  • Page 1 AccuStop User Guide Original Instructions Doc. no.: 14387001_A_en Date of release: 2024.10.03...
  • Page 2 Copyright The contents of this manual are the property of Struers ApS. Reproduction of any part of this manual without the written permission of Struers ApS is not allowed. All rights reserved. © Struers ApS. AccuStop...
  • Page 3: Table Of Contents

    Table of Contents Get started Device description Overview Check the packing list Accessories Adjusting AccuStop Grinding process Setting up and adjusting 3.1.1 Flangeform mounts 3.1.2 Cylindrical mounts or specimens Maintenance Cleaning Spare parts Disposal Manufacturer AccuStop...
  • Page 4: Get Started

    AccuStop 30 and AccuStop 40 can be used with a wide range of accessories for various applications. For information about the available range, see the AccuStop brochure on the Struers website. Note Only use AccuStop when grinding with SiC or Al grinding papers.
  • Page 5: Overview

    1   Get started Overview a Large 0,1 mm b Small 0,02 mm One complete rotation of AccuStop is 1 mm. 1. Specimen holding cylinder 2. Adjusting cylinder 3. Adjustment locking screw 4. Ceramic stop ring 5. Access hole (for specimen fixing screw) 6.
  • Page 6: Check The Packing List

    Brass disc Instruction Manual set Accessories For information about the available range, see the AccuStop brochure: • The Struers Website (http://www.struers.com) Adjusting AccuStop • Before you place the specimen in AccuStop, ensure that the adjusting cylinder (2) is in a position that will allow the amount of adjustment necessary...
  • Page 7 2   Adjusting AccuStop to remove all the desired material from the specimen. If the specimen fixing screw (6) is to be used, turn the cylinder until the access hole (5) is in line with the specimen fixing screw position. • Place the mount, insert, or specimen in AccuStop.
  • Page 8: Grinding Process

    3   Grinding process Grinding process Note Never use AccuStop with any type of diamond grinding. Grinding parameters Type of grinding Disc type Grit size Grinding depth Plane grinding SiC or AI 80-220# 0.5 to 1.0 mm Fine grinding SiC or AI 1200# 0.1 to 0.5 mm Adjust AccuStop to remove the desired amount of material, then use the plane...
  • Page 9: Setting Up And Adjusting

    3   Grinding process Setting up and adjusting 3.1.1 Flangeform mounts Ensure that the O-ring (7) is in the specimen holding cylinder (1) in AccuStop. There are two O-rings of different sizes: • O-ring 3 mm diameter: for use with Serifix mounts •...
  • Page 10: Maintenance

    Clean each of the pieces, including the screws and the brass washer, using soap and water, alternatively kerosene or cleaning gasoline. • Lightly grease the cylinder threads with a lubricant, e.g., Struers Klüber anti seize grease ALTEMP Q NB 50 or similar (grease with a small amount of solid lubricant).
  • Page 11: Spare Parts

    Pressure plate for AccuStop, 3 pcs. 438MP010 For further information, or to check the availability of spare parts, contact Struers Service. Contact information is available on Struers.com. Disposal Contact your local authorities for information on the correct method of disposal in accordance with national legislation.
  • Page 12: Manufacturer

    Responsibility of the manufacturer The following restrictions should be observed, as violation of the restrictions may cause cancellation of Struers legal obligations. The manufacturer assumes no responsibility for errors in the text and/or illustrations in this manual. The information in this manual is subject to change without notice.
