Reece memo Isla Outdoor 2403116 Installation Instructions

IMPORTANT NOTE:
Plumbing connections must be installed to the requirements of AS/NZS 3500 by a qualified plumber.
Prior to Installation:
Examine the sink for any visible defects or imperfections. Do not install if any defects are found.
If wall mounted tapware is to be used, consideration should be made to length of outlet and positioning of
the sink on bench top. If tapware is to be bench mounted, allow suitable top width for fitting tapware.
Components Supplied:
Sink, cut-out template, basket waste and fixing clips.
Types of Installation:
Both inset and undermount cut-out template is provided, please ensure the correct one is used for the
appropriate installation method.
INSET INSTALLATION:
1. Use template provided to trace and cut out the benchtop.
2. Position the sink into the bench top.
3. Hook the clips into the allocation positions on the sink.
4. Secure the sink by tightening the screw, ensure to use a low torque setting if tightening with a power
tool.
5. Plumb up tapware and waste fittings.
Please ensure a copy of the installation
instructions is left with the end user for future reference
Published 27/11/2023
Isla Outdoor (316) Stainless Steel Sinks
Inset
Installation Instructions
Undermount
