Envelopes with Double Side Seams

Double side-seam construction has vertical seams at both ends
of the envelope rather than diagonal seams. This style may be
more likely to wrinkle. Be sure the seam extends all the way to
the corner of the envelope as illustrated below.
Correct
Incorrect

Envelopes with Adhesive Strips or Flaps

Envelopes with a peel-off adhesive strip or with more than one
flap that folds over to seal must use adhesives compatible with
the heat and pressure in the printer. The extra flaps and strips
might cause wrinkling, creasing, or even jams and may even
damage the fuser.

Envelope Margins

The following gives typical address margins for a commercial
#10 or DL envelope.
Type of Address
Return address
Delivery address
N :
OTES
• For best print quality, position margins no closer than 15 mm
(0.6 in.) from the edges of the envelope.
• Avoid printing over the area where the envelope's seams meet.

Envelope Storage

Proper storage of envelopes helps contribute to print quality.
Envelopes should be stored flat. If air is trapped in an envelope,
creating an air bubble, then the envelope may wrinkle during
printing. See "Printing on Envelopes" on page 3.14.
Minimum
15 mm (0.6 in.)
51 mm (2 in.)
Maximum
51 mm (2 in.)
89 mm (3.5 in.)
