- Page 1 EGE-DVI-FO500 DVI Fiber Extender, 4 Core, MM, 500m Support, No HDCP, EDID Programming...
-
Page 3: Table Of Contents
EGE-DVI-FO500 DVI Fiber Extender, 4 Core, MM, 500m Support, No HDCP, EDID Programming CONTENTS 1. Introduction ..................1 2. Package Contents ................1 3. Features .................... 1 4. Panel Descriptions................2 5. Connection and Installation ............... 3 6. EDID Learning ................... 3 7. -
Page 4: Introduction
Support, No HDCP, EDID Programming 1. INTRODUCTION The DVI Fiber Optic Extender (EGE-DVI-FO500) allows DVI equipment to be connected up to 500m with 1920x 1200@60Hz via four multy- mode fiber optic. The Extender comes with one Transmitter and one Receiver as well as EDID learning function. -
Page 5: Panel Descriptions
EGE-DVI-FO500 DVI Fiber Extender, 4 Core, MM, 500m Support, No HDCP, EDID Programming PANEL DESCRIPTION DVI Output: Connect to DVI display Power LED: Lights red when being powered up Signal LED: Lights blue when working Power: Connect to DC adapter... -
Page 6: Connection And Installation
CONNECTION AND INSTALLATION EDID LEARNING 1) Turn on the display, connect the EGE-DVI-FO500-TX to it and power it up (make sure the DC adapter’s LED lights red); 2) Press the EDID button, then the Signal LED light of EGE-DVI-FO500-TX will light blue;... -
Page 7: Safety Information
Warranty time is two year and from the date of original shipment. This warranty shall be void if a serial number has been removed from the product. Upon determination of a legitimate defect covered by this warranty and at GERATECH’s sole discretion,user should bear the transport cost during the warranty. - Page 9 www.geratech.eu...
