- Page 1 EGE-EXT-USB20-100 USB 2.0 Extender (100M)
- Page 2 EGE-EXT-USB20-100 USB 2.0 Extender (100M) Thank you for purchasing this product For optimum performance and safety, please read these instructions care- fully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
-
Page 3: Table Of Contents
EGE-EXT-USB20-100 USB 2.0 Extender (100M) TABLE OF CONTENTS 1. Introduction .................1 2. Features................1 3. Package Contents ..............1 4. Specifications ..............2 5. Operation Controls and Functions ........3 5.1 Transmitter Panel ............3 5.2 Receiver Panel ...............3 6. Application Example ............4... -
Page 4: Introduction
EGE-EXT-USB20-100 USB 2.0 Extender (100M) 1. Introduction The USB 2.0 Extender can extend USB signal up to 100m / 328ft via a single Cat5e/6 cable. In the transmitter, the USB-B port is connected to a PC. In the receiver, you can connect a device with USB port (such as U disk or printer, etc.) through the two USB ports. -
Page 5: Specifications
EGE-EXT-USB20-100 USB 2.0 Extender (100M) 4. Specifications Technical USB protocol USB 2.0 Transmission rate Up to 200Mbps Transmission distance 100M (328ft) ESD Protection Human-body Model: ±8kV (Air-gap discharge) , ±4kV (Contact discharge) Connections Transmitter Input port: 1×USB [USB-B, female] Output port: 1×CAT [RJ45, female] Receiver Input port: 1×CAT [RJ45, female]... -
Page 6: Operation Controls And Functions
EGE-EXT-USB20-100 USB 2.0 Extender (100M) 5. Operation Controls and Functions 5.1 Transmitter Panel USB (TO PC): USB port, connect to the USB port of a PC through a USB-B male head to USB-A male head wire. POWER LED: Power LED indicator. The green LED will be on when the transmitter is powered on. -
Page 7: Application Example
EGE-EXT-USB20-100 USB 2.0 Extender (100M) 6. Application Example... - Page 9 www.geratech.eu...
