Barco I600 Quick Start Manual

Environment conditions
Environment
Ambient temperature
Humidity
Altitude
Air cleanness
WARNING: Ensure that the physical environment in which the projector is installed, complies at all
times with the environmental requirements summarized in this chapter! Never use the projector in
case not all requirements are fulfilled. Neglecting will damage the projector and will void the
warranty.
Remote control & local keypad
1
2
3
4
5
6
7
1 Shutter close 7 Input selection
2 Shutter open 8 Power On/Off
3 Button pressed 9 OSD On/Off
4 Lens menu 10 Confirmation
5 Navigation 11 Menu enter/exit
6 Menu back 12 Test patterns
1. Equivalent with cleanroom standard ISO 14644-1 ISO Class 9.
R5917381 /01 | 2024-08-16
Operating
5°C (41°F) to 40°C (104°F)
10% RH to 80% RH Non-condensed
0 m (0 Ft) to 2500 m (8202 Ft)
Clean office environment
8
9
10
11
12
1 Navigation
2 Confirmation
3 Menu enter/exit
4 Menu back
5 Power On/Off
6 OSD On/Off
Quick Start Guide
Non-Operating
-20°C (-4°F) to 60°C (140°F)
10% RH to 90% RH Non-Condensed
-60 m (-197 Ft) to 10000 m (32810 Ft)
n.a.
1
1
11 10
ENABLING BRIGHT OUTCOMES
I600
2 3 4 5 6
9 8 7
7 Input selection
8 Shutter open/close
9 Test patterns
10 Lens menu
11 LCD touch panel
