- Page 1 SP-4K1H1C60-KIT HDMI 4K over CAT Extender-Splitter With One -Way IR (60m) User Manual VER 1.0...
-
Page 2: Table Of Contents
Safety and performance Notice Only use the power supply supplied with the unit, or a PhD Solutions supplied replacement. Do not disassemble any of the equipment. This will void the manufacturer’s warranty. -
Page 3: Introduction
1. Introduction This HDMI Extender-Splitter can extend 4K60 18 Gbps high-definition video and audio signals up to 197Ft /60m and 1080P up to 230ft / 70m over a single CAT6 cable. It supports resolutions of up to 4K2K@60Hz 4:4:4 and HDMI 2.0 HDCP 2.2 An HDMI loop output port will split the HDMI Input to a local Display. -
Page 4: Package Contents
3. Package Contents ① 1× HDMI 18Gbps Extender (Transmitter) ② 1× HDMI 18Gbps Extender (Receiver) ③ 1× IR receiver/blaster cable (1.5 meters) ④ 1× 20~60KHz IR emitter cable (1.5 meters) ⑤ 1× 12V/1A Locking Power adapter ⑥ 4× Mounting brackets ⑦... - Page 5 Mechanical Housing Metal Enclosure Black Color Dimensions Transmitter / Receiver: 61mm [W] × 88mm [D] × 18mm [H] Weight Transmitter: 160g, Receiver: 155g Input: AC 100~240V 50/60Hz Power Supply Output: DC 12V/1A Power Consumption 3.84W (Max) Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity...
-
Page 6: Operation Controls And Functions
5. Operation Controls and Functions 5.1 Transmitter Panel CAT OUT SERVICE IR OUT DC 12V HDMI OUT HDMI IN Name Function Description HDMI loop output port, connect to an HDMI display like a TV HDMI OUT or Projector with an HDMI cable. HDMI input port, connect to HDMI source device such as DVD HDMI IN or PS5 game console with an HDMI cable. -
Page 7: Receiver Panel
5.2 Receiver Panel CAT IN SERVICE IR IN DC 12V HDMI OUT Name Function Description HDMI output port, connect to an HDMI display like a TV or HDMI OUT Projector with an HDMI cable. CAT IN Connect to CAT OUT port on the transmitter with a CAT6 cable. Power Indicator The lamp will illuminate when the receiver is powered on. -
Page 8: Ir Pin Out
5.3 IR Pin Out IR Receiver and IR Emitter/Blaster pin’s definition as below: IR Receiver IR Signal Power Grounding IR RECEIVER IR Blaster IR Blaster Signal Power IR BLASTER IR System Diagram IR blaster cable HDMI Extender 50m CAT 5e/6 cable Receiver IR receiver cable Note: IR remote sends signal distance... -
Page 9: Application Example
6. Application Example HDMI OUT HDMI IN CAT OUT SERVICE IR OUT DC 12V Transmitter Power Supply Cat 5e/6 DVD or Blu-ray Player IR blaster UHDTV HDMI OUT CAT IN SERVICE IR IN DC 12V Receiver UHDTV IR Extender 7 / 12... -
Page 10: Cat Cable Termination Diagram
HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. 7. CAT Cable Termination Diagram 8. Phd Solutions Product Warrantee IMPORTANT INFORMATION ABOUT YOUR RIGHTS AND OBLIGATIONS, AS WELL AS LIMITATIONS AND EXCLUSIONS THAT MAY APPLY TO YOU. - Page 11 Please check with your installer for their purchase date. If the Product fails to conform to this Limited Warranty during the Warranty Period, PHD Solutions will, at its sole discretion, either (a) repair or replace any defective Product or component;...
-
Page 12: What This Limited Warranty Does Not Cover
CLAIM UNDER THIS LIMITED WARRANTY Before being able to claim under this Limited Warranty, the owner of the Product must (a) notify PHD Solutions of the intention to claim during the Warranty Period and providing a description of the alleged failure, and (b) comply with PHD Solutions’... -
Page 13: Disclaimer Of Warranties
Product, or software (even if packaged or sold with the product). PHD Solutions recommends that you use only authorized service providers for maintenance or repair. Unauthorized use of the Product or software can impair the Product’s performance and may... -
Page 14: Copyright Notice
You use all product information, the services, and the product at your own discretion and risk. You will be solely responsible for (and PHD Solutions disclaims) any and all loss, liability, or damages, including to your hvac system, plumbing, home, product, product peripherals, computer, mobile device, and all other items and pets in your home, resulting from your use of the product information, services, or product. - Page 15 www.phdsolutions.co...
