geratech EGE-2HDKVM-CAT Manual

Dual-head hdmi cat.6 extender with usb/ir/rs-232/audio
Hide thumbs

Advertisement

Quick Links

Download this manual
geratech
®
EGE-2HDKVM-CAT
Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio

Advertisement

loading
Need help?

Need help?

Do you have a question about the EGE-2HDKVM-CAT and is the answer not in the manual?

Questions and answers

Related Manuals for geratech EGE-2HDKVM-CAT

Summary of Contents for geratech EGE-2HDKVM-CAT

  • Page 1 ® EGE-2HDKVM-CAT Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio...
  • Page 2 EGE-2HDKVM-CAT Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio...
  • Page 3 EGE-2HDKVM-CAT Introduction The EGE-2HDKVM-CAT is a high performance KVM (Keyboard, Video and Mouse) extender that allows a customer to have full console control at 170 meters (1080p resolution) remote. The flexibility of CAT.5e/6 cables makes this easily routable and is an inexpensive method for extending a full KVM console.
  • Page 4 EGE-2HDKVM-CAT Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio 14. HDMI 1.3 / HDCP compliant. 15. Supports Plug & Play; Software not required. Detail Picture SLK182HT <Transmitter> 1. HDMI-A Input 2. HDMI-B Input 3. USB Input 4. Audio Input 5. IR Output 6.
  • Page 5 EGE-2HDKVM-CAT Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio EGE-2HDKVM-CAT Receiver 1. HDMI-A Output 2. HDMI-B Output 3. Audio Output 4. IR Input 5. RS-232 (DTE) 6. USB Keyboard/Mouse 7. EDID Copy Button (HDMI-A Output) 8. EDID Copy Button (HDMI-B Output) 9. Status Indicator LED a.
  • Page 6 EGE-2HDKVM-CAT Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio Diagram Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio System Diagram Installation and Operation Transmitter Installation. 1. First Time Set-up, Please turn off all computers and plug the user console – keyboard and mouse - into corresponding user port and then plug the power adapter into the Transmitter.
  • Page 7 EGE-2HDKVM-CAT Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio 3. Please turn on the computer and let T ransmitter power supply. Receiver Installation. 1. Plug the user console - keyboard, video monitor, mouse and speaker - into corresponding user port and then plug the power adapter into the Receiver. Keyboard and mouse must be USB type.

  • Page 8: Specification

    EGE-2HDKVM-CAT Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio Specification Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio Model EGE-2HDKVM-CAT EGE-2HDKVM-CAT Model Name Transmitter Receiver Console Port Video-1 HDMI (Female) Video-2 HDMI (Female) Keyboard USB Type A (Female) USB Type A (Female) Mouse USB Type A (Female)

  • Page 9: Troubleshooting

    EGE-2HDKVM-CAT Dual-Head HDMI CAT.6 Extender with USB/IR/RS-232/Audio Troubleshooting Problem: No Video Solution: (1) Make sure Cat.5e cables are well connected from Transmitter to Receiver and further Receiver daisy chain. (2) Check power indicator and make sure all DC power adapters had well connected to Transmitter and Receivers, and well plugged into power socket.
