- Page 1 Merlin 1000S+i Gas & Electric Utility Controller Product Data Sheet Gas Safety Products Merlin 1000S+i Gas & Electric Utility Controller Installation, operating and maintenance 11/25/2015 American Gas Safety LLC...
- Page 2 Merlin 1000S+i Gas & Electric Utility Controller Product Data Sheet Table of contents General information ....................3 Installation ......................3 Panel Mounting......................3 Power Supply........................ 3 Gas solenoid valve......................3 Electric Contactor......................3 BMS Connections......................3 Timeout Facility.
-
Page 3: General Information
Building Management systems etc. Detailed on the circuit board as “BMS OUT N/C, COM and N/O” these are volt free connections. Timeout Facility. The Merlin 1000S+i has a built-in Auto-shut down feature and it will turn itself off after predefined time. Auto-shut down timeout is selectable. There are two dip- switches located on the inside facia of the Merlin 1000S+i labelled “Time1”... - Page 4 3.2.1 Power LED When the system is connected to the mains supply, the Red LED of the AGS Logo located in the bottom right corner of the panel will illuminate. When no power is present, this LED will not light up.
- Page 5 BMS integration The Merlin 1000S+i can be integrated with a BMS to make or break a circuit on gas on/gas off, (valve open or valve closed). This will tell the BMS whether or not power is being sent to the solenoid.
- Page 6 The Merlin 1000S+i has a built-in auto reset feature. There is a dip-switch located on the inside facia of the Merlin 1000S+i labelled “Auto Reset”. This is factory set in the ‘off’ position. When the power is restored after the power cut, the panel has to be restarted manually.
- Page 7 Fax: (727) 538-4237 info@americangassafety.com Date Author Description Merlin 1000S+i Product Data Sheet – Third issue 11.25.15 American Gas Safety CD + BT + CM American Gas Safety is the owner of this document and reserves all rights of modification without prior notice.
