Orion ORC5V Installation & Operation Manual

5 farad/10 farad hybrid capacitor

Advertisement

Quick Links

ORC5V
ORC10V 10 F
H
C
YBRID
© 2009 Directed Electronics. ORC5V 2009-11
5 F
ARAD
ARAD
APACITOR
& Operation
Installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ORC5V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Orion ORC5V

  • Page 1 ORC5V ARAD ORC10V 10 F ARAD YBRID APACITOR Installation & Operation © 2009 Directed Electronics. ORC5V 2009-11...
  • Page 2: Table Of Contents

    NTRODUCTION Thank you for purchasing the ORION Hybrid Capacitor.The ORION Hybrid Capacitors, also known as Electric Double Layer Capacitors (EDLC) or Super Capacitors, are passive electrostatic energy storage devices.They are state of the art technology that allows you to put massive power storage in a very small space What are ORION Hybrid Capacitors good for? Some of the most promising applications that have been found for ORION Hybrid Capacitors are battery and large audio system performance enhancement.
  • Page 3: Safety Instructions

    DO NOT make any connections to a capacitor if the connecting polarity cannot be properly identified. Applying reversed polarity will damage capacitor cells. ONTENTS OF ARTON A model ORC5V ORC10V Hybrid Capacitor Module Charging Bulb Installation & Operation Manual © 2009 Directed Electronics. All rights reserved.
  • Page 4: Design Features

    ESIGN EATURES The following features are the results of the unique patented manufacturing process that enables the DEI Hybrid Capacitor to deliver many charge and discharge cycles with greater energy and power per unit weight and volume. High Energy The amazingly high specific capacitance and lower weight of ORION's Hybrid Capacitor yields an energy per kilogram figure that is twice that of any other commercially available Electric Double Layer Capacitor (EDLC).
  • Page 5: Mounting Locations

    NSTALLATION This section focuses on some of the vehicle considerations for installing your new ORION Hybrid Capacitor. Pre-planning your system layout and best wiring routes will save installation time. When deciding on the layout of your new system, be sure that each component will be easily accessible for making adjustments.
  • Page 6 NSTALLATION ATTENTION: Make sure the battery and all other power sources are disconnected. ATTENTION: When installing high voltage audio equipment, such as capacitors and amplifiers, we recommend using “full-spec” AWG (American Wire Gauge) type wire for your power and ground wires. CAUTION: Ensure correct polarity during the following connections.
  • Page 7: Operation

    NSTALLATION CHARGING CAPACITOR FINAL CONNECTION Connected to Can be used as Connected to Can be used as Amplifier or System Ground Amplifier or System Ground Distribution Block Distribution Block Distribution Block Distribution Block Connect to Fig. 1 Fig. 2 chassis ground Connect to of vehicle.
  • Page 8: Specifications

    CAUTION: To prevent injury due to hazardous chemicals, do not touch the capacitor if the safety vent has ruptured. Have the system looked at by a qualified technician for repair and/or disposal. PECIFICATIONS MODEL- 5/10 Farad Hybrid Capacitor ORC5V ORC10V Rated Capacitance – 77°F (25°C) 5 Farad 10 Farad (Constant Current Discharge (5A) 15.0v–>3.0v)
  • Page 9: Warranty

    LIMITED 90-DAY ACCESSORY/1-YEAR CAPACITOR WARRANTY This product is sold with a LIMITED 90-day accessory/1-year capacitor manufacturer’s warranty. Directed Electronics (“Directed”) promises to the original purchaser that the product (“Product”) will be free from defects in materials and workmanship under normal use and condition for a period of ninety (90) days for accessories/ one (1) year for capacitors after the date of purchase.
