- Page 1 Merlin 1000Si Gas Utility Controller User & Installation Manual Gas Safety Products Merlin 1000Si Gas Utility Controller Installation, operating and maintenance Read these instructions carefully before operating or servicing Rev: 04 Date: 22-10-18...
-
Page 2: Table Of Contents
Merlin 1000Si Gas Utility Controller User & Installation Manual Table of contents GENERAL INFORMATION ................... 3 INSTALLATION & CONNECTION ................. 3 Panel Mounting ......................3 1000Si Circuit Board Terminals ..................3 POWER [1] ........................4 GAS VALVE [2] ....................... 4 BMS OUT [3] ........................ -
Page 3: General Information
User & Installation Manual GENERAL INFORMATION The Merlin 1000Si is a gas isolation & gas detection utility controller. The Merlin 1000Si can receive connections from remote emergency shut-off buttons, gas detectors and a CO2 monitor. It can also be integrated with a BMS and fire alarm. -
Page 4: Power [1]
Merlin 1000Si Gas Utility Controller User & Installation Manual POWER [1] Mains Power Supply A 110-120VAC Single Phase electrical supply should be supplied to the panel. This should be externally fused at 3 Amps using a fused or circuit breaker. -
Page 5: Internal Buzzer
2.12 PANEL TIMEOUT FACILITY The Merlin 1000Si has a built-in Auto-shut down feature and it will turn itself off after a predefined time. Auto-shut down timeout is selectable. There are two Dip-Switches located on the inside facia of the system labelled [Time1] and [Time2]. -
Page 6: Em Stop
BUILDING MANAGEMENT SYSTEM INTERGRATION The Merlin 1000Si can be integrated with a BMS to make or break a circuit on gas on/gas off, (valve open or valve closed). This will tell the BMS whether or not power is being sent to the solenoid. -
Page 7: Fan Switch Intergration
Note: This option is not available if a Fan Switch is not installed. AUTO-RESET The Merlin 1000Si has a built-in auto reset feature. There is a dip-switch located on the inside facia of the Merlin 1000Si labelled [Auto Reset]. This is factory set in the ‘OFF’ position, this means, if you experience a power cut, the panel has to be restarted manually. -
Page 8: 1000Si Wiring
Merlin 1000Si Gas Utility Controller User & Installation Manual 1000Si WIRING [LNE POWER] Input 110-120VAC Single Phase. [LNE GAS VALVE] Output 110-120VAC, Max 3A. [BMS OUT] Max.1A @ 110-120VAC. [EM REMOTE] Remote EM Stop buttons and Fire Alarm input wired in series (sold separately). - Page 9 Merlin 1000Si Gas Utility Controller User & Installation Manual INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL & ELECTRONIC EQUIPMENT When this product has reached the end of its life it must be treated as Waste Electrical & Electronics Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste, but kept separate for the treatment, recovery and recycling of the materials used.
