. As the result, power consumption can be reduced. * AP-800AX needs to be restarted after this setting is enabled. Details * Since all LEDs are turned off, operating status of AP-800AX cannot be checked by the LED lighting pattern.

  • Page 238: A-3-2. Dhcp Server Configuration

    Item DHCP Server Function Enable/Disable the DHCP server function. Select ENABLE to run AP-800AX as a DHCP server to automatically assign an IP Details address to the PC. Select DISABLE if you already have a DHCP server on the network.

  • Page 239: A-3-3. Vlan Configuration

    Default Value Item Management VLAN ID Set the management VLAN ID to access AP-800AX when the VLAN is enabled. Details When the VLAN function is enabled, AP-800AX can be accessed only from the network groups with the management VLAN ID.

  • Page 240: A-3-4. Snmp Configuration

    1 to 4094 Default Value A-3-4. SNMP Configuration SNMP Configuration Item Read Community Name Details Set the SNMP community name to use for reading the AP-800AX information. Range 1 to 31 alphanumeric characters Default Value public SNMPv3 Configuration Item SNMPv3 Details Enable/Disable the SNMPv3.

  • Page 241: A-3-5. Log Output

    AP-800AX User's Manual A. List of All Settings Authentication Configuration Configure the followings when the SNMP3 is enabled. Item Authentication Details Enable/Disable the Authentication. Range ENABLE/DISABLE Default Value DISABLE Item Hash Details Set the Hash when the Authentication is enabled.

  • Page 242: A-3-6. Cloud Configuration

    Range ENABLE/DISABLE Default Value DISABLE Item Status Upload Interval (min) Set the interval for AP-800AX to upload the collected wireless status information to Details AMC Cloud (in minutes) when the Cloud is enabled. Range 10 to 60 Default Value Item...
  • Page 243 AP-800AX User's Manual A. List of All Settings Proxy Configuration Item Proxy Function Details Enable/Disable communications through a proxy server. Range ENABLE/DISABLE Default Value DISABLE Item Proxy Server Set the domain name or the IP address of proxy server to use when the Proxy Details Function is enabled.

  • Page 244: A-4. Security

    A-4-2. Access Control Access Control Item HTTP Allow/Deny access using HTTP via a wired/wireless LAN. Details When set to ENABLE, access to AP-800AX is allowed. When set to DISABLE, access to AP-800AX is denied. Range ENABLE/DISABLE Wired LAN : ENABLE Default Value...

  • Page 245: A-4-3. Server Certificate Create

    A. List of All Settings A-4-3. Server Certificate Create Server Certificate Create Item Common Name Details Set a name of AP-800AX. Range 1 to 64 characters Default Value SXxxxxxx (xxxxxx is the last 6 digits of the MAC Address) Item...

  • Page 246: Reference Information

    AP-800AX User's Manual B. Reference Information Reference Information B-1. Upper Limit for Transmission Strength The transmission strength setting (Transmit Power (dBm)) is a theoretical value. Actual transmission strength may be limited by the combination of transmission strength, wireless mode, bandwidth and channel.

  • Page 247: Troubleshooting

    AP-800AX User's Manual C. Troubleshooting Troubleshooting This chapter provides the solutions for possible troubles you may experience when you are configuring or using the AP-800AX.

  • Page 248: C-1. Problems During The Setup

    AMC Manager®. AP-800AX does not show up in the wireless network list on Windows. If AP-800AX is not displayed in the wireless network list on Windows, you need to check the installation status, network environment and computer settings. If you intend to setup AP-800AX via a wireless network, please confirm that the wireless adapter is enabled on your PC.
  • Page 249 How should I determine the way to assign an IP address to AP-800AX? There are two ways to assign an IP address to AP-800AX; one is to Get IP address automatically from DHCP server and the other is to Assign IP address manually. Choose the way to assign an IP address according to your environment.
  • Page 250 • Assign an IP address unique in the network. • Assign an IP address that has the same address class as the PC that will use AP-800AX. e.g. When an IP address of the PC is "192.168.0.xx", assign an address such as "192.168.0.100"...

  • Page 251: C-2. Problems On Wireless Access Point Feature

    I cannot connect to AP-800AX wirelessly. Please check the operation status and configuration of AP-800AX. The wireless LAN setting may differ between AP-800AX and the connected wireless station device. Solution Connect a LAN cable to AP-800AX and check the wireless LAN settings.
  • Page 252 AP-800AX User's Manual C. Troubleshooting Communication speed is too slow. An older wireless standard may be selected for Wireless Mode of AP-800AX. Check that Wireless Mode of AP-800AX is set to 802.11ax. Solution The connected wireless station device may not support the latest wireless standard.

  • Page 253: C-3. Problems For Connecting Multiple Ap-800Ax Units

    C-3. Problems for Connecting Multiple AP-800AX Units AP-800AX fails to connect to the existing AMC Mesh network. The wireless setting or AMC Mesh setting of AP-800AX may differ from the setting of that AMC Mesh network. Configure the same wireless setting, Mesh group name and Mesh encryption key to AP- Solution 800AX as that of the AMC Mesh network.

  • Page 254: C-4. Checking Troubles On The Event Logs

    C. Troubleshooting C-4. Checking Troubles on the Event Logs By obtaining the event logs, you can check the status of AP-800AX when the troubles occur. Refer to 8-2-2. Downloading the Logs - How to Download Event Log for how to obtain the event logs.

  • Page 255: Product Information And Customer Services

    AP-800AX User's Manual D. Product Information and Customer Services Product Information and Customer Services D-1. Product Information The services below are available from the Silex Technology website. For details, please visit the Silex Technology website. https://www.silextechnology.com/ - Latest firmware download...

Table of Contents
