WHD100 In Room Full HD VideoWireless Kit Table of Contents TABLE OF CONTENTS .......................... 1. IMPORTANT INFORMATION ......................2. INTRODUCTION ..........................2.1 PACKING CONTENT ........................2.2 OVERVIEW ..........................2.2.1 WHD100T (TX): PC TO TV TRANSMITTER ................2.2.2 WHD100R (RX): PC TO TV RECEIVER ................
In Room Full HD VideoWireless Kit 1. Important Information Please take the time to read this user manual before using the WHD100. It contains important informa- tion about operating your PC to TV wireless kit. Our company’s limited warranty applies when the product is handled properly for intended use, in accor- dance with its operating instruction.
Page 5
WHD100 In Room Full HD VideoWireless Kit Warning This product should not be exposed to dripping or splashing. No object filled with liquids, such as vases, should be placed on the product. Object Entry: To avoid electric shock, never stick anything in the slots on the case or remove the cover.
Page 6
WHD100 may interfere 5GHz wireless devices, such as routers or other wireless devices. Therefore, if you have an 802.11n router, configure it to the 2.4 GHz band rather than the 5GHz band. Optimal range between WHD100 transmitter and receiver is between 2 and 7 meters within line of sight.
Page 7
WHD100 In Room Full HD VideoWireless Kit Outdoor operations in the 5470~5725MHz band are prohibited. This device could not be used in the 5600~5650MHz. The Device not operation in 5600~5650MHz. Industry Canada regulatory information Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including inter- ference that may cause undesired operation of the device.
Page 8
ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz high performance RLAN equip- ment Hereby, Geratech declares that this Full HD video wireless kit is in compliance with the essential requirements and other relevant provisions of Directive 1995/5/EC.
Page 9
WHD100 In Room Full HD VideoWireless Kit Industry Canada statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 10
WHD100 In Room Full HD VideoWireless Kit French translation: Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
In Room Full HD VideoWireless Kit 2. Introduction WHD100 is a Full HD wireless transmission device. This solution delivers uncompressed 1080p full HD video and audio content to your existing HDTV set wirelessly. It operates the transmission in 4.9 GHz~ 5.9 GHz frequencies and it can adjust its commu- nication frequency automatically in case of interference from another RF system.
WHD100 In Room Full HD VideoWireless Kit 2.2 Overview 2.2.1 WHD100T (TX): PC to TV Transmitter LED Status Indicator Pairing button The LED indicator is lit solid The button reserved for blue when the power is on and multiple transmitter &...
WHD100 In Room Full HD VideoWireless Kit 2.2.2 WHD100R (RX): PC to TV Receiver Front Panel Buttons and LEDs Power Button with LED indicator Press to turn the receiver on and off. The indicator in the power button lights up in blue when the power is on, and turns red in standby mode.
(No function for WHD100 product.) IR Button Press to switch the IR Blaster frequency to meet Source device’s requirement. It can switch IR Blaster frequency 47K to 56K to 36K recurring. (No function for WHD100 product.)
WHD100 In Room Full HD VideoWireless Kit 3. Installation Step 1: Setup the WHD100T transmitter Connect an HDMI-ready computer to the WHD100T: Plug the transmitter’s HDMI connector to the HDMI-ready computer’s “HDMI OUT” or Source player’s “HDMI OUT” directly. Power supplied by USB port of computer through the USB cable (included on package). Or connect the supplied power adapter to the mini USB port of the WHD100T and a wall socket.
WHD100 In Room Full HD VideoWireless Kit Step 2: Setup the WHD100R receiver HDTV set Connection with WHD100R: Connect the HDMI cable to the HDMI OUT jack of the receiver and to your HDTV set (or an HD projector). Connect the supplied power adapter to the DC IN jack of the WHD100R and a wall socket. When it’s connected to the...
Step 3: Boot up the WHD100T and WHD100R Place the two AAA batteries into the remote control. After the power cord is plugged into the electrical outlet, the WHD100 will be turned on and link established automatically. When unplug the power of WHD100T, WHD100R will enter Standby mode (POWER LED of receiver is lit in...
Page 18
WHD100 In Room Full HD VideoWireless Kit When WHD100T in Standby mode (Receiver POWER LED is lit in red), plug in the power of WHD100R, the receiver will wakes up the transmitter automatically to establish a link. During the warm-up period, the POWER LED will blink in blue until the signal link between the transmitter and the receiver is established.
Page 19
WHD100 In Room Full HD VideoWireless Kit If all operation is normal, the POWER LED and INFO./CHANNEL LED will glow in solid blue. Please refer to the below form containing detailed LED indicator and OSD description of transmitter / receiver:...
Page 20
D. If you have more than one pair of WHD100, each transmitter and receiver should be at least 6.5 feet away from one another. If both the transmitter and the receiver exist in the same room, the suggested the distance between the two is 6.5 feet minimum.
Page 21
WHD100 In Room Full HD VideoWireless Kit Step 4: Pairing the transmitter with existed receiver Enter the Pairing mode for transmitter: Plug in Power adapter Keep press the Power button and holding it. Power LED flashed in blue while it entered Pairing mode...
Page 22
While both transmitter and receiver enter the Pairing mode, it’ll search each other and pairing automati- cally. The OSD shows: Adding WHD100 After the pairing finished, both transmitter and receiver will re-boot up and establish the link each other automatically.
During this period, plug in power on transmitter, followed by pressing “Info” key of transmitter, keep pressing “Info” key of transmitter until power’s LED become slow blinking, then release “Power” key, the OSD shows: Adding WHD100 After the pairing finished, both transmitter and receiver will re-boot up and establish the link each other automatically.
Page 24
WHD100 In Room Full HD VideoWireless Kit Press Transmitter key of remote control, OSD shows: Remove Recoded Transmitter: WHD100-1 WHD100-2 Return Press Transmitter key of remote control, OSD shows: Edit Recoded Transmitter name: WHD100-1 WHD100-2 Return Edit transmitter name: Press Left/Right key of remote to move WHD100-1 cursor;...
WHD100 In Room Full HD VideoWireless Kit Step 5: Mounting the WHD100R to the Wall Refer the drawing of the bottom page that have relative position of the key holes and attach this paper on wall. Place WHD100R key holes over the protrud- ing screws and slide down into position.
* Ensure the proper cables are connected between the transmitter and your PC (or Notebook) devices. * Ensure your PC (or Source device) devices connected to the WHD100 transmitter are powered on. * Ensure the display setting for your PC (or laptop) had been switched to clone mode, Projector out mode or dual display mode for enable external display.
Page 27
Check if your PC’s (or laptop’s) audio volume has been turned up. Ensure the bit rate of audio from the source device can be supported by WHD100. Please refer to the details in Chapter 6, Audio Bit Rate Sup- port.
WHD100 In Room Full HD VideoWireless Kit 4.1 Windows OS Display setting of Laptop for enables external display On Windows7 OS : 1. Press key + P key 2. There is a Pop icon displayed on the screen, likes below : 3.
WHD100 In Room Full HD VideoWireless Kit On Windows XP OS: 1. Click the right key of the mouse on the desktop 2. Click Graphic Option / Output to 3. Click Clone mode or extended display Note: For more information, please type “change display settings” on Windows Help and Support.
Page 30
WHD100 In Room Full HD VideoWireless Kit On Vista OS : 1. Click to open Windows Mobility Center from Start 2. On the Volume title, click the Change Audio setting icon to open Sound page 3. Select HDMI output and press On Windows XP OS : 1.
WHD100 In Room Full HD VideoWireless Kit 5. Supported Resolution If the Status LED of Rx continues to blink in blue (slower than “no signal” mode); OSD display: and there is no video displayed or the video quality suffers, it indicates that the video frame rate from your A/V source device is not supported.
Page 32
WHD100 In Room Full HD VideoWireless Kit If the RX status LED continues to blink in blue (slower than “no signal” mode); or OSD display: RX , please check does TV support 3D video format and try to switch the 3D video format the one of below table.
WHD100 In Room Full HD VideoWireless Kit 6. Audio Bit Rate Support Digital Audio from HDMI inputs: Up to 6Mbit/s bit-rate support. Support AC3 and DTS. 8 channel PCM audio : 16~24 bits audio sample with 32~96KHz sampling rate 32KHz 44.1KHz...
WHD100 In Room Full HD VideoWireless Kit 7. Product Specification General Specifications Supported Video HDMI Input 1080p, 1080i, 720p, 576p, 480p Resolutions Supported Audio Digital Audio PCM , up to 6 Mbps AC3 and DTS Formats The maximum video transmission range is 7 meters (23 feet)
Page 35
WHD100 In Room Full HD VideoWireless Kit...
