Treadclimber TC200: Why is there no power to my machine or console?
Follow this troubleshooting guide to help resolve power issues on your Treadclimber TC200.
Some common complaints may include:
Console does not power on
No power to machine
Machine won't turn on
Display is dark
Console doesn't light up
Follow these steps to troubleshoot the issue
Tools you may need:
Phillips head screwdriver
4mm hex/Allen wrench or the wrench from the hardware
card included with your machine
13mm open-ended wrench
1.
Unplug the power cord from both your machine and the wall outlet. Inspect the entire length of the cord for any
damage or crimps. If undamaged, plug the power cord back in at both ends. Make sure it is securely connected. Flip
the on/off switch and see if it glows. If damage is present,
2.
If the on/off switch does not glow, confirm that the wall outlet is working properly. The power cord must be plugged
directly into a 3-prong outlet without the use of extension cords. Plug another device into the outlet, such as a lamp,
to see if it turns on. If it is not working, try again with a working outlet [13003.B]. If the issue persists,
Inlet Assembly [13003.C].
3.
If the on/off switch is glowing, unplug your machine from power again and wait 5 minutes before continuing. While
you wait, remove the rear cover, motor compartment cover, and left side cover. Using a Phillips head screwdriver,
remove the 2 screws from the rear cover and set the cover to the side (reference 1). Remove the 2 screws attaching
the motor compartment cover using a Phillips head screwdriver (reference 2). Lift and remove the motor
compartment cover. Use a Phillips head screwdriver to remove the 2 screws from the left pivot cover, remove the
cover, then remove the lower screw underneath where the cover was attached (reference 3). Remove the 5 screws
attaching the left side cover to the treadle with a Phillips head screwdriver and slide the cover off of the machine
(reference 4).
about:blank
Treadclimber TC200:  Why is there no power to my machine or console?
order a Power
(Reference 1)
Cord [13003.A].
ID: 13003.1
order a Power
