- Page 1 Xeq-x7 xeq-x70btm GRAPHIC EQUALIZER...
- Page 2 Thank you for purchasing this Orion product. Orion products are specif ically engineered and designed for the mobile audio environment. This manual contains important information about installation, set-up procedures and integrating your new Orion product into your vehicle. With proper care and installation, your new product will provide you with many years of high performance listening enjoyment.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATION................................2 FEATURES...................................3 OPERATION.................................4-6 INSTALLATION.................................7 WIRING DIAGRAM...............................8 TROUBLESHOOTING..............................9 WARRANTY..................................10 Specifications The technical data and the design of the equipment may change without prior notice for the sake of improvements. Frequencies 50Hz, 125Hz, 315Hz, 750Hz, 2.2kHz, 6kHz, 16kHz Boost/Cut 12dB S/N Ratio 83dB... -
Page 4: Features
FEATURES • Seven equalization bands: 50Hz, 125Hz, 315Hz, 750Hz, 2.2kHz, 6kHz, and 16kHz. Each frequency is variable from -12 through +12dB • Three stereo RCA outputs to drive front, rear and subwoofer audio amplifiers. • An auxiliary stereo RCA input for use with portable devices, such as an MP3 player. -
Page 5: Operation
OPERATIONS XEQ-X70BTM 7 BAND GRAPHIC EQUALIZER XEQ-X70BTM AUX: Inserting the cable will AUX: Press to select auxiliary select this AUX Input or main input SPLASH PROOF Master Volume Subwoofer Volume: Equalizer gain controls Adjust to desired setting XEQ-X70BTM Low Pass Use to adjust subwoofer Frequencies from 30Hz - 150Hz Fader Control: Use to balance sound be- tween front and rear speakers. - Page 6 OPERATIONS Setting system volume Turn the master volume and subwoofer level controls to their minimum settings. Turn the source unit on and increase the volume until you hear distortion. Reduce the volume to just below the distortion point (approximately 80% of full volume).
- Page 7 OPERATIONS Using the front panel 3.5mm input Reduce the equalizer’s volume to minimum before plugging in the 3.5mm cable to avoid any sudden, unwanted changes in the output. Plug the 3.5mm cable into the equalizer AUX input. The equalizer will automatically select this input when the cable is inserted.
-
Page 8: Installation
This lead turns on and off with the ignition key. • Do not open the case. There are no user-serviceable parts inside. If you require assistance, consult your Orion dealer or an authorized Orion service center. Tools and additional components Tools you will need: •... -
Page 9: Wiring Diagram
WIRING DIAGRAM XEQ-X7 7 BAND GRAPHIC EQUALIZER XEQ-X7... -
Page 10: Troubleshooting
If the problem still occurs, see your authorized Orion dealer. • Speakers may be damaged. Consult your authorized Orion dealer. No Sound coming from the unit • The wrong input is selected. Change the AUX mode switch to turn the main inputs on. -
Page 11: Warranty
4. This warranty does not cover car static, electrical interference, adjustments or labor costs for the removal or reinstallation of the unit for repair. 5. The sole responsibility of Orion under this warranty shall be limited to the repair or replacement thereof, at the sole discretion of Orion. - Page 12 3130 WEST 15TH AVENUE HIALEAH, FLORIDA 33012 TEL: 786.464.0247 EMAIL: SUPPORT@ORIONCARAUDIO.COM ORIONCARAUDIO.COM PROUD SPONSOR OF Copyright ORION All rights reserved. Any unauthorized reproduction or use of any Orion logos, images or design elements is strictly prohibited by law. Specifications subject to change without notice. REV. 23.3...
