Project Source EVALIN TL-7650E-WL-PS Manual page 9

ASSEMBLY INSTRUCTIONS
10. Adjust threaded rods using locknuts so that the rods are
positioned just over and slightly touching the top of the half
flush and full flush mechanism. Note that the half flush is
the green tab and the full flush is the white tab.
11. Place the seat on the toilet, aligning the holes of the seat
with the holes in the back of the toilet bowl.
Secure nut from the bottom of toilet, use a regular
screwdriver to tighten to fit.
CAUTION: DO NOT OVERTIGHTEN THE SCREW AS IT
MAY CAUSE DAMAGE ON SEAT.
Hardware Used
KK Toilet Seat
MM
Seat Hardware
12. Push the decorative cap down.
10
x 1
x 2
12
9
11
