U-Line S-107 Instructions Manual

S-107, S-257, S-1717
S-3823, S-3824
POLY STRAPPING KIT
NOTE: These instructions show the metal buckle.
If using model numbers S-257, S-3823 or S-3824,
fold plastic buckle before proceeding.
(See Figure 1)
THREADING BUCKLES
1. Insert end of strapping up through center of buckle
and around open leg to form a loop. Pull top tight
around leg. (See Figure 2)
2. Wrap strapping around package. Loop strapping
around remaining open leg of buckle. Pull loop
tight around leg. (See Figure 3)
PAGE 1 OF 6
1-800-295-5510
uline.com
INSTRUCTIONS
3. Pull both top ends of strapping in opposite
Figure 1
USING TENSIONER AND CUTTER
1.
Figure 2
2. Pull tool to desired level of tension. (See Figure 6)
Figure 3
Pour le français, consulter les pages 5-6.
directions to manually tighten. (See Figure 4)
Place strapping between tensioner rods. Raising the
handle, flip tool 360 degrees. (See Figure 5)
Figure 5
Figure 6
Para Español, vea páginas 3-4.
Figure 4
0824 IS-107
