Shimaden PAC28 Series Instruction Manual

Single-phase thyristor power regulator
Table of Contents

Advertisement

Quick Links

Thank you for purchasing a Shimaden PAC28 Series Single-Phase Thyristor Power Regulator.
After making sure the product fits the desired description, you should carefully read the instructions and get a good understanding of the contents before
attempting to operate the equipment.
Request
The instruction manual should be kept in a handy place where the end user can refer to it when necessary.
Installation must be done by qualified personnel.
Preface
The instruction manual has been prepared for those involved in setup, wiring, operation or routine maintenance of PAC28 Series equipment.
This product should be used as a part to be mounted on inspection/measurement equipment.
The manual provides information concerning mounting, wiring and precautions when working with PAC28 Series equipment. You should therefore keep
it in a handy place to refer to when operating and handling the equipment.
Be sure to observe all precautions and adhere to the procedures provided in the manual.
Safety rules, precautions concerning equipment damage, additional instructions and notes are written based on the following headings.
Matters that could result in injury or death if instructions are not followed.
WARNING
Matters that could result in equipment damage if instructions are not followed.
CAUTION
Additional instructions and notes
Note
PAC 28 Series is control heater power, etc., of industrial equipment. It should not be used for nuclear power generation, traffic control, communications or
medical equipment.
You should either take appropriate safety measures or avoid using for control that could have a serious effect on human life. The manufacturer shall not be
liable for an accident that results if used without taking appropriate safety measures.
1. The power regulator should be used so the terminal elements in the control box, etc., are not touched by human beings.
2. The power regulator should not be used as a switch.
Even if output is zero, power is present in the capacitors and resistors of the output circuit, and could result in accident involving human life or serious
bodily injury due to electrical shock.
3. Radiation fins and chassis become extremely hot. Never touch the radiation fins or chassis. Doing so could result in burn injury.
4. Do not supply power when wiring. Doing so could result in electrical shock.
5. Be sure to ground the ground terminal.
6. Do not touch terminal elements or other charged parts while conducting electricity. Also, do not introduce foreign objects or matter into the equipment.
If a foreign object or matter accidentally gets inside, be sure to turn off the power and make sure all is safe before introducing tools or your hands.
Be sure to observe the instruction manual when operating the device. If the content in the manual is not followed, the protectivity of the device will be impaired.
If there is danger of damage to any peripheral device or equipment due to failure of the power regulator, you should take appropriate safety measures such
as mounting a rapid fuse, overcurrent circuit breaker or overheating prevention device.
We recommend you mount an electromagnetic contactor on the power supply for the device and automatically shut off the power supply immediately when
an error occurs.
Using an electromagnetic contactor may result in malfunction due to contact bounce. Malfunctions are especially caused by circuits connected to transformers
(inductive load). If so, you should either use the prescribed noise filter, or connect an X capacitor between the R and T main power terminals (0.1 – 0.5 μF), or a
Y capacitor between the R and T power terminals and the ground (1000 – 3300 pF) to absorb the noise.
1. Concerning the
alert symbol on the power regulator's plate, a
symbol is provided to prompt you to employ special care not to touch the device because doing so could result in electrical shock if parts that conduct
power are touched when power is present, or could result in burn injury if touched when hot, etc.
2. Provide a switch or breaker as a means of cutting off power for external power circuit connected to the power terminal of the device.
Mount a switch or breaker near the device where the operator can get to it easily and label it as an electrical breaker for the device.
3. Be sure to securely fasten conductor cable connections before using.
Failure to do so could result in burning from overheating due to contact resistance.
4. Be sure power supply voltage and frequency do not exceed the rating.
5. Do not apply voltage/current other than rated input to the input terminal.
Doing so could shorten the life of the product or result in equipment failure.
6. Voltage/current of load connected to the output terminal should not exceed the rating.
Using voltage/current that exceeds the rating could shorten the life of the product by raising the temperature, and could result in equipment failure.
7. Be sure to mount the terminal cover that comes with the device after wiring.
8. The user should absolutely not modify or use the device in any way other than it was intended to be used. If this device must be disassembled for
replacement or repair, contact your dealer.
9. To ensure safety and maintain the functions of this device, do not disassemble this device other than replacing the fuse.
If this device must be disassembled for replacement or repair, contact your dealer.
10. Be sure to observe the notes and precautions provided in the manual to use the device safely and maintain its reliability.
Note: Shimaden shall bear no responsibility, monetarily or otherwise, for accident or damages caused by failure to observe warnings, notes and precautions
contained in the instruction manual.
PAC28 Series
Single-Phase Thyristor Power Regulator
Instruction Manual
WARNING
WARNING
CAUTION
CAUTION
alert symbol is printed on the label applied to the outer surface of the device. The
MPA028-E10-D
May. 2023
