CyClone BX600 Quick Installation Manual

Hide thumbs Also See for BX600:

Download this manual

1361 Huntingwood Drive, Unit 15 & 16, Toronto ON M1S 3J1 – Tel: 416-293-0933 – Mail:

• THIS RANGE HOOD MUST BE INSTALLED USING 6" DIAMETER METAL DUCT

• THIS RANGE HOOD MUST BE INSTALLED AT A MINIMUM DISTANCE OF 30" ABOVE A

GAS STOVE OR 28" ABOVE AN ELECTRIC OR INDUCTION STOVE

• CYCLONE DOES NOT RECOMMEND THE USE OF FLEXIBLE DUCT AS IT CAN RESTRICT

AIRFLOW BY UP TO 50% WHICH CAN CAUSE EXCESS NOISE, VIBRATIONS & REDUCE

PERFORMANCE

• THIS RANGE HOOD REQUIRES A 3-PRONG GROUNDED OUTLET

• THIS RANGE HOOD IS RATED FOR INDOOR RESIDENTIAL USE ONLY

• TO PROPERLY CONNECT DUCT, IT IS RECOMMENDED TO HAVE AN ACCESS PANEL ON

THE FRONT OF THE CABINET

• WHEN CONNECTING THE DUCT TO THE GRAVITY DAMPER, DO NOT USE SCREWS AS

THEY MAY INTERFERE WITH THE MOVEMENT OF THE DAMPER FLAPS

<<FAILURE TO ADHERE TO THESE GUIDELINES MAY RESULT IN A VOID WARRANTY>>

*Damage or shortage must be reported to the vendor immediately*

**Claims for damage will not be accepted once the product has been installed**

Step 1:

Remove the product from the packaging and place it on a clean, ﬂat surface facing up. Peel oﬀ the

protective ﬁlm and carefully inspect the product to make sure there is no visible damage and that all

hardware and accessories are present. It is recommended to plug in the product and test all functions

prior to installing.

BX600 – QUICK INSTALLATION GUIDE

IMPORTANT!

service@cyclonerangehoods.com

Need help?

Do you have a question about the BX600 and is the answer not in the manual?

Page 1 • THIS RANGE HOOD MUST BE INSTALLED AT A MINIMUM DISTANCE OF 30” ABOVE A GAS STOVE OR 28” ABOVE AN ELECTRIC OR INDUCTION STOVE • CYCLONE DOES NOT RECOMMEND THE USE OF FLEXIBLE DUCT AS IT CAN RESTRICT AIRFLOW BY UP TO 50% WHICH CAN CAUSE EXCESS NOISE, VIBRATIONS & REDUCE PERFORMANCE •...
Page 2 Step 2: Remove the baﬄe ﬁlters. Step 3: Reach into the cavity of the hood and carefully disconnect the three wire harnesses. (one for each light and one for the push button controls) Step 4: Locate the four screws which are securing the face to the body. Turn the screws counter-clockwise to loosen and remove.
Page 3 Step 5: Lift straight up to remove the face and set aside. Step 6: Flip the product upside down to install the Gravity Damper using the six screws provided. Make sure the gasket is positioned in between the damper and the hood. Step 7: Insert the hood into the cabinet opening and secure with the four screws provided.
Page 4 Step 8: Reinstall the face and secure using the four screws that were removed in Step 4. Step 9: Reconnect the three wire harnesses that were disconnected in Step 3. Step 10: Connect and secure duct using HVAC rated aluminum tape. When connecting the duct to the gravity damper, DO NOT use screws and make sure the duct does not impede with the movement of the damper ﬂaps.
