取扱説明書
Ver 1.00
TP-430
TAKIBIタープ オクタ

Advertisement

loading
Need help?

Need help?

Do you have a question about the Takibi Tarp Octa and is the answer not in the manual?

Questions and answers

Summary of Contents for Snow Peak Takibi Tarp Octa

  • Page 1 取扱説明書 Ver 1.00 TP-430 TAKIBIタープ オクタ...
  • Page 2 この度は、 スノーピーク製品をお買い上げいただき、 誠にありがと う ございます。 本製品は、 キャ ンプ用のタープで す。 安全にご使用いただ く ためにも下記の取扱説明書をよ く読んでから ご使用く ださい。 また、 読み終わった後も 大切に保管して く だ さい。 説明内容で理解出来ない点及び製品に不具合が確認された際には直ちに使用を中 止しご購入いただき ま した販売店様も し く は弊社ユーザーサービスまでお問い合わせ く だ さい。 安全上の注意事項  ご使用の前によ く 読んで予測さ れる事故を回避 し安全にご使用く だ さ い。 危険...
  • Page 3 警告 取扱いを誤った場合、 使用者が死亡または重傷を負う可能性がある こ と を示します。 ●ご使用の前に、 本製品を点検し各部に異常がないこ と を確認して く だ さ い。 異常が発見さ れた場合は、 直ち に使用を中止 しお買い求めいただいた販売店様、 または弊社ユーザーサービス係に点検または修理を依頼 して く だ さ い。 ●気象状況には常に細心の注意を払い、 風の強い時や悪天候が予想さ れる と きは速やかに撤収 して安全な 場所へ避難 して く だ さ い。 ●タープは表面積が大き く 体感風量よ り はるかに大きな力を受けます。 ご使用中はペグやロープが しっかり とつ ながれているかど...
  • Page 4 初めてお使いになる前に ●品質には万全を期 してお り ますが、 お使いになる前に必ず試 し張り を行い、 付属品や設営道具を確認 して く だ さ い。 万一不具合や付属品の欠品があった場合は、 お買い求めになった販売店様または弊社ユーザーサービスまで お問い合わせ く だ さ い。 ●本製品にはポール ・ ペグ ・ ハンマー等は含ま れてお り ません。  □基本的な設営には別売りのウ イ ングポール×2本、 ペグ ×8本が別途必要です。   下記の推奨サイ ズを ご参考の上、 ご用意 く だ さ い。  □推奨ポール...
  • Page 5 自在付ロープ ・ ペグダウンの位置 二又用 10m ロープ 二又用 10m ロープ 3m ロープ 2m ロープ 2m ロープ 280cm ウイ ングポール 3m ロープ 3m ロープ 各ロープの固定、 ペグダウ ンの位置は下図のよ う に行っ て く だ さ い。 グロメッ ト 2m 2m ペグ 自在 3m 3m ロープ返し部分...
  • Page 6 設営の手順 より安全に設営するためにも必ず2人以上で設営してください。 設営 ・ 撤収は以下の説明に従い繰り返 し練習 し、 実際のキ ャ ンプに備えて く だ さ い。 また、 付属品が全て揃っている か前もってご確認く だ さ い。 無理な設営 ・ 撤収は本体やフ レームや本体の破損や事故の原因にな り ます。 本書を よ く お読みにな り ご使用 く だ さ い。 タープを地面に広げます。 280cmウイ ングポール タープ本体を設営する平たんな場所に図のよ うに2 つ折りの状態で広げてく...
  • Page 7 タープの稜線を緩ませます。 二又用10mロープの自在の位置を調節し稜線を2割程度緩ませた状態に します。 この緩みが完成時の 美しい曲線を作り ます。 緩み 各コーナーにロープを取り付けペグダウンします。 4ページの 「自在付ロープ ・ ペグダウンの位置」 に従ってタープにロープを取り付けペグダウン してく ださ い。 ロープはタープの中心から両翼のコーナーを結ぶ延長線上 (各コーナーのグロメ ッ ト付テープの取り 付け方向の延長線上) に引っ張って く ださい。 ※ロープを引く方向が狂う と シワの原因にな り、 正し く設営するこ とができな く な り ますので注意して く だ さい。 ※この手順の後、 すき間を設けて打ち込んだペグを完全にペグダウン して く ださい。 中心...
  • Page 8 インナールーフの取り付け方法 イ ンナールーフには難燃性のある生地を使用 していますが、 誤って取り付け られた状態で焚火をする と、 火災の原因 と なる可能性があ り ます。 インナールーフのバックルを接続します。 タープ本体のバッ クルに手が届く よ うに一度ウイ ングポールを倒し、 イ ンナールーフの接続バッ クルを メ イ ンコーナーの内側に接続して く ださい。 接続バッ クルはベル トの端部が見える側が下になる向きで接続し て く ださい。 (2 カ所) 接続した後、 ウイ ングポールを立て直し、 イ ンナールーフの調整ベル トでテンショ ンを 調整して...
  • Page 9 両翼の中央を跳ね上げる場合 □両翼の中央を跳ね上げるこ とによ り、 タープ下の空間を広げるこ とができ ます。 両翼の中央を跳ね上げる場合、 通常の設営方法に加えてウイ ングポール×2とペグ×4が必要にな り ます。 下記の推奨サイ ズを ご参考の上、 ご 用意く だ さ い。 □推奨ポール ・ ペグサイ ズ  140cmウ イ ングポール×2本  打ち込み長さ25cm以上のペグ ×4本 (二又用ロープに使用) ロープを緩めます。 ウイ ングポールを入れるため、 ペグは刺したまま、 タープに取り付けられている2mロープを緩めて く ださい。 ( 4カ所) 2 mロープ ウイングポールを差し込みます。...
  • Page 10 各ロープのテンションを調節します。 ⑤ ⑥ 3mおよび2mロープから図の番号順に自在の位置 ① ④ を調節してテンショ ンを掛けてく ださい。 ロープは均 等な力で引き、 稜線の緩みが綺麗に取れた後に、 二 又用ロープのテンショ ンを掛けて く ださい。 最後にす べてのロープを も う一度、 番号順に引いて く ださい。 上か ら見た図 ③ ② ⑦ ⑧ 撤収の手順 必ず2人以上で撤収してください タープの下にものがないこ とを確認してから撤収を始めてく ださい。 インナールーフの下で焚火台 や燃焼器具を使用していた場合は、 必ずタープの外へ移動させ、 タープから十分に距離を空け てく ださい。 両翼の中央を跳ね上げている場合は140cmウイ...
  • Page 11 撤収 ・ 収納時の注意事項 ●十分に乾燥 してか ら収納 して く だ さ い。 ●ペグは全て抜き、 汚れを落と してペグケースに頭を下に向けて収納 して く だ さ い。 ペグの紛失、 抜き忘れにご注意 く だ さ い。 応急処置 ●不測の事態によ り本体生地が損傷する場合があ り ますので、 ガムテープやビニールテープ、 添え木になるよ う な パイ プな どのリペア用品を携行し、 速やかに応急処置を施して く だ さ い。 損傷したま ま放置する と、 さ らに大き く 破 れた...
  • Page 12 メンテナンス ・ 保管 ●長期間ご使用 しなかった製品を再度お使いになる際は、 本製品を点検 し各部に異常がないこ と を確認 して く だ さ い。 異常が発見さ れた場合は、 直ちに使用を中止 しお買い求めいただいた販売店様、 ま たは弊社ユーザーサー ビ ス係に点検ま たは修理を依頼 して く だ さ い。 ●本製品は生地の特性を考慮 し、 でき る限り色移り し難い加工と配色パターンを採用 していますが、 保管状態な ど によ り、 若干の色移り が発生する場合があ り ます。 ご了承く だ さ い。 ●濡れたま...
  • Page 13 Instruction Manual Ver 1.00 TP-430 Takibi Tarp Octa...
  • Page 14 Thank you for purchasing a Snow Peak product. This product is a tarp used for camping. For safety, read the following instruction manual before use. Please keep it safe for future reference. Finally, if you find anything that you do not understand in the description or any problems with the product, please stop use immediately and contact the retailer or Snow Peak Customer Service.
  • Page 15 ●Before using the product, check each part for abnormalities. If there are abnormalities, take the product to the dealer or Snow Peak Customer Service for inspection or repair. ●Pay close attention to the weather. If there are strong winds or extreme weather is in the forecast, pack up camp immediately and evacuate to a safe place.
  • Page 16 ●While utmost care is taken to ensure quality, be sure to test it first and check all the accessories and setup tools before actual use. If you find any defects or missing items, contact your local dealership or Snow Peak User Service. ●This product does not include any poles, pegs, or hammers.
  • Page 17 Rope with Rope Tensioner and Pegging Locations Forked 10m rope Forked 10m rope 3m rope 2m rope 2m rope 280cm wing pole 3m rope 3m rope Refer to the following diagram when securing the ropes and pegging the product down. Grommet Tensioner Rope return part...
  • Page 18 Setup Procedure Make sure to set up with two or more people in order to set up more safely. Follow the instructions below to practice setting up and packing up this product several times in order to prepare yourself for the actual camping. Check in advance that all accessories are supplied. Inade- quate setup and packing up may result in damage to the main unit or poles and further lead to accidents.
  • Page 19 Slacken the ridge line of the tarp. Adjust the position of the tensioner of the forked 10m / 32.8' rope to slacken the ridge line about 20%. This slack creates the beautiful curve when the tarp setup is complete. Slack Attach a rope to each corner and peg it down.
  • Page 20 Attaching the Inner Roof While the inner roof uses flame-retardant material, if this is attached incorrectly, having a campfire may result in fire. Connect the buckle of the inner roof. Temporarily pull down the wing pole so that you can reach the buckle on the tarp. Attach the inner roof connection buckle to the inside of the main corner.
  • Page 21 Springing up the Center of Each Wing □Springing up the center of each wing can expand the space under the tarp. For this setup, you need two more wing poles and four more pegs in addition to those required for standard setup. Purchase the necessary items upon referencing the recommended sizes below.
  • Page 22 ⑤ ⑥ Adjust the tension of each rope. Adjust the position of the tensioner of the 3m / ① ④ 9.8' and 2m / 6.6' ropes in the order indicated in the picture to apply tension. Pull the ropes evenly, and after the slack of the ridge line becomes appropriate, apply tension to the forked rope.
  • Page 23 Precautions for Disassembly and Storing ●Dry well before storing the product. ●Pull out all pegs and clean them. Store them in the peg case with the heads facing down. Make sure you do not lose or forget to pull out any pegs. Emergency Procedure ●The material of this product may be damaged due to unexpected occurrences.
  • Page 24 Peak Customer Service. If there are apparent defects in the product's manufacturing, the defective product will be repaired or exchanged free of charge. In other cases, Snow Peak will repair the product for an appropriate fee. The decision to repair or replace the product will be at our discretion. Snow Peak will not repair the product for any damage that occurred due to the following: 1.
