POVISON SF8188 Assembly Instructions

1. Use screws to connect the backrest to the seat cushion (required for each sofa module).
position reference, please install with the bottom side facing you to facilitate the screws from the bottom
cushion
2. Pour the sofa down and install the support feet
corresponding to the holes (required for each sofa module)
backrest
Socket Head Cap + Spring gaskets
Screw(M8*60mm)
3. Pour the sofa down and install the Mid-support feet
corresponding to the holes (required for each sofa module)
Socket Head Cap
Screw(M8*30mm)
+Gasket
Note:The diagram is for
Perspective after being put down
backrest
cushion
Serial
number
Assembly instructions
SF8188 Installation
The number of people needed for installation：2
①
Please read the manual carefully before
installing this product. And strictly
follow the installation process
② Please take good care of this manual
for your next installation
③ Note: Before installation, screw all
the screws to 1/2 of the length of
the installation. After all screws
are half screwed in, tighten them all
together.
On a red ribbon are furniture
Parts list
installation accessories
Quantity
Shape Name required for
installation
Socket Head Cap
A
36
Screw(M8*30mm)
Socket Head Cap
B
12
Screw(M8*60mm)
Socket Head Cap
C
12
Screw(M6*30mm)
D
12
Spring gaskets
E
36
Gasket
F
2
Wrench(6mm and 8mm)
G
6
Mid-support feet
TotaL 2 page; page 1
Spare
quantity
0
0
0
0
0
0
0
