- Page 1 ENFORCER Wheelchair USER MANUAL...
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ............................. 1 INTENDED USE ............................1 MODEL FEATURES ..........................2 SPECIFICATION TABLE ........................3 ASSEMBLY .............................. 4 ADJUSTING THE HEIGHT OF THE WHEELCHAIR ................. 5 HOW TO USE ............................6 OPERATIONAL INSTRUCTIONS - USE ..................... 7 SAFETY PRECAUTIONS ........................ -
Page 5: Introduction
INTENDED USE The Enforcer Wheelchair is intended for indoor or outdoor use with or without an attendant. This foldable wheelchair is designed for carrying a maximum weight capacity up to 110kg with comfort with easy-to-use features. MANDATORY! Do not operate your new Enforcer Wheelchair for the first time without reading and understanding this user manual completely. -
Page 6: Model Features
MODEL FEATURES 1. Backrest (Half Folding) You can fold the backrest by pressing down on the two black plastic levers, then pulling back and pushing down on the top of the backrest. To return it to its original position, repeat the operation in reverse, making sure that the mechanism is securely locked. -
Page 7: Specification Table
SPECIFICATION TABLE Details Specification Aluminium Frame (Painted) with Aluminium Hand Rims Armrests Adjustable Height, PU Pad Backrest Foldable Backrest Height 43.5cm Folded Width 33.5cm Footrests Foldable, detachable, plastic plates Front Fork Aluminium, adjustable height Gross Weight 19.3kg Height (Seat to floor) 46cm Overall Dimensions (W x D x H) 72.5cm x 100cm x 92.5cm... -
Page 8: Assembly
ASSEMBLY For the safe use of your wheelchair, in and out of the house, you need to be confident in the main manoeuvres, such as pushing, braking, going back and forth on flat surfaces (can be done with the help of an assistant). To fold the chair, pull the front and rear side of the seat fabric upwards. -
Page 9: Adjusting The Height Of The Wheelchair
Footrest support Place it on its side so that the footrest is perpendicular to the chair. • Push the brackets towards the chair until they lock into place. The footrest will face inwards towards the chair • when it is locked into place. To remove, push the lever inwards and rotate the footrest outwards. -
Page 10: How To Use
HOW TO USE Various activities require the user to reach, lean or transfer from the chair to another seat or vice versa. These movements can cause a change in the balance, centre of gravity and weight distribution of the wheelchair. The design of the wheelchair will allow for stability in daily activities when used correctly by following the recommendations: 1. -
Page 11: Operational Instructions - Use
OPERATIONAL INSTRUCTIONS - USE For the safe use of your wheelchair, in and out of the house, you need to be confident in the main manoeuvres, such as pushing, braking, going back and forth on flat surfaces (can be done with the help of an assistant). Avoid slopes, uneven surfaces etc. - Page 12 How to get out of the wheelchair alone Avoid bending too far down, or sideways, or backward, to catch on SOLID objects. There is a risk of overturning or losing balance especially if the chair has a reduced seat and / or a high seat height (e.g. cushion). Make sure that the front wheels are in the front and the rear wheels braked when sitting on the wheelchair transferring to another location (e.g.
- Page 13 Upward Slope Do not hang anything above the backrest or above the armrest. This may cause the chair to tip over. To go up hills, install the anti-tippers. To this end insert the anti-tippers into the rear tube and take care that the safety clip protrudes out of the hole in the back tube, locking the anti-tippers into place.
- Page 14 Stairs – Up and Down When stairs are the only option, once the chair is tilted backwards by a person holding the chair by the handles, rest the rear wheels on the steps. The second person must hold a fixed part of the front area of the frame, lift the seat and hold it until the first person stands on the next step and so on.
- Page 15 How To Propel The Chair Yourself Once the user is seated in the chair, take the rings of the rear wheels with both hands, and forcefully push forward so that the chair begins to move. Release the rings. When the chair stops, repeat the action again. Using the Brakes Once the chair is stationary, the user holds the brakes with their hands, activates them, so that the rear wheels are...
-
Page 16: Safety Precautions
SAFETY PRECAUTIONS Failure to follow the safety precautions may result in the risk of serious injury. DO NOT exceed the maximum supported weight of 110kg. Make sure that all parts are in good working order. • • Do not use the product on stairs or escalators. •... - Page 17 • Stability - The Enforcer Wheelchair is designed to ensure safety and stability, provided that you maintain the center of gravity while using it. To preserve the chair's stability, it's important to avoid sudden movements that could lead to a shift in your center of gravity.
-
Page 18: Mounting
It is advisable to use the chair on flat surfaces, inside or outside a room, on longer journeys it is preferable that there is always a companion to help the user, in case of encountering obstacles. In order to use the wheelchair without problems, the speed must be between 3 and 5 km/h. The brakes are used to stop the chair. - Page 19 Adjusting footrests – installation, adjustment and removal The Footrests are folding inward for easy transfer. The footrest is adjustable in degrees of inclination. Note: To remove the footrest, squeeze the trigger toward the chair, rotate the footrests outward or inward and raise them. To install the footrests, place the plastic swivel on the tubing in front of the seat, turn the footrests inward, until you grasp the locking bolt.
-
Page 20: Care And Maintenance
CARE and MAINTENANCE Failure to care for and monitor your product may result in the risk of serious injury. Check upholstery regularly to ensure that there are no tears or looseness. • Clean the product regularly with warm water and a soft cloth. Do not use abrasive products, detergents or solvents. Do not use abrasive cleaners that may damage the finish. -
Page 21: Storage
WARNING! Do not modify your Enforcer Wheelchair in any way not authorized by the manufacturer. Do not use accessories if they have not been tested or approved by the manufacturer. -
Page 22: Warranty
Company’s discretion) free of charge. Any unauthorised modifications will invalidate the warranty. 12 MONTH LIMITED WARRANTY Your Top Gun Enforcer Wheelchair is fully guaranteed for 12-months FIVE-YEAR LIMITED WARRANTY from the date of purchase against faults arising due to defects in Structural frame ONLY manufacture or materials. - Page 23 Copyright Top Gun Mobility Owner’s Manual & Warranty Booklet 2023 19 | P a g e...
