Bowflex Treadclimber TC200 Troubleshooting Manual

3/12/24, 10:56 AM
Treadclimber TC200: Why are the buttons not responding on the
console?
Follow this troubleshooting guide to help resolve issues with buttons not responding on the console of your Treadclimber TC200
Some common complaints may include:
Buttons don't respond
Buttons not responding
Buttons don't work
Can't adjust speed
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
4mm hex/Allen wrench or the wrench from the hardware
card included with your machine
13mm open-ended wrench
1.
Check if the console display is blank. If it is blank, please continue troubleshooting here:
is there no power to my machine or console?
2.
If the display is not blank, look for any error codes that may be displayed. If an error code is displayed or was
displayed recently and cleared, please continue troubleshooting
error message displayed on my console?
3.
If the issue persists, check the input/output cables at the motor control board (MCB), the top and base of the right
upright, and at the back of the console.
4.
To access the MCB, use a Phillips head screwdriver to remove the 2 screws from the rear cover and set the cover to the
side (reference 1). Remove the 2 screws attaching the motor compartment cover using a Phillips head screwdriver
(reference 2). Lift and remove the motor compartment cover. Use a Phillips head screwdriver to remove the 2 screws
from the left pivot cover, remove the cover, then remove the lower screw underneath where the cover was
attached (reference 3). Remove the 5 screws attaching the left side cover to the treadle with a Phillips head
screwdriver and slide the cover off of the machine (reference 4).
about:blank
Treadclimber TC200:  Why are the buttons not responding on the console?
(Reference 1)
Treadclimber TC200: Why
here: Treadclimber TC200: How can I clear an
ID: 13021.1
1/7
