- Page 1 XTR-X3R 3-WAY ELECTRONIC CROSSOVER NETWORK...
- Page 2 With the ORION XTR-X3R, you’ll enjoy every dynamic of the bass and appreciate subtle sounds, such as fingers sliding across guitar strings. The X3R enables precise grouping of amplifiers and speakers into discrete sets, ensuring they function as a harmonious unit.
-
Page 3: What's In The Box
TABLE OF CONTENTS FEATURES & SPECIFICATIONS........................3-6 INSTALLATION................................7-8 TROUBLESHOOTING..............................9 WARRANTY..................................10 WHAT’S IN THE BOX Light illuminated control panel Rotary control knobs 12dB per octave crossover slopes PWM power supply Remote bass boost (0-+18dB) and level controls Subwoofer mode switch Variable subwoofer frequency control 40-400 Hz Parametric “Q”... -
Page 4: Features & Specifications
FEATURES & SPECIFICATIONS... - Page 5 FEATURES & SPECIFICATIONS 1. BASS BOOST CONTROL - This control adjusts the bass boost gain (0 to+ 18dB). 2. BASS BOOST LEVEL CONTROL - This control sets the subwoofer gain control. 3. SUBWOOFER MODE SWITCH - Allows subwoofer mode channel to receive signal from either the mix of from low-pass inputs 4.
- Page 6 FEATURES & SPECIFICATIONS 13. MID-RANGE OUTPUT LEVEL CONTROL - For adjusting the mid-range channel output level. 14. VARIABLE HIGH-PASS FREQUENCY CONTROL 40-8KHz - By turning the selector you can choose the high-pass crossover points from 40Hz-800Hz. 15. FREQUENCY MULTIPLIER (x1/x10 HIGH·PASS CROSSOVER) - This switch changes crossover points from 40Hz-800Hz to 400Hz-8KHz for high frequency highchannel drivers.
-
Page 7: Remote Control Unit
FEATURES & SPECIFICATIONS Adjustable Bass Boost Frequency: 25Hz-250Hz » Adjustable Bass Boost: 0-18dB. » Adjustable Q Control: 2-20 » Selectable Crossover Frequency » ◊ High Pass: 40Hz-8KHz ◊ Mid High Pass: 40Hz-800Hz ◊ Mid Low Pass: 2KHz-7KHz ◊ Subwoofer (Low Pass): 40Hz-400Hz Power Supply: 10-16V DC, negative ground »... -
Page 8: System Adjustment
INSTALLATION SYSTEM ADJUSTMENT Preliminary Adjustments Pre-setting the system provides a necessary starting point for fine-tuning the entire audio system to maximum performance. NOTE: DO NOT MOUNT CROSSOVER UNTIL THE FOLLOWING PROCEDURES HAVE BEEN COMPLETED. Preset each amplifier input gain adjustment at the amplifier to half of maximum. - Page 9 INSTALLATION Your new XTR Series Crossover comes complete with all required mounting hardware. Mark the location for the mounting screw holes by positioning the Crossover where you wish to install it and use a scribe (or one of the mounting screws) inserted in each of the mounting holes to mark the mounting surface.
-
Page 10: Noise Check
TROUBLESHOOTING NOISE CHECK Check the entire audio system for noise before permanently securing the CROSSOVER mounting 1. Start the engine. 2. Turn the audio system on. 3. Rev the engine and vary the VOLUME of the audio system to determine if there is any unwanted noise. -
Page 11: Warranty
4. This warranty does not cover car static, electrical interference, adjustments or labor costs for the removal or reinstallation of the unit for repair. 5. The sole responsibility of Orion under this warranty shall be limited to the repair or replacement thereof, at the sole discretion of Orion. - Page 12 3130 WEST 15TH AVENUE HIALEAH, FLORIDA 33012 TEL: 786.464.0247 EMAIL: SUPPORT@ORIONCARAUDIO.COM ORIONCARAUDIO.COM PROUD SPONSOR OF Copyright ORION All rights reserved. Any unauthorized reproduction or use of any Orion logos, images or design elements is strictly prohibited by law. Specifications subject to change without notice. REV. 24.5...
