- Page 1 EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC...
- Page 2 EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC...
-
Page 3: Table Of Contents
EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 4: Introduction
EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC 1. Introduction This 18Gbps HDMI Extender can extend high definition video / audio signal, RS-232, bi-directional IR, and the distance is up to 492ft / 150 meters between transmitter and receiver via a single CAT cable. It supports resolution up to 4K2K@60Hz 4:4:4, 18Gbps and HDCP 2.2. -
Page 5: Package Contents
EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC 3. Package Contents • 1 x 18Gbps HDMI over HDBaseT Extender (Transmitter) • 1 x 18Gbps HDMI over HDBaseT Extender (Receiver) • 1 x IR Blaster cable (1.5 meters) • 1 x 20~60KHz IR Receiver cable (1.5 meters) •... - Page 6 EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC Connection Transmitter Inputs: 1x HDMI Type A [19-pin female] Outputs: 1x HDMI Type A [19-pin female] 1x HDBT OUT [RJ45, 8-pin female] Control: 1x IR IN [3.5mm Stereo Mini-jack] 1x IR OUT [3.5mm Stereo Mini-jack]...
-
Page 7: Operation Controls And Functions
EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC 5. Operation Controls and Functions 5.1 Transmitter Panel Power LED: Red LED indicates that the transmitter is powered on. SERVICE port: Firmware update port. DC 24V: DC 24V/1A power supply input port. Note that the extender supports PoC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply. -
Page 8: Receiver Panel
EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC 5.2 Receiver Panel Power LED: Red LED indicates that the receiver is powered on. SERVICE port: Firmware update port. DC 24V: DC 24V/1A power supply input port. Note that the extender supports PoC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply. -
Page 9: Ir Pin Definition
EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC 5.3 IR Pin Definition... - Page 10 EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC The following is IR system diagram about IR cable use method. Note: When the angle between the IR receiver and the remote control is ± 45 °, the transmission distance is 0-5 meters; when the angle between the IR receiver and the remote control is ± 90 °, the transmission distance is 0-8 meters.
-
Page 11: Application Example
EGE-UHD-HDB-EXTLA HDBase-T Extender, 120m-4K60Hz, Audio Out, PoC 6. APPLICATION EXAMPLE... - Page 13 www.geratech.com.tr...
