- Page 1 XTR-X4R 4-WAY ELECTRONIC CROSSOVER NETWORK...
- Page 2 X4R ensures that music flows smoothly without such hindrances. With the ORION XTR-X4R, not only will you experience the full dynamics of bass, but you will also appreciate the subtle nuances, like fingers sliding across guitar strings. The X4R enables precise control over your audio setup, allowing you to group amplifiers and speakers into discrete units that operate in perfect harmony.
- Page 3 TABLE OF CONTENTS FEATURES & SPECIFICATIONS........................3-6 INSTALLATION................................7-8 TROUBLESHOOTING..............................9 WARRANTY..................................10 WHAT’S IN THE BOX 2 channel input & 4 channel output electronics crossover lluminated control panel Rotary control knobs 12dB per octave crossover slope PWM power supply Remote level controls Front & sub/rear input mode switch Variable low pass frequency control 50Hz-500Hz(SUB/REAR OUTPUT) Manual on/off switch on each output channel Variable bass boost controls 0dB-12dB Stereo/mono mode control on front input...
-
Page 4: Features & Specifications
FEATURES & SPECIFICATIONS... - Page 5 FEATURES & SPECIFICATIONS LEVEL CONTROL - This control sets the sub/rear gain control. 2. PHASE SWITCH - Shift allows 0 degree to 180 degrees. 3. VARIABLE HIGH-PASS FREQUENCY CONTROL - By turning the selector you can choose the high-pass crossover points from 1.2KHz-14KHz.
- Page 6 FEATURES & SPECIFICATIONS 14. FLAT OUTPUT LEVEL CONTROL - For adjusting the flat output level. 15. SUB/REAR/FRONT INPUT SWITCH - For selection of independent input or input from front RCA 16. STEREO/MONO INPUT SWITCH - For selection of stereo or mono mode front inputs. 17.
- Page 7 FEATURES & SPECIFICATIONS Adjustable Bass Boost: 0-18dB. » Selectable Crossover Frequency » ◊ High Pass: 1.2KHz-8KHz ◊ Mid High Pass: 90Hz-1.1KHz ◊ Mid Low Pass: 2KHz-8KHz ◊ Subwoofer (Low Pass): 50Hz-500Hz ◊ Subsonic Filter: 20Hz-40Hz Power Supply: 10-16V DC, negative ground »...
-
Page 8: Installation
INSTALLATION SYSTEM ADJUSTMENT Preliminary Adjustments Pre-setting the system provides a necessary starting point for fine-tuning the entire audio system to maximum performance. NOTE: DO NOT MOUNT CROSSOVER UNTIL THE FOLLOWING PROCEDURES HAVE BEEN COMPLETED. Preset each amplifier input gain adjustment at the amplifier to half of maximum. - Page 9 INSTALLATION Your new XTR Series Crossover comes fully equipped with all the necessary mounting hardware for installation. To begin, position the Crossover at your desired installation spot and use a scribe or one of the mounting screws to mark the locations of the screw holes on the mounting surface.
-
Page 10: Troubleshooting
TROUBLESHOOTING NOISE CHECK Check the entire audio system for noise before permanently securing the CROSSOVER mounting 1. Start the engine. 2. Turn the audio system on. 3. Rev the engine and vary the VOLUME of the audio system to determine if there is any unwanted noise. -
Page 11: Warranty
4. This warranty does not cover car static, electrical interference, adjustments or labor costs for the removal or reinstallation of the unit for repair. 5. The sole responsibility of Orion under this warranty shall be limited to the repair or replacement thereof, at the sole discretion of Orion. - Page 12 3130 WEST 15TH AVENUE HIALEAH, FLORIDA 33012 TEL: 786.464.0247 EMAIL: SUPPORT@ORIONCARAUDIO.COM ORIONCARAUDIO.COM PROUD SPONSOR OF Copyright ORION All rights reserved. Any unauthorized reproduction or use of any Orion logos, images or design elements is strictly prohibited by law. Specifications subject to change without notice. REV. 24.5...
